The fields of the RADIUS screen are described in the table below.
Field Name
Enable Accounting
Server Address
Accounting Port
Retransmission
Interval
Number of
Retransmissions
Shared Secret
Select Attributes
(button)
The RADIUS dialog box has a secondary dialog box, RADIUS Attributes, that allows you to customize accounting
information sent to the RADIUS server by the MultiVOIP GSM. The MultiVOIP GSM software logs data about
many aspects of the call traffic going through the MultiVOIP GSM. The RADIUS Attributes screen lets you pick
which aspects will be included in the accounting reports sent to the RADIUS server.
Field Description
Select All Log report to include all fields
shown.
Channel Channel carrying call.
Number
Duration Length of call.
Packets Sent Total packets sent in call.
Bytes Sent Total bytes sent in call.
Packets Lost Packets lost in call.
Outbound DTMF digits received by this
Digits Sent gateway from remote gateway
(if that DTMF set to "Out of
Band").
Call Status Successful or unsuccessful.
Server Details The IP address of the traffic control server being used will be displayed here if the call is handled
through that server. The Options field refers to server features that might be activated.
From Details
Gateway Originating gateway
Name
IP Address IP address where call originated.
Description Identifier of where call originated.
Options When selected, log will record
Silence Compression and Forward
Error Correction by call originator.
Multi-Tech Systems, Inc.
RADIUS Screen Field Definitions
Values Description
Y/N When checked, the MultiVOIP GSM will access the accounting functionality
of the RADIUS server.
n.n.n.n IP address of the RADIUS server that handles accounting (billing) for the
current MultiVOIP GSM unit.
1 - 65535 TDM time slot at which RADIUS accounting information will be transmitted
and received.
If the MultiVOIP GSM sends out a packet to the RADIUS server and doesn't
receive a response in the retransmit interval, it will retransmit that packet
again and wait the retransmit interval again for a response. How many
0 - 255
times it does this is determined by the setting in the Number of
Retransmissions field.
alpha-numeric Client encryption key for the current VOIP unit.
-- Gives access to RADIUS Attributes screen. On Attributes screen, one can
specify the parameters to be tallied by the RADIUS server for accounting
(usually billing) purposes.
"RADIUS Attributes" Definitions
MVPGSM
Chapter 4: Configuring your MVPGSM
Field Description
Start Date, Time Date and time the phone call began.
Call Mode Voice or fax.
Packets Received Total packets received in call.
Bytes Received Total bytes received in call.
Coder Voice Coder /Compression Rate used for
call will be listed in log.
Prefix Matched When selected, the phonebook prefix
matched in processing the call will be
listed in log.
Gateway Completing or answering gateway
Name
IP Address IP address where call was completed/answered.
Description Identifier of where call was
completed/answered.
Options When selected, log will record Silence
Compression and Forward Error Correction by
party answering call.
To Details
