  • Page 1 CINE 6 R9002370 R9002379 OWNER'S MANUAL...
  • Page 3 BARCO PROJECTION SYSTEMS CINE 6 R9002370 R9002379 OWNER'S MANUAL Date : 01052000 Rev : 01 Art. No. : R5975809...
  • Page 4 Produced by BARCO NV, June 2000. All rights reserved. Trademarks are the rights of their respective owners. BARCO n.v./Projection Systems Noordlaan 5 B-8520 Kuurne Belgium Tel : +32/56/368211 Fax : +32/56/351651 E-mail : sales.bps@barco.com Visit Barco at the web : http://www.barco.com Printed in Belgium...

  • Page 5: Table Of Contents

    Internal Cross-Hatch Pattern ............................6-2 Selection Menu ................................6-2 Picture Tuning ................................6-2 Color Balance ................................6-3 Gamma ..................................6-3 Decoding ..................................6-3 Color Select ................................. 6-4 Geometry adjustments ..............................6-4 Horizontal Phase adjustment ............................. 6-5 R5975809 BARCO CINE 6 ____________________________________________________________________________________...
  • Page 6 How to activate the tuner mode ..........................A-1 Tuner Set-up ................................A-2 Broadcasting System ..............................A-2 Auto Search .................................. A-3 Manual Search ................................A-3 Organise Channel List ............................... A-4 Bilingual ..................................A-5 Teletext ..................................A-5 i - 2 ____________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 7: Safety Instructions

    INSTALLATION INSTRUCTIONS Before operating this equipment please read this manual thoroughly, and retain it for future reference. Installation and preliminary adjustments should be performed by qualified BARCO personnel or by authorized BARCO service dealers. OWNER’S RECORD The part number and serial number are located at the left side of the projector. Record these numbers in the spaces provided below.

  • Page 8: On Safety

    6. Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the projector due to lightning and AC power-line surges. 1 - 2 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 9: On Installation

    Replacement parts - When replacement parts are required, be sure the service technician has used original BARCO replace- ment parts or authorized replacement parts which have the same characteristics as the BARCO original part. Unauthorized substitutions may result in degraded performance and reliability, fire, electric shock or other hazards.
  • Page 10 Safety Instructions 1 - 4 ___________________________________________________________________________________ R5975809 BARCO CINE 6...
  • Page 11 13. RS 232 : Allows connection to the serial port of a Computer for controlling the projector. Front Panel Terminology IR SENSOR : Receiver for control signals transmitted from the RCU. IRIS Camera : ( optional ) R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 12: Locations And Functions Of Control

    - variable adjustment speed : when pushing continuously on the arrow keys or the picture keys, the adjustment will be executed in an accelerated fashion. Local Keypad ADJUST EXIT ENTER STANDBY stand-by pause/park sharpness tint color brightness contrast 2 - 2 ___________________________________________________________________________________ R5975809 BARCO CINE 6...
  • Page 13 RC operating indication : lights up when a button on the remote control is pressed. (This is a visual indicator to check the operation of the remote control). Function keys Direct access keys for certain menu functions. R5975809 BARCO CINE 6 ___________________________________________________________________________________...
  • Page 14 Locations and Functions of Control 2 - 4 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 15: Connections

    Composite video signals from a VCR, OFF air signal, decoder, etc. Composite Video 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 TV Tuner Audio Amplifier V C R R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 16: Connecting A Rgb Analog Source With Composite Sync

    It accepts RGB at 15 and 32 K. Always use an interface when a computer and local monitor have to be connected to the projector. Examples of interfaces which can be applied : Universal analog interface: R9826100 3 - 2 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 17: Connecting A Component Video Source

    The projector automatically determines the presence of a tuner. Connect the RF signal to the RF input of the projector. Connect the audio output to an audio amplifier. TV Antenna or Cable Network Audio Amplifier R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 18: Peripheral Equipment

    IR receiver and the projector or the RCVDS. The infrared control information from the RCU is sent to the IR Remote Receiver. The IR Remote Receiver 800 displays the selected source on a 7-segment display. Order No. R9827515. 3 - 4 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 19: Controlling

    Battery Compartment Cover The projector can be controlled with a. The RCU b. The hardwired RCU (cable not included) c. The local keypad. Controlling the projector with the RCU and the hardwired RCU is the same. R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 20: How To Use The Rcu

    The projector with the corresponding address will respond to that RCU. How to display the projector address. Press the ADDRESS key (recessed key on the RCU) with a pencil. The projector's address will be displayed in a 'Text box'. PROJECTOR ADDRESS 4 - 2 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 21: How To Program An Address Into The Rcu

    When a valid source number is selected, the projector will display this source or it will wait until the source becomes available. A message Source not available will be displayed for a short time. Warning source not available R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 22: Picture Controls

    Press the ADJUST key to display the GENERAL ACCESS menu. Use the arrow keys to highlight the desired control and press ENTER to select. GENERAL ACCESS BRIGHTNESS CONTRAST Enter ADJUST Select with then <ENTER> <EXIT> to return 4 - 4 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 23: The Pause Key

    The MUTE key stops the sound when pressed. Pressing a second time restarts the sound. Freeze Key When pressed on source 1 (Comp video) or source 02(S-video), the current frame is frozen and displayed. on pressing again programme continues. R5975809 BARCO CINE 6 ___________________________________________________________________________________...
  • Page 24 Controlling 4 - 6 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 25: Start Up Of The Adjustment Mode

    Some items in the Adjustment mode are password protected. while selecting such an item, the projector asks you to enter your password. (Password protection is only available when the Password strap on the controller module is in the ON position. Contact a BARCO authorized technician when no password is requested during the adjustment procedure and password protection is desired.) Your password contains 4 digits.
  • Page 26 When your password is correct, you get access to the Adjustment Mode. When the password is incorrect, the message WRONG PASSWORD will be displayed. The projector stays on the previously selected item. Factory programmed password : 0000 5 - 2 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 27: Random Access Adjustment Mode

    Random Access Adjustment Mode RANDOM ACCESS ADJUSTMENT MODE Starting up the Random Access Adjustment Mode. RANDOM ACCESS ADJUSTMENT MODE ENTER. ENTER EXIT MAIN MENU Image Control Function Keys WARNING RISK OF INCORRECT Service Menus ADJUSTMENT OF THE PROJECTOR. ADJUSTMENT MODE The following service menus are reserved to, and to be performed Select a path from below :...

  • Page 28: Selecting Setup Pattern

    Random Access Adjustment Mode Selecting a Setup Pattern Genlocked pattern Internal pattern Enter Exit Adjust Internal Cross Hatch Pattern INTERNAL # PATTERN INTERNAL INTERNAL # PATTERN ENTER Random Access Adjustment mode selection menu. RANDOM ACCESS RANDOM ACCESS ADJUSTMENT MODE. ADJUSTMENT MODE Picture Tuning PICTURE TUNING ENTER...

  • Page 29: Color Balance

    Random Access Adjustment Mode Color Balance PICTURE TUNING ENTER Custom Color Balance : ENTER COLOR BALANCE ENTER EXIT PICTURE TUNING Gamma PICTURE TUNING GAMMA COLOR BALANCE ENTER EXIT Decoding PICTURE TUNING Only for NTSC signals. DECODING ENTER ENTER EXIT PORT 2 : S-Video PICTURE TUNING ENTER EXIT...

  • Page 30: Color Select

    Random Access Adjustment Mode Color Select COLOR SELECT ENTER RANDOM ACCESS ADJUSTMENT MODE ENTER EXIT ADJUST ENTER EXIT COLOR SELECT RED AND BLUE ENTER EXIT Geometry Adjustments RANDOM ACCESS GEOMETRY RANDOM ACCESS ADJUSTMENT ENTER GEOMETRY ENTER EXIT ADJUST GEOMETRY GEOMETRY Horizontal Phase Adjustment GEOMETRY H PHASE...

  • Page 31: Raster Shift Adjustment

    Random Access Adjustment Mode Note : If the genlocked pattern was selected, the external source will be displayed. ENTER Raster Shift Adjustment CAUTION : GEOMETRY ENTER EXIT...
  • Page 32 Random Access Adjustment Mode WARNING : In order to ensure maximum CRT longevity and to avoid CRT damage, do not shift the raster outside the phosphor area of the CRT. EXIT...
  • Page 33 Random Access Adjustment Mode Left - Right (East-West) Adjustments GEOMETRY LEFT - RIGHT (E/W) Left-Right (E-W) ENTER ENTER EXIT ADJUST...
  • Page 34 Random Access Adjustment Mode Top-Bottom (North-South) Adjustments Top-Bottom (N/S) ENTER. GEOMETRY TOP-BOTTOM (N/S)

  • Page 35: Horizontal & Vertical Size Adjustment

    Random Access Adjustment Mode Horizontal & Vertical Size Adjustment H & V Size GEOMETRY ENTER GEOMETRY H or V SIZE ENTER EXIT ADJUST Note : if the internal # pattern was selected, the pattern remains on the screen. µ if the genlocked pattern was selected, the external source will be displayed. µ...

  • Page 36: Blanking Adjustment

    Random Access Adjustment Mode Blanking Adjustments BLANKING BLANKING GEOMETRY ENTER GEOMETRY BLANKING...
  • Page 37 Random Access Adjustment Mode Top, Bottom, Left Right ENTER EXIT...

  • Page 38: Convergence Adjustment

    Random Access Adjustment Mode Convergence Adjustment RANDOM ACCESS ADJUSTMENT MODE PICTURE TUNING GEOMETRY CONVERGENCE COLOR SELECT Select with then <ENTER> <EXIT> to return. CONVERGENCE GREEN ONLY RED ON GREEN BLUE ON GREEN Select with then <ENTER> <EXIT> to return. ENTER CONVERGENCE SEL : select area using...

  • Page 39: Service Mode

    DELETE A BLOCK DELETE ALL BLOCKS MEMORY MANAGEMENT ALL SETTINGS TO MIDPOS R & B CONVERGENCE MID G2 ADJUSTMENT CRT RUN IN CYCLE COMMON SETINGS PROJECTOR WARM UP CRT DRIVE MODE MEMORY BANK OFFSET CORRECTION I2C DIAGNOSTICS R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 40: Projector Set-Up

    The status can be changed by pressing the TEXT key once on the RCU. Serial No. : Indicates the manufacturing serial number of the projector. This number can be useful when technical assistance is required. 7 - 2 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 41: Total Run Time

    CHANGE PROJECTOR ADDRESS LANGUAGE CHANGE BAUDRATE POWERUP MODE : Standby ENGLISH COMMON ADDRESS ESPANOL BARCO LOGO FRANCAIS DEUTSCH Select with then <ENTER> Select new language with or <EXIT> to return then <ENTER> <EXIT> to return R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 42: Change Projector Address

    The current baud rate will be highlighted in the menu. To change the baud rate, use the arrow keys to select the desired baud rate and press ENTER to accept this baud rate. Pressing EXIT in this menu returns to PROJECTOR SETUP menu. 7 - 4 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 43: Power Up Mode

    <EXIT> to return BARCO LOGO By selecting this function, the BARCO LOGO can be enabled and positioned anywhere on the screen. Highlight 'BARCO LOGO' using the arrow keys and then press ENTER. The BARCO LOGO menu is displayed. PROJECTOR SET-UP...

  • Page 44: Copy A Block

    Active block nr. 1 Select with then <ENTER> Select with <EXIT> to return Scroll with <ENTER> to delete The selected block <EXIT> to return will be deleted ! <ENTER> to Confirm <EXIT> to cancel 7 - 6 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 45: Deletion Of All Blocks

    When Undo is selected, all settings are restored to their previous settings. MEMORY MANAGEMENT COPY A BLOCK DELETE A BLOCK DELETE ALL BLOCKS UNDO MIDPOSITION R & B CONVERGENCE TO MID Select with then <ENTER> <EXIT> to return R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 46: R&B Convergence Mid

    Again a confirmation screen will be displayed first. Press ENTER to confirm. CONVERGENCE OFF Press EXIT to cancel the procedure. convergence setting in current block will be overwritten ! <ENTER> to Confirm <EXIT> to cancel 7 - 8 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 47: Common Settings

    Select with EXIT returns to the Common settings menu. then <ENTER> ADJUST returns to the Operational mode. <EXIT> to return 'G2 adjustment should be performed by BARCO personnel, or BARCO authorized SAFETY dealers'. NOTICE RISK OF ELECTRICSAL SHOCK If you are qualified, press ENTER to continue. if not qualified, press EXIT to return to the Commmon settings menu.

  • Page 48: Crt Drive Mode

    Boost can be selected with arrow keys. Press ENTER to select mode. THE CRT'S ! Permanent Boost gives the Brightest Image but a reduced life for CRT. Select with then <ENTER> <EXIT> to return Memory Bank Toggle to ON or OFF 7 - 1 0 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 49: Adjustment For Removing Horizontal Centre Line

    V MIDLINE BOW OFFSET (VP) <EXIT> to return NS BOW OFFSET (HPVS) NS KEYSTONE OFFSET (HSVS) WARNING : PERFORMED ALL CORRECTIONS IN THE ORDER GIVEN ABOVE ! Select with then <ENTER> <EXIT> to return R5975809 BARCO CINE 6 ___________________________________________________________________________________ 7-11...
  • Page 50 V MIDLINE BOW OFFSET (VP) NS BOW OFFSET (HPVS) NS KEYSTONE OFFSET (HSVS) WARNING : PERFORMED ALL CORRECTIONS IN THE ORDER GIVEN ABOVE ! Select with then <ENTER> <EXIT> to return Centre line Yellow screen 7 - 1 2 ___________________________________________________________________________________ R5975809 BARCO CINE 6...
  • Page 51 Select with then <ENTER> <EXIT> to return Centre line ADJUST WITH ARROW KEYS Green screen LEFT / RIGHT KEYS Centre line HPVS SIDES Green screen UP / DOWN KEYS Centre line HPVS CENTER Green screen R5975809 BARCO CINE 6 ___________________________________________________________________________________ 7-13...
  • Page 52 UP / DOWN KEYS Centre line HSVS CENTER Green screen THIS COMPLETES THE ADJUSTMENT The offset adjustment can be adjusted for each block in the memory and the settings copied into new sources. 7 - 1 4 ___________________________________________________________________________________ R5975809 BARCO CINE 6...
  • Page 53 When no errors are detected, the following message will appear on the screen I2C DIAGNOSTICS Failure : addr IC number mod. name "No errors on I2C-bus detected". IC200 DECODER Select with then <ENTER> <EXIT> to return R5975809 BARCO CINE 6 ___________________________________________________________________________________ 7-15...

  • Page 54: Options

    = ground shield conductor conductor = data information When the cable is ready, plug one side in the remote control and the other side in the connector on the rear of the projector labelled ‘remote’. R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 55: Adapter And Communication Cables

    It offers the possibility to connect and switch up to 5 different Video sources, 3 different S-Video sources and 1 RGB Analog source to a BARCO projector. In addition, the audio signal proper to the source, can be switched to an audio amplifier.

  • Page 56: Appendix A : Tuner Mode

    When a new channel is displayed, a text box appears on the screen with preselection number, the channel name (when entered) and the sound reproduction. When you want to leave the tuner mode, press the BARCO key again. 2. Using the local keypad.

  • Page 57: Tuner Setup

    Broadcasting System The broadcasting system is the way the signals are transmitted through the air. Barco designed 4 different tuners to fulfil the different broadcasting systems worldwide. Changing the broadcasting system is only necessary for the BG/L system. BG system : European standard.

  • Page 58: Auto Search

    If another preselection is desired, press the corresponding digits with the numeric keys and press ENTER to store the displayed image in that program location. Press EXIT to return to the 'Tuner Setup' menu. TUNER SETUP MANUAL SEARCH MANUAL SEARCH R5975809 BARCO CINE 6 ___________________________________________________________________________________...

  • Page 59: Organise Channel List

    Maximum 6 position can be entered in the same way. When the name is programmed, press EXIT to return to the channel list. COMPOSE A - 4 ___________________________________________________________________________________ R5975809 BARCO CINE 6...

  • Page 60: Bilingual

    The selected sub-page will be displayed on the screen and remains on the screen. This page will frequently updated. HELP To display concealed information. Some teletext pages contain concealed information such as answers to puzzles. To reveal this information press the HELP key. R5975809 BARCO CINE 6 ___________________________________________________________________________________...
  • Page 61 Tuner Mode A - 6 ___________________________________________________________________________________ R5975809 BARCO CINE 6...
