VS-GSLG OPERATOR INSTALLATION GUIDE
5
13
11
8
VS-GSLG
MODEL
REF.
NO. PART NO. DESCRIPTION
Variable Speed Control Box Assemblies
2520-459 1/2 HP, 115V, 1-Phase Controller
2520-460 1/2 HP, 208/230V, 1-Phase Controller
2520-461 1/2 HP, 208/230V, 3-Phase Controller
2520-462 1/2 HP, 460V, 3-Phase Controller
2520-455
2520-456 1 HP, 208/230V, 1-Phase Controller
2520-457 1 HP, 208/230V, 3-Phase Controller
2520-458 1 HP, 460V, 3-Phase Controller
2520-417 2 HP, 208/230V, 1-Phase Controller
2520-418 2 HP, 208/230V, 3-Phase Controller
2520-419 2 HP, 460V, 3-Phase Controller
1 2120-447 Enclosure with Cover, VS
2 2500-2084-HALF 24VAC Contactor, half block
3 Transformers
2500-766 115/24V, 75VA
2500-767 208/230/24V, 75VA
2500-768 460/24V, 75VA
4 Hitachi Controllers
2500-2244 1/2 HP, 115VAC, 1-Phase
2500-2246 1/2 HP, 208/230VAC, 1- or 3-Phase
2500-2249 1/2 HP, 460VAC, 3-Phase
2500-2245 1 HP, 115VAC, 1-Phase
1
10
3
1 HP, 115V, 1-Phase Controller
8
12
2
CONTROL BOX WITH HITACHI
REF.
NO. PART NO.
4 Hitachi Controllers continued
2500-2247
2500-2250
2500-2248
2500-2251
5 2500-2207
7 2510-295-VS
2510-268-VS
2500-1980
2500-1975
2500-1966
8 2500-071
9 2500-2291
10 2510-250
11 2510-249
12 2510-253
13 2510-346
2510-371
- 28 -
9
DESCRIPTION
1 HP, 208/230VAC, 1- or 3-Phase
1 HP, 460VAC, 3-Phase
2 HP, 208/230VAC, 1- or 3-Phase
2 HP, 460VAC, 3-Phase
Optional Low Voltage Surge Protector
Control Board with 3-Phase Motor Board
Control Board only
3-Phase Motor Board (top board)
3-Amp Fuse for Control Board
2-Amp Fuse for Control Board
Terminal Strip, 16-141
Power On/Off Switch, 30 Amp, 600VAC
Output Wire Harness Assembly
Input Wire Harness Assembly
Limit Switch Harness
Control Box Motor Harness, 115/230VAC
Control Box Motor Harness, 460V
4
7
