VS-GSLG OPERATOR INSTALLATION GUIDE
MODEL
REF.
NO. PART NO. DESCRIPTION
2120-359 Complete Enclosure with Door Assembly
1 2120-144 Enclosure without Door
2120-360 Complete Door and Lock Assembly
2500-2192 C-Face Brake, 115V
2500-2397 C-Face Brake, 208/230/460V
5 2110-265 Rail Assembly
15 2100-573 Spacer Plate
2100-661 Back Brace
12 2100-1738 Drive Shaft, 1"
48 2400-501 Retaining Ring
9 2200-274 Bearing, 1"
43 2100-1737 Pillow Block Retaining Plate
40 2200-042 Sprocket, 48-B-15, 1" bore
2200-015 Shaft Collar, 1"
7 2120-388 Torque Limiter Assembly, 5 1/2"
7A 2100-1650 Plate with Solid Pin Groove
7B 2100-1661 Keyed Plate
7C 2300-390 Friction Disc (pair)
7D 2200-817 Belleville Washer
7E 2100-1621 Belleville Washer Retaining Disc
7F 2100-1622 Adjustment Nut
7G 2400-407 Brass Tipped Set Screw
7H 2400-416 Dowel Pin
7I 2100-529 Woodruff Key
8 2200-555 Sprocket, 40-A-48
42 2200-886 Drive Sprocket, 50-B-20, 1" bore
2110-363 Gear Reducer/Disconnect Assembly
2 2200-551 Gear Reducer, 10:1
19 2120-132 Shifter Lever Assembly
18 2110-362 Shifter Lever Fulcrum Assembly
37 2100-551 Shifter Lever Rod
38 2400-169 Pal Nut
20 2100-1133 Locking Lever Plate
28 2100-910 Locking Lever
41 2200-291 Shifter and Locking Lever Spring
14 2200-014 Shaft Collar, 1"
11 2110-364 Sprocket, 40-A-24, with Bearing
30 2200-549 Disconnect Collar, 1" (keyed)
31 2110-131 Shifter Block
2400-133 Key, 1/4" x 1/4" x 2 1/4"
32 2200-115 Disconnect Spring
33 2400-308 Fender Washer, 3/8"
34 2400-017 Flat Washer, 3/8"
35 2400-016 Lock Washer, 3/8"
36 2400-207 HHCS, 3/8"-16 x 2 1/2"
VS-GSLG
MECHANICAL PARTS LIST
REF.
NO. PART NO.
16 2110-700
2300-697
2100-1731
6 2520-453
2500-764
2100-057
2200-030
2100-261
2110-162
2100-756-PLT Limit Box Cover only
2200-029
2400-029
2200-042
39 2200-008
2200-922
2200-041
2200-200
2200-276
2200-654
2200-432
2200-654
2200-010
2200-605
2200-006
17 2100-657
24 2200-221
2200-111
25 2100-258
26 2200-306
22 2100-2007
27 2400-090
23 2400-170
21 2400-038
2500-867
2510-064
4 2500-2313
2500-2315
2500-372
- 27 -
DESCRIPTION
Idler Assembly
UHMW Idler Wheel
Idler Shaft
Rotary Limit Box Assembly
Limit Switch
Standard Limit Shaft
Limit Nut
Detent Plate
Limit Box Enclosure with Cover
Flange Bearing, 1/2" ID
Push-On Nut
Limit Drive Sprocket, 48-B-15, 1" bore
For drives up to 34 feet wide:
Limit Box Sprocket, 48-B-10, 1/2" bore
#48 Chain, 25 Links
For drives from 35 to 49 feet wide:
Limit Box Sprocket, 48-B-15, 1/2" bore
#48 Chain, 27 Links
For drives from 50 to 65 feet wide:
Limit Box Sprocket, 48-B-20, 1/2" bore
#48 Chain, per foot, 29 links required
For drives over 65 feet wide:
Limit Box Sprocket, 48-B-30, 1/2" bore
#48 Chain, per foot, 32 links required
#48 Master Link
#40 Chain, 37 Links
#40 Master Link
Rain Cover
#50 Roller Chain, per foot
#50 Master Link
Chain Pin
Tension Spring
Gate Bracket
Hex Nut, 1/2"
Gate U-Bolt
Mounting U-Bolt
Alarm, 24VAC
3-Button Station with Lead Wires
C-Face Motors
1/2 HP, 208/230/460V, 3 Phase
1 HP, 208/230/460V, 3 Phase
2 HP, 208/230/460V, 3 Phase
