VS-GSLG OPERATOR INSTALLATION GUIDE
Imperial Oil
3 sso
Date Prepared: February 02, 1996
Supersedes: January 07, 1995
MSDS Number: 225570
Cette fi che signaletique ast aussi disponible en francais
1. PRODUCT INFORMATION
Product Identifi er: ESSO GEAR OIL GX 80W-90
Application and Use: Premium quality multigrade extreme pressure gear oil for use in automotive ap-
plications including some manual transmissions.
Product Description: A lubricating oil consisting of a saturated and unsaturated hydrocarbons derived
from paraffi nic distillate, and additives.
REGULATORY CLASSIFICATION
WHMIS: Not a controlled product
CEPA: CANADIAN ENVIRONMENTAL PROTECTION ACT
All components of this product are either on the Domestic Substances List (DSL) or are exempt.
TRANSPORTATION OF DANGEROUS GOODS INFORMATION
Shipping Name: Petroleum Lubricating Oil
Class: Not regulated Packing Group:
PIN Number: Not regulated Guide Number:
Please be aware that other regulations may apply.
TELEPHONE NUMBERS
Emergency 24 hr. 519-339-2145
Technical Info. 800-268-3183
2. REGULATED COMPONENTS
The following components are defi ned in accordance with subparagraph 13(a) (l) to (lv) or paragraph
14(a) of the Hazardous Products Act:
NAME
Not applicable
3. TYPICAL PHYSICAL & CHEMICAL PROPERTIES
Physical State: Liquid
Specifi c gravity: not available
Viscosity: 15.50 cSt at 100 deg. C
Vapour Density: not available
Boiling point: 229 to 600 deg. C
Evaporation rate: <0.1 (1=n-butylacefate)
Solubility in water: negligible
Freezing/Pour Point: -27 deg. C D97
Odour Threshold: not available
Vapour Pressure: <0.1 kPa at 20 deg. C
Density: 0.89 g/cc at 15 deg. C
Appearance/odour: Dark brown liquid, petroleum hydrocarbon odour.
4. HEALTH HAZARD INFORMATION
NATURE OF HAZARD:
INHALATION: Negligible hazard at normal temperatures (up to 38 deg. C). Elevated temperatures or
mechanical action may form vapours, mists or fumes which may be irritating to the eyes, nose, throat
and lungs. Avoid breathing vapours or mists.
EYE CONTACT: Slightly irritating, but will not injure eye tissue.
SKIN CONTACT: Low toxicity. Frequent or prolonged contact may irritate the skin.
INGESTION: Low toxicity.
ACUTE TOXICITY DATA: Based on animal testing data from similar materials and products, the acute
toxicity of this product is expected to be:
Oral: LD50 > 5000 mg/kg (rat)
Dermal: LD50 > 3160 mg/kg (rabbit)
Inhalation: LC50 > 5000 mg/m3 (rat)
OCCUPATIONAL EXPOSURE LIMIT:
ACGIH recommends: For oil mists, 5 mg/m3. Local regulated limits may vary.
5. FIRST AID MEASURES
INHALATION: Vapour pressure of this material is low and as such inhalation under normal conditions
is usually not a problem. If overexposed to oil mist, remove from further exposure. Administer artifi cial
respiration if breathing has stopped. Keep at rest. Call for prompt medical attention.
EYE CONTACT: Flush eyes with large amounts of water until irritation subsides. If irritation persists,
get medical attention.
SKIN CONTACT: Flush with large amounts of water. Use soap if available. Remove severely contami-
nated clothing (including shoes) and launder before reuse. If irritation persists, seek medical attention.
INGESTION: If swallowed, DO NOT induce vomiting. Keep at rest. Get prompt medical attention.
6. PREVENTIVE AND CORRECTIVE MEASURES
PERSONAL PROTECTION: The selection of personal protective equipment varies, depending upon
conditions of use. In open systems where contact is likely, wear safety goggles, chemical-resistant
overalls, and chemically impervious gloves. Where only incidental contact is likely, wear safety glasses
with side shields. No other special precautions are necessary provided skin/eye contact is avoided.
Where concentrations in air may exceed the occupational exposure limits given in Section 4 and where
engineering, work practices or other means of exposure reduction are not adequate, approved respira-
tors may be necessary to prevent overexposure by inhalation.
ENGINEERING CONTROLS: The use of local exhaust ventilation is recommended to control emis-
sions near the source. Laboratory samples should be handled in a fumehood. Provide mechanical
ventilation of confi ned spaces.
Esso Sheet 80W-90 082500
Not regulated
129
MANUFACTURER/SUPPLIER
IMPERIAL OIL
Products Division
111 St. Clair Ave. West
Toronto, Ontario M5W 1K3
416-968-4111
% CAS #
MATERIAL SAFETY DATA SHEET
HANDLING, STORAGE AND SHIPPING: Keep containers closed. Handle and open containers with
care. Store in a cool, well ventilated place away from incompatible materials. Do not handle or store
near an open fl ame, sources of heat, or sources of ignition. Odorous and toxic fumes may form from
the decomposition of this product if stored at temperatures in excess of 45 deg. C for extended periods
of time or if heat sources in excess of 121 deg. C are used. Empty containers may contain product
residue. Do not pressurize cut, heat, or weld empty containers. Do not reuse empty containers without
commercial cleaning or reconditioning.
LAND SPILL: Eliminate source of ignition. Keep public away. Prevent additional discharge of material. If
possible to do so without hazard. Prevent spills from entering sewers, watercourses or low areas. Con-
tain spilled liquid with sand or earth. Recover by pumping or by using a suitable absorbent. Consult an
expert of disposal or recovered material. Ensure disposal in compliance with government requirements
and ensure conformity to local disposal regulations. Notify the appropriate authorities immediately. Take
all additional action necessary to prevent and remedy the adverse effects of the spill.
WATER SPILL: Remove from surface by skimming or with suitable absorbants. If allowed by local
authorities and environmental agencies, sinking and/or suitable dispersants may be used in uncon-
fi ned waters. Consult an expert on disposal of recovered material. Ensure disposal in compliance with
government requirements and ensure conformity to local disposal regulations. Notify the appropriate
7. FIRE AND EXPLOSION HAZARD
Flashpoint and method: 178 deg. C COC D92
Autoignition: NA
GENERAL HAZARDS:
Low hazard; liquids may burn upon heating to temperatures at or above the fl ash point. Decomposes;
fl ammable/toxic gases will form at elevated temperatures (thermal decomposition). Toxic gases will
form upon combustion.
FIRE FIGHTING: Use water spray to cool fi re exposed surfaces and to protect personnel. Shut off
fuel to fi re.
Use foam, dry chemical or water spray to extinguish fi re. Respiratory and eye protection required for
fi re fi ghting personnel. Avoid spraying water directly into storage containers due to danger of boilover.
A self-contained breathing apparatus (SCBA) should be used for all indoor fi res and any signifi cant
outdoor fi res. For small outdoor fi res, which may easily be extinguished with a portable fi re extinguisher,
use of an SCBA may not be required.
HAZARDOUS COMBUSTION PRODUCTS: Smoke, carbon monoxide, carbon dioxide and traces of
8. REACTIVITY DATA
STABILITY: This product is stable. Hazardous polymerization will not occur.
INCOMPATIBLE MATERIALS AND CONDITIONS TO AVOID: Strong oxidizing agents.
HAZARDOUS DECOMPOSITION: Smoke, carbon monoxide, carbon dioxide, oxides of sulphur and
phosphorus. Alkyl mercaptans and sulfi des may also be released.
9. NOTES
This MSDS has been revised in Section 3.
10. PREPARATION
Date Prepared:
Prepared by: Lubricants & Specialties
CAUTION: "The information contained herein relates only to this product or material and may not be
valid when used in combination with any other product or material or in any process. If the product is
not to be used for a purpose or under conditions which are normal or reasonably foreseeable, this in-
formation cannot be relied upon as complete or applicable. For greater certainty, uses other than those
described in Section 1 must be reviewed with the supplier. The information contained herein is based
on the information available at the indicated date of preparation. This MSDS is for the use of Imperial
Oil. Customers and their employees and agents only. Any further distribution of this MSDS by Imperial
Oil customer is prohibited without the written consent of Imperial Oil."
IMPERIAL OIL
Products Division
ESSO GEAR OIL GX 80W-90
- 31 -
Flammable Limits: LEL: NA UEL: NA
February 02, 1996
IMPERIAL OIL
Products Division
111 St. Clair Ave., West
Toronto, Ontario MsW 1K3
800-268-3183
