- Page 1 HSLG INSTALLATION GUIDE USA & Canada (800) 421-1587 & (800) 392-0123 (760) 438-7000 - Toll Free FAX (800) 468-1340 www.linearcorp.com UL325 COMPLIANCE REQUIRES THE USE OF CONTACT EDGES OR PHOTOELECTRIC CONTROLS ON ALL AUTOMATIC OR REMOTELY-CONTROLLED GATE OPERATORS.
-
Page 2: Table Of Contents
GATE OPERATOR INSTALLATION CHECKLIST ......................30 CAUTION! CAUTION! ONLY QUALIFIED SERVICE CAUTION! DO NOT INSTALL TECHNICIANS SHOULD DO NOT INSTALL CONTROLS ON A WORK ON AN LINEAR CONTROLS GATE OR FENCE SLIDE GATE OPERATOR ON THE OPERATOR LINE - 2 -... -
Page 3: Gate Operator Classifications
The following contact or non-contact obstruction detection devices have been approved for use with LINEAR slide gate operators as part of a UL325 compliant installation: Contact Edges: Miller Models*: MG0-20, MGR-20, MGS-20, and... -
Page 4: Installation Wiring Specifi Cations
You must use Belden 8760 Twisted Pair Shielded Cable distances. 24VAC is available for other devices, such as loop detectors (or equivalent) only – LINEAR part number 2500-1982, per foot). See and photo eyes. page 9 for details of this connection, as well as dip switch selection. -
Page 5: Post Mounting Instructions
Make sure that the chain sag does not exceed recommended sizes and that the chain does not come into contact with the moving parts of the gate or ground. For optional pad mounting instructions, see LINEAR drawing SIDE PLATE INSTALLATION #2700-360. -
Page 6: Gate Bracket And Chain Assembly Instructions
HSLG OPERATOR INSTALLATION GUIDE GATE BRACKET AND CHAIN ASSEMBLY INSTRUCTIONS Numbered items in these drawings are for instruc- tional reference only. For actual part numbers, go to the parts lists in the back of this booklet. Assemble a gate bracket (1) to the front edge of the gate, Assemble the other gate bracket on the rear edge of the using two U-bolts (2), and mounting hardware (3). -
Page 7: Torque Limiter Adjustments
HSLG OPERATOR INSTALLATION GUIDE TORQUE LIMITER ADJUSTMENTS Before adjusting the torque limiter, make sure the gate is in good working condition. One per- son should be able to move the gate by hand. Be certain the gate moves freely and without binding throughout its travel. -
Page 8: Electrical Connection And Adjustments
Keep clear of gate during operation. All LINEAR gate operators are supplied with a power disconnect switch to turn on and off the power supply available to the operator. Incoming power should be brought into the operator and connected to the labeled pigtails in the disconnect box following wiring specifi... -
Page 9: Control Board Adjustments
HSLG OPERATOR INSTALLATION GUIDE CONTROL BOARD ADJUSTMENTS LIMIT SWITCH L.E.D.s LIMIT SWITCH CONNECTOR TERMINAL STRIP #1 CONNECTOR 3A Fuse 2A Fuse TERMINAL STRIP #2 DIAGNOSTIC CONNECTOR L.E.D.s NOTE: DO NOT FORCE 270-DEGREE POTENTIOMETERS BEYOND THEIR NORMAL RANGE OF MOTION OR DAMAGE MAY RESULT! Auto Close Timer Adjustment: This 270-degree adjustable potentiometer will signal the operator to close automatically, provided no open, reversing or obstruction signals are present from the fully-open position. -
Page 10: Terminal Connection Descriptions
(See page 9 for details.) You must follow all required safety precautions and instructions at all times. Review the safety brochure in- cluded with the operator. If any pages are missing or unreadable, contact LINEAR at 1-800-333-1717 to request additional copies. -
Page 11: Current Sensing Adjustments
A three-wire shielded conductor cable is required to connect master and slave operators. You must use Belden 8760 Twisted Pair Shielded Cable (or equivalent) only – LINEAR part number 2500-1982, per foot). See page 9 for details of this connec- tion, as well as dip switch selection. -
Page 12: Onboard L.e.d. Indicator Descriptions
HSLG OPERATOR INSTALLATION GUIDE ONBOARD L.E.D. INDICATOR DESCRIPTIONS Control Board L.E.D. Indicators: OPEN This indicator is lit when an open signal is present. This signal can come from such devices as button stations, radio receivers, keypads and telephone entry systems. CLOSE This indicator is lit when a closed signal is present. -
Page 13: Important Notes For Installation Of Master/Slave Applications
HSLG OPERATOR INSTALLATION GUIDE IMPORTANT NOTES FOR INSTALLATION OF MASTER/SLAVE APPLICATIONS When setting up Master/Slave gate operators, it is best to make adjustments and run each operator individually. To do this, simply: a. Set Dip Switch #4 to proper hand of operation (right-hand or left-hand) b. -
Page 14: Control And Accessory Connection Illustrations
HSLG OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS - 14 -... - Page 15 HSLG OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS - 15 -...
- Page 16 HSLG OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS - 16 -...
- Page 17 HSLG OPERATOR INSTALLATION GUIDE CONTROL and ACCESSORY CONNECTION ILLUSTRATIONS - 17 -...
-
Page 18: Loop Layout Illustration
HSLG OPERATOR INSTALLATION GUIDE LOOP LAYOUT ILLUSTRATION Refer to Connection Descriptions on page 10 and Loop Accessory Connections on page 17 for details. - 18 -... -
Page 19: Edge Layout Illustration #1
HSLG OPERATOR INSTALLATION GUIDE EDGE LAYOUT ILLUSTRATION #1 Refer to Connection Descriptions on page 10 and Contact Edge Connections on page 16 for details. - 19 -... -
Page 20: Edge Layout Illustration #2
HSLG OPERATOR INSTALLATION GUIDE EDGE LAYOUT ILLUSTRATION #2 Refer to Connection Descriptions on page 10 and Contact Edge Connections on page 16 for details. - 20 -... -
Page 21: Photo Eye Illustration
HSLG OPERATOR INSTALLATION GUIDE PHOTO EYE ILLUSTRATION Refer to Connection Descriptions on page 10 and Photo Eye Connections on page 16 for details. - 21 -... -
Page 22: Picket Gate Illustration
HSLG OPERATOR INSTALLATION GUIDE PICKET GATE ILLUSTRATION Refer to Connection Descriptions on page 10 and Accessory Connections on pages 14-17 for additional details. - 22 -... -
Page 23: Track Gate Illustration
HSLG OPERATOR INSTALLATION GUIDE TRACK GATE ILLUSTRATION - 23 -... -
Page 24: Troubleshooting
Check for jumping. HOW TO ORDER REPLACEMENT PARTS Use the part numbers listed on the following pages. Contact your local LINEAR dealer or distributor to order parts. 1. Supply the model number and serial number of your operator. -
Page 25: Model Hslg Mechanical Parts Exploded View
HSLG OPERATOR INSTALLATION GUIDE HSLG MODEL MECHANICAL PARTS EXPLODED VIEW - 25 -... -
Page 26: Model Hslg Mechanical Parts List
HSLG OPERATOR INSTALLATION GUIDE HSLG MODEL MECHANICAL PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION Motors 2110-240 Intermediate Shaft Assembly 2500-2307 1/2 HP, 115V, 1 Phase 2100-765 Pulley Shaft 2500-2308 1/2 HP, 208/230V, 1 Phase 2200-213 Sprocket, 41-B-9, 5/8” bore 2500-2309 3/4 HP, 115V, 1 Phase 2200-309... -
Page 27: Model Hslg Single Phase Control Box Exploded View And Parts List
HSLG OPERATOR INSTALLATION GUIDE HSLG MODEL SINGLE PHASE CONTROL BOX PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION 2300-696 Clear Control Box Cover 2100-1778 Control Box Wrapper 2300-735 Heyco Bushing, 1.09 diameter 2100-1757 Control Box Mounting Plate 2100-1762 Terminal Strip Bracket, Output Side 2200-876 Plunger, Spring Loaded 2100-1761... -
Page 28: Model Hslg Three Phase Control Box Exploded View And Parts List
HSLG OPERATOR INSTALLATION GUIDE HSLG MODEL THREE PHASE CONTROL BOX PARTS LIST PART NO. DESCRIPTION PART NO. DESCRIPTION 2100-1865 Control Box Wrapper 2500-071 Terminal Strip, 16-141 2500-270 Terminal Strip, 9-142 OR 2100-1866 Control Box Cover 2500-185 Terminal Strip, 13-142 2100-1864 Terminal Strip Bracket 2300-488 Terminal Strip Barrier for 9-142 OR... -
Page 29: Preventative Maintenance
• Keep clear of gate during operation. GENERAL: LINEAR gate operators are designed for many years of trouble-free operation and, under recommended operating conditions, will require only minimal maintenance. To ensure that your unit is ready for operation at all times--and to preclude serious damage or failure--inspect the unit systematically. -
Page 30: Gate Operator Installation Checklist
HSLG OPERATOR INSTALLATION GUIDE GATE OPERATOR INSTALLATION CHECKLIST INSTALLER CUSTOMER ________ ________ 1. The gate has been checked to make sure it is level and moves freely in both directions. ________ ________ 2. Potential pinch areas have been guarded so as to be inaccessible OR have contact and/or non-contact obstruction sensing devices installed.
