Page 1: Installation Guide
Swing Gate Operator Installation Guide Operator models contained in this manual conform to UL325 standard for use in Class I, II, III, and IV applications USA & Canada (800) 421-1587 & (800) 392-0123 (760) 438-7000 - Toll Free FAX (800) 468-1340 www.linearcorp.com... -
Page 2: Table Of Contents
Indicator Descriptions ........9 Model SWG Exploded View........26 Terminal Descriptions . -
Page 3: Pre-Installation Information
If any pages are missing or are unreadable, four single family dwellings with a common garage or parking area or you do not have the safety instructions, please call Linear at associated with these dwellings. 1-800-421-1587 to request additional copies. -
Page 4: Wiring Specifi Cations
Wiring Specifi cations MODEL SWG SINGLE PHASE POWER WIRING MAXIMUM DISTANCE (FEET) VOLTS & HP WIRE GAUGE Refer to the following steps for details on power and SINGLE DUAL accessory wiring for the operator. 115 VOLTS WARNING 1/2-HP 1430 ALL AC ELECTRICAL CONNECTIONS TO THE POWER SOURCE AND... -
Page 5: Mounting Pad Installation
FOR ARM CLEARANCE WHILE OPENING IF NON-STANDARD MOUNTING IS NECESSARY, CONSULT THE FACTORY OPERATOR ACCESS DOOR MUST FACE AWAY FROM DRIVEWAY Figure 2. Mounting Pad Specifi cations - 3 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 6: Operator Preparation
✓ NOTE: Illustrations shown on this page are for right-hand application. For left-hand, overtravel stop (9) should be on the opposite side Figure 5. Overtravel Stop Installation - 4 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 7: Gate Plate Installation
Setting the Arm Lengths Most installations will use the standard dimensions specifi ed. If non-standard mounting is required, contact the factory for information. Figure 7. Pipe Link Installation - 5 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 8: Operator Setup
THE OPERATOR MUST BE MADE BY A LICENSED ELECTRICIAN AND MUST OBSERVE ALL NATIONAL AND LOCAL ELECTRICAL CODES AC Power Connection All Linear gate operators are supplied with a power LOOSEN KNOB disconnect switch to turn on and off the power available TO REMOVE to the operator. -
Page 9: Torque Limiter Adjustment
ADJUSTED. is in good working condition. With the gate disconnected Figure 10. Model SWG Limit Switches & Cams from the gate arm, one person should be able to move the gate by hand. Be certain the gate moves freely and without binding throughout its travel. -
Page 10: Controller Features
INPUT TERMINALS OUTPUT INPUT TERMINALS TERMINALS REVERSE INPUT TERMINALS TERMINALS INPUT TERMINALS ALARM OPEN LOOP SHADOW/RESET LOOP OUTPUT INPUT TERMINALS INPUT TERMINALS TERMINALS Figure 12. Controller Features - 8 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 11: Indicator Descriptions
SELECTION MAXIMUM CLOSE REVERSE ANTI-TAILGATE RESET TO "CC" "RD" "AT" "CL" CURRENT DELAY TIME ENABLE FACTORY DEFAULTS ADVANCED BRAKE RADIO "AD" "BD" "RA" PROGRAMMING DELAY TIME ENABLE - 9 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 12: Terminal Descriptions
STROBE LIGHT) FOR ACTIVATION (OR DEACTIVATION) DURING GATE OPERATION. N.C. 24 VOLT SOLAR PANEL NOT USED WITH THIS MODEL OPERATOR. 24 VOLT BATTERY NOT USED WITH THIS MODEL OPERATOR. - 10 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 13: Operator Accessory Connections
MAGLOCK GATE EDGE SENSOR FOR REVERSE TWO-CHANNEL RADIO RECEIVER WARNING STROBE OR AUDIBLE SOUNDER CHANNEL #1 WIRELESS GATE EDGE SENSOR OPEN/CLOSE TRANSMITTER Figure 13. Operator Accessory Connections - 11 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 14: Basic Controller Programming
PRESS UP OR 1 TO 59 SECONDS DOWN TO CYCLE THROUGH OPTIONS SET TIMER VALUE PRESS ENTER TO 1 TO 9 MINUTES SELECT AN OPTION AUTO CLOSE TIMER - 12 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 15: Run Alarm And Pre-Start Alarm
(50-75 lbs.) will activate a reversal should an obstruction occur, but high enough to keep the gate moving under normal conditions without interruption. - 13 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 16: Advanced Controller Programming
SET STAGGER DELAY VALUE 1 TO 99 SECONDS PRESS UP OR DOWN TO CYCLE THROUGH OPTIONS STAGGER DUAL GATES PRESS ENTER TO SELECT AN OPTION DELAY TIME ONLY - 14 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 17: Auxiliary Relay Mode
OPTIONS This function is displayed, but only used in operators with SET TIMER VALUE "BD" mechanical brakes. The Model SWG does not have a mechanical 0 TO 3 SECONDS brake. PRESS UP OR The factory default sets the Brake Delay to no delay (0 seconds). Heavy... -
Page 18: Reset Cycle Count
THROUGH OPTIONS the antenna to the ANTENNA connector. RADIO PRESS ENTER TO SELECT AN OPTION ENABLE - 16 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 19: Radio Transmitter Learn
AC MOTOR PRIMARY WITH OR MOTOR TYPE. DC MOTOR BACKUP WITH BRAKING RESET TO MOTOR TYPE AC MOTOR PRIMARY WITH FACTORY DEFAULTS SELECTION DC MOTOR BACKUP WITH SOFT START/STOP - 17 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 20: Loop Layout Illustration
Loop Layout Illustration - 18 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 21: Safety Edge Layout Illustration
Safety Edge Layout Illustration - 19 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 22: Photoeye Installation Illustration
Photoeye Installation Illustration - 20 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 23: Dual Gate Installations
C - C SHIELDED CABLE OR EQUIVALENT B - B A - A OPERATOR #2 CONNECT SHIELD WIRE AT BOTH ENDS SHIELD Figure 14. COMM LINK Wiring - 21 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 24: Gate Operation
While the gate is opening or closing, the number of seconds auto close timer is set, when the close obstruction input is running time is displayed. cleared, the gate will close when the auto close timer expires. - 22 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 25: Error Indications
Maximum Run Time has been exceeded, the sounder will beep twice every fi ve seconds. The next operation of the gate will clear the indication. - 23 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 26: How To Order Replacement Parts
How to Order Replacement Parts Use the part numbers listed on the following pages. Contact your local Linear dealer or distributor to order parts. 1. Supply the model number and serial number of your operator. 2. Specify the quantity of pieces needed and order by part number and name of part. -
Page 27: Preventative Maintenance
General 2. For operators with V-belts, inspect for wear and replace Linear gate operators are designed for many years of as necessary. Check for proper tension and adjust if trouble-free operation and, under recommended operating required. Check all pulley setscrews for tightness and conditions, will require only minimal maintenance. -
Page 28: Model Swg Exploded View
Model SWG Exploded View - 26 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... - Page 29 2100-206 #40 Chain, 30 Links 2200-467 #40 Chain, 22-1/2” 2200-006 #40 Master Link 2400-254 Key, 3/16” x 3/16” x 3” 2400-201 Key, 1/4” x 1/4” x 1-1/2” - 27 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013...
-
Page 30: Single Phase Controller Parts List
115V Power Box Assembly 2510-430 208/230V Power Box Assembly 2100-2143 Power Box Mounting Strap 2300-1025 Apex Plastic Cover 2510-423 Cover Knob Kit 2520-526 Complete Wiring Harness Assembly (not shown) - 28 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 31: Three Phase Controller Parts List
2100-2148 Cover 2500-2393 Apex Module 2500-1980 Motor Board 2500-034 Power Switch 2500-767 Transformer 208/230V 2500-768 Transformer 460V 2500-2084 Contactor 2510-423 Cover Knob Kit 2300-1025 Apex Plastic Cover - 29 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... -
Page 32: Gate Arm Assembly Parts List
Spacer - black, 1 1/4” OD x 1/2” ID x 1/2” LTB 2100-1320 Spacer - zinc-silver, 3/4” OD x 1/2” ID x 1/2” LTB 2400-309 Set Screw, 1/4” - 20 x 1/2” - 30 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013... - Page 33 This page intentionally left blank. - 31 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013...
-
Page 34: Gate Operator Installation Checklist
By signing this installation checklist, I/we hereby certify that each item listed and checked above has been covered by the installer and is clearly understood by the customer. Customer’s Signature Date Installer’s Signature Date - 32 - SWG Swing Gate Operator Installation Guide P1227 Revision X5 2-13-2013...
