Electrical Instructions And Limit Switch Adjustments; Limit Switch Adjustment - Linear VS-GSLG Installation Manual

VS-GSLG OPERATOR INSTALLATION GUIDE
You'll fi nd the complete electrical circuit print inside the operator cover. The power supply must be ample and not taken from
an overloaded line, as faulty operation will result. The supply must be of correct voltage and phase. For proper wire gauge,
refer to "Wiring Specifi cations" on Page 32.
Proper thermal protection is supplied with the operator. The motor contains a thermal overload protector (single phase) to
protect from overheating the motor due to overload or high-frequency operation.
Refer to the photo on page 7 when following these instructions.
Adjust the limit nuts by depressing the detent plate and turning the nuts in the desired direction of travel. To allow for addi-
tional travel in the open direction, for instance, rotate the open limit nut so that it moves to the left on the shaft. To allow for
greater travel in the close direction, rotate the close limit nut so that it moves to the right on the shaft.
Special Notes for Setting Speeds using LSO-2 & LSC-2:
Limit switches LSO-2 and LSC-2 control when the operator accelerates to maximum speed and decelerates to minimum
speed. It is recommended that LSO-2 and LSC-2 are adjusted fi rst* so the gate slows to near stop before hitting LSO-1 or
LSC-1 as these will apply the brake upon activation.
* These are adjusted by slightly loosening the two screws which hold them in place and sliding toward or away from the center
of the limit box. Care must be taken not to adjust too close to the center as the limit nut may travel past the switch and start
accelerating at the end of the cycle.
A. Power supply must be of correct voltage and phase.
B. Always disconnect power from operator before servicing.
C. Keep clear of gate during operation.
ELECTRICAL INSTRUCTIONS

LIMIT SWITCH ADJUSTMENT

(For Right Hand Operation, Left Hand Opposite)
IMPORTANT
- 5 -
