Interior Comfort
Bluetooth Hands-Free (Panel Operation)
NOTE
A device can be programmed only when the
l
vehicle is parked. If the vehicle starts to
move, the pairing procedure will end.
Programming is dangerous while driving -
pair up your device before you start
driving. Park the car in a safe place before
programming.
A total of seven devices can be programmed
l
to one vehicle. If you require an additional
device to be programmed to a vehicle with
seven devices already programmed, delete
one of the programmed devices before
programming the latest one.
If a Bluetooth device has already been
l
programmed to the vehicle as a Bluetooth
audio device, it does not need to be
programmed again when using the device
as a hands-free mobile phone. Conversely,
it does not need to be programmed again as
a Bluetooth audio device if it has already
been programmed as a hands-free mobile
phone.
Since the communication range of a
l
Bluetooth equipped device is about 10
meters (32 ft), if a device is placed within a
10-meter (32 ft) radius of the vehicle, it may
be detected/programmed unintentionally
while another device is being programmed.
Device registration can also be done by
l
operating the audio unit. Refer to
"Bluetooth Audio Preparation" (page
6-90).
Device registration can also be done using
l
voice recognition (page 6-101).
Depending on the device, the registration
l
status may be lost after a certain period of
time. If this occurs, repeat the entire
process from Step 1.
6-126
Form No.8BG7-EC-10H
Programming a Bluetooth Hands-Free
device which has a PIN code (four
digits)
1. Press selection button 6 to display the
Bluetooth Hands-Free setting menu
screen.
2. Press selection button 2 to display the
pairing program screen.
3. Enter Pin:0000 and
Rotate/Press TUNE dial to change
code. Select OK when complete. are
displayed for input of the PIN code.
4. Turn the manual tuning dial to select
the specified number for the Bluetooth
Hands-Free device and press the enter
button ( ) to input the number.
NOTE
Some devices accept only a particular
l
pairing code (Usually, "0000" or "1234").
If pairing cannot be completed, refer to the
l
owner's manual of your mobile device, and
try those numbers if necessary.
5. After inputting the four digits, turn the
manual tuning dial and select OK ,
and then press the enter button
( ) to set the four digits and
display
Pairing is in progress. Please start
pairing procedure on your Bluetooth
device. Use the PIN xxxx . .
NOTE
Press the return button (
to the pairing program screen.
) to return
