Page 1: Installation Guide
HSLG Slide Gate Operator Installation Guide Operator models contained in this manual conform to UL325 standard for use in Class I, II, III, and IV applications USA & Canada (800) 421-1587 & (800) 392-0123 (760) 438-7000 - Toll Free FAX (800) 468-1340... -
Page 2: Table Of Contents
FCC Notice ..........27 Model HSLG Exploded View ....... . .28 Single Phase Controller Parts List . -
Page 3: Pre-Installation Information
If any pages are missing or are unreadable, four single family dwellings with a common garage or parking area or you do not have the safety instructions, please call Linear at associated with these dwellings. 1-800-333-1717 to request additional copies. -
Page 4: Wiring Specifi Cations
Wiring Specifi cations MODEL HSLG SINGLE PHASE POWER WIRING MAXIMUM DISTANCE (FEET) VOLTS & HP WIRE GAUGE Refer to the following steps for details on power and SINGLE DUAL accessory wiring for the operator. 115 VOLTS WARNING 1/2-HP ALL AC ELECTRICAL CONNECTIONS TO THE POWER SOURCE AND... -
Page 5: Mounting Pad Installation
Figure 1. Side contact with the moving parts of the gate or ground. Plate Installation Figure 2. Post Mounting Specifi cations - 3 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 6: Gate Bracket And Chain Assembly
IDLER WHEEL IDLER WHEEL DRIVE CHAIN SPROCKET PATH IDLER CHAIN WHEEL PATH NOTE: IDLER CONFIGURATION MAY APPEAR DIFFERENT DEPENDING ON THE SLIDE OPERATOR MODEL Figure 5. Chain Path - 4 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 7: Operator Setup
GATE IS MANUALLY MOVED MUST OBSERVE ALL NATIONAL AND LOCAL ELECTRICAL CODES AC Power Connection All Linear gate operators are supplied with a power disconnect switch to turn on and off the power available MANUAL DISCONNECT to the operator. Following wiring specifi cations on Page 2,... -
Page 8: Open And Close Limit Adjustment
CLOCKWISE ONE FLAT during normal operation. See Figure 11. THEN RE-TEST LESS To adjust the torque limiter in model HSLG: 1. Loosen the jam nut. TO DECREASE TORQUE TIGHTEN JAM NUT 2. To increase the output, turn the adjustment nut clockwise... -
Page 9: Controller Features
INPUT TERMINALS OUTPUT INPUT TERMINALS TERMINALS REVERSE INPUT TERMINALS TERMINALS INPUT TERMINALS ALARM OPEN LOOP SHADOW/RESET LOOP OUTPUT INPUT TERMINALS INPUT TERMINALS TERMINALS Figure 12. Controller Features - 7 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 10: Indicator Descriptions
SELECTION MAXIMUM CLOSE REVERSE ANTI-TAILGATE RESET TO "CC" "RD" "AT" "CL" CURRENT DELAY TIME ENABLE FACTORY DEFAULTS ADVANCED BRAKE RADIO "AD" "BD" "RA" PROGRAMMING DELAY TIME ENABLE - 8 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 11: Terminal Descriptions
STROBE LIGHT) FOR ACTIVATION (OR DEACTIVATION) DURING GATE OPERATION. N.C. 24 VOLT SOLAR PANEL NOT USED WITH THIS MODEL OPERATOR. 24 VOLT BATTERY NOT USED WITH THIS MODEL OPERATOR.. - 9 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 12: Operator Accessory Connections
MAGLOCK GATE EDGE SENSOR FOR REVERSE TWO-CHANNEL RADIO RECEIVER WARNING STROBE OR AUDIBLE SOUNDER CHANNEL #1 WIRELESS GATE EDGE SENSOR OPEN/CLOSE TRANSMITTER Figure 13. Operator Accessory Connections - 10 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 13: Basic Controller Programming
PRESS UP OR 1 TO 59 SECONDS DOWN TO CYCLE THROUGH OPTIONS SET TIMER VALUE PRESS ENTER TO 1 TO 9 MINUTES SELECT AN OPTION AUTO CLOSE TIMER - 11 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 14: Run Alarm And Pre-Start Alarm
(50-75 lbs.) will activate a reversal should an obstruction occur, but high enough to keep the gate moving under normal conditions without interruption. - 12 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 15: Advanced Controller Programming
SET STAGGER DELAY VALUE 1 TO 99 SECONDS PRESS UP OR DOWN TO CYCLE THROUGH OPTIONS STAGGER DUAL GATES PRESS ENTER TO SELECT AN OPTION DELAY TIME ONLY - 13 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 16: Auxiliary Relay Mode
OPEN INHIBIT ON, SHADOW LOOP INHIBITS OPENING AND CLOSING PRESS UP OR DOWN TO CYCLE THROUGH OPTIONS SHADOW LOOP PRESS ENTER TO SELECT AN OPTION OPEN PREVENTION - 14 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 17: Reset Cycle Count
DOWN TO CYCLE antenna. If using a remote antenna, connect coax cable from the antenna THROUGH OPTIONS to the ANTENNA connector. RADIO PRESS ENTER TO SELECT AN OPTION ENABLE - 15 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 18: Radio Transmitter Learn
SELECT AN OPTION DO NOT SELECT OR MOTOR TYPE. NOT USED IN THIS MODEL RESET TO MOTOR TYPE DO NOT SELECT FACTORY DEFAULTS SELECTION NOT USED IN THIS MODEL - 16 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 19: Loop Layout Illustration
Loop Layout Illustration - 17 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 20: Safety Edge Layout Illustration #1
Safety Edge Layout Illustration #1 - 18 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 21: Safety Edge Layout Illustration #2
Safety Edge Layout Illustration #2 - 19 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 22: Photoeye Installation Illustration
Photoeye Installation Illustration - 20 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 23: Picket Gate Installation
Picket Gate Installation - 21 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 24: Track Gate Installation
Track Gate Installation - 22 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 25: Dual Gate Installations
CONTACTOR 208/230 VOLT HEATER (P/N 2510-273) THREE PHASE 460V MODELS CONTACTOR 460 VOLT HEATER (P/N 2510-354) Figure 15. In-cabinet Heater Wiring - 23 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 26: Gate Operation
While the gate is opening or closing, the number of seconds obstruction input is cleared, the gate will close when the running time is displayed. auto close timer expires. - 24 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 27: Error Indications
Maximum Run Time has been exceeded, the sounder will beep twice every fi ve seconds. The next operation of the gate will clear the indication. - 25 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 28: How To Order Replacement Parts
How to Order Replacement Parts Use the part numbers listed on the following pages. Contact your local Linear dealer or distributor to order parts. 1. Supply the model number and serial number of your operator. 2. Specify the quantity of pieces needed and order by part number and name of part. -
Page 29: Preventative Maintenance
General 2. For operators with V-belts, inspect for wear and replace Linear gate operators are designed for many years of as necessary. Check for proper tension and adjust if trouble-free operation and, under recommended operating required. Check all pulley setscrews for tightness and conditions, will require only minimal maintenance. -
Page 30: Model Hslg Exploded View
Model HSLG Exploded View - 28 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... - Page 31 Stop/Reset Button Mounting Bracket 2200-276 Limit Box Sprocket, 48-B-20, 1/2” bore 2500-1495 Stop/Reset Button 2200-654 #48 Chain, per foot, 30 Links required 2200-202 #40 Chain, per foot 2400-038 U-Bolt, 4-5/8” - 29 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011...
-
Page 32: Single Phase Controller Parts List
208/230V Power Box Assembly 2100-2143 Power Box Mounting Strap 2300-1025 Apex Plastic Cover 2510-423 Cover Knob Kit 2100-1781 Accessory Shelf 2520-525 Complete Wiring Harness Assembly (not shown) - 30 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 33: Three Phase Controller Parts List
Control Box Assembly (Complete) 460V 2110-840 Control Box Assembly (Box only) 2100-582 Cover 2500-2393 Apex Module 2500-1980 Motor Board 2500-034 Power Switch 2500-767 Transformer 208/230V 2500-768 Transformer 460V 2500-2084 Contactor - 31 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011... -
Page 34: Gate Operator Installation Checklist
By signing this installation checklist, I/we hereby certify that each item listed and checked above has been covered by the installer and is clearly understood by the customer. Customer’s Signature Date Installer’s Signature Date - 32 - HSLG Slide Gate Operator Installation Guide P1220 Revision X8 6-22-2011...
