Installation

Parts supplied
4. Attach the camera stand and rear
view camera. (Fig. 3-4)
�� Rear view camera × 1
Route the cables as shown in the figure so
�� RCA power supply cable × 1
that they do not become entangled.
�� Image processing unit power supply × 1
�� Button unit × 1
Attach the camera stand while being
�� Hexagonal wrench × 1
careful not to mistake the vertical
�� Velcro tape (soft type) × 1
orientation
�� Velcro tape (hard type) × 1
of the rear view camera. (Fig. 8)
�� Metal clamp × 5
�� Plastic clamp × 10
Installation Procedure
�� Waterproof pad × 1
�� Double-sided tape (rectangular) × 1
�� Double-sided tape (square) × 1
Note:
�� Camera stand bracket �� × 1
• Before making a final installation of the unit,
temporarily connect the wiring to confirm that
Installation example (Fig. 1)
the connections are correct and the system works
properly.
① Glass surface
• Use only the parts included with the unit to ensure
② Make sure it doesn't touch the wiper
proper installation. The use of unauthorized parts
③ Install on the center part
can cause malfunctions.
• Consult with your nearest dealer if installation
Note:
requires the drilling of holes or other
• The position and angle of the image from the rear
modifications of the vehicle.
view camera can still be adjusted using the initial
• Install the unit where it does not get in the driver's
setup even if the camera is not installed in the
way and cannot injure the passenger if there is a
center of the vehicle. Refer to "First Time Setup"
sudden stop, like an emergency stop.
in the Owner's Manual for details.
• When mounting this unit, make sure none of
Changing the orientation of camera
the leads are trapped between this unit and the
surrounding metalwork or fittings.
stand installation (Fig. 12-1)
• To prevent electric shock, do not install the image
processing unit power supply in places where it
The camera stand can be installed in
might come in contact with liquids.
various ways by changing the direction in
• Do not mount this unit near the heater outlet,
which camera stand bracket �� is attached
where it would be affected by heat, or near the
or attaching camera stand bracket ��.
doors, where rainwater might splash onto it.
Change to match your car's shape or the
(Never install in locations such as the above
installation site.
because of the danger of malfunction due to high
temperatures.)
1. Use the hexagon wrench to remove
• Before drilling any mounting holes always check
the screws securing camera stand
behind where you want to drill the holes. Do not
brackets �� and ��. (Fig. 2)
drill into the gas line, brake line, electrical wiring
2. Change the direction of installation
or other important parts.
bracket ��. (Fig. 3-1)
• If this unit is installed in the passenger compartment,
anchor it securely so it does not break free while the
3. Reattach with the screws.
car is moving, and cause injury or an accident.
• If this unit is installed under a front seat, make
Installing Using Camera Stand Bracket ��
sure it does not obstruct seat movement. Route
(Fig. 12-4)
all leads and cords carefully around the sliding
mechanism so they do not get caught or pinched
1. Use the hexagon wrench to remove
in the mechanism and cause a short circuit.
the screws securing camera stand
• Locate in the position you want to install the rear
brackets �� and ��. (Fig. 2)
view camera. Adjust the angle of the rear view
2. Attach camera stand bracket �� to
camera, and install so that the camera doesn't
touch the car.
the camera stand. (Fig. 3-2)
• When sticking to a glass surface, stick it on in a
3. Attach the rear view camera to cam-
position that assures the camera doesn't touch the
era stand bracket ��. (Fig. 3-3)
rear window.
• Install so that it does not obstruct the rear field of
4. Attach the camera stand removed in
view.
step 2 to the rear view camera with
• Install so that it does not protrude from the side of
the mounting screws. (Fig. 8)
the car.
The rear view camera has a mark indicating
• Do not perform installation in rain or fog.
the top of the camera.
• When humidity is high, dry the surface to which
the unit is to be attached before installing. Moisture
Attach the camera stand while being
on the attachment surface reduces adhesive strength
careful not to mistake the vertical
which may lead to the unit coming off.
orientation of the rear view camera.
① Top
• Install so that the rear view camera is aligned in
② Bottom
parallel with the direction of vehicle movement
③ Mark
(straight back from the vehicle). (Fig. 4)
• Install the rear view camera above the license plate.
5. Peel off the sheet on the back of they
If the installed location of the rear view camera is
camera stand and stick it on. (Fig. 9,
lower than the license plate, it will not be possible
Fig. 10)
to make image corrections causing distortion of the
image from the rear view camera.
Press the camera stand with your fingers to
• If the temperature of the attachment surface is
stick it to the installation surface. Touching
low, warm with a hair dryer of other means before
the adhesive surface or sticking the unit
installing to improve adhesive strength.
on a second time reduces adhesive power
• Do not attach the camera stand to areas on the car
which may result in the unit coming off.
body treated with fluorocarbon resin, or glass. This
① Camera stand
may result in the rear view camera falling off.
② When sticking to the center
• During the 24-hour period after installing:
③ When attaching using camera stand bracket
– Do not apply water to the unit.
�� (attaching while rotating by 90°)
– Do not expose the unit to rain.
6. Adjust the angle so that the bumper
– Do not subject the camera to unnecessary force.
or rear edge of the car is displayed
• Thoroughly clean where tape is used for sticking
on the unit.
at the bottom of the TV screen.
1. Clean the surface to which the rear
(Fig. 11, Fig. 12-2, Fig. 12-3, Fig. 13)
① Angle of view
view camera is to be installed.
Horizontal: 135°
(Fig. 5)
② Angle of view
Use a cloth or other item to wipe oil, wax,
Vertical: 100°
③ Bumper or rear edge of car
dust and any other dirt from the installation
surface.
Note:
2. Remove the rear view camera from
• The angle shown varies according to the camera
the camera stand. (Fig. 6)
specifications. The actual angle is narrower as a
result of image processing.
Remove the mounting screws with the
• The position and angle of the image from the
hexagon wrench provided.
rear view camera can still be adjusted using the
① Top
② Rear view camera
initial setup even if the bumper or rear edge of
③ Bottom
the car is not displayed on the bottom of the TV
④ Installation screw
screen. Refer to "First Time Setup" in the Owner's
⑤ Camera stand
Manual for details.
7. Attach the image processing unit
3. Align the camera stand with the
power supply. (Fig. 14)
installation surface. (Fig. 7)
Affix the Velcro tape (hard type) to the
Adjust the camera stand so that there is no
bottom of the image processing unit power
space between it and the installation surface.
① Turn
supply, and affix the Velcro tape (soft type)
② Twist
to the mounting location.
③ Camera stand
① Image processing unit power supply
② Velcro tape (hard type)
③ Velcro tape (soft type)
<ENGLISH>
• You can use Velcro tape (hard type) to attach
directly to a carpet, but do not use the soft type.
• Install the image processing unit power sup-
ply close enough for the rear view camera
cable to reach.
8. Attach the button unit (Fig. 15).
Affix the double-sided tape (square) to
the backside of the button unit. Next press
the unit onto the location where it will
be mounted. Affix the metal clamp to the
location where the cord is to be and then
secure the cord with the clamp.
① Double-sided tape (square)
② Button unit
③ Metal clamp
Instalación
<ESPANÕL>
Piezas suministradas
3. Fije la cámara de vista posterior a la
ménsula del soporte de la cámara ��.
�� Cámara de vista posterior × 1
(Fig. 3-3)
�� Cable de suministro de energía RCA × 1
�� Fuente de energía de la unidad de procesa-
4. Fije el soporte de la cámara y la
miento de imagen × 1
cámara de vista posterior. (Fig. 3-4)
�� Unidad de botones × 1
Encamine los cables como se muestra en la
�� Llave hexagonal × 1
�� Cinta Velcro (tipo blanda) × 1
figura de modo que no queden enredados.
�� Cinta Velcro (tipo dura) × 1
Fije el soporte de la cámara teniendo
�� Abrazadera metálica × 5
cuidado en no invertir la orientación
�� Abrazadera plástica × 10
vertical de la cámara de vista superior.
�� Almohadilla impermeable × 1
(Fig. 8)
�� Cinta de doble cara (rectangular) × 1
�� Cinta de doble cara (cuadrada) × 1
Procedimiento de instalación
�� Ménsula del soporte de la cámara �� × 1
Ejemplo de instalación (Fig. 1)
Nota:
• Antes de la instalación final de la unidad, conecte
① Superficie de vidrio
el cableado temporalmente y confirme que las
② Asegúrese de que no toque el limpiador
conexiones son correctas y que el sistema trabaja
normalmente.
③ Instale en la pieza central
• Utilice solamente las partes incluídas con la unidad
para asegurar una instalación adecuada. El uso de
Nota:
partes no autorizadas puede ocasionar fallas de
• Todavía se puede ajustar la posición y el ángulo de la
funcionamiento.
imagen desde la cámara de vista posterior utilizando
• Si la instalación requiere del taladrado de orificios u
la configuración inicial aunque la cámara no esté
otras modificaciones del vehículo, consulte con su
instalada en el centro del vehículo. Para los detalles,
agente o concesionario más cercano a su domicilio.
consulte la sección "Configuración por primera vez".
• Instale la unidad en donde no interfiera con el
Cambio de la orientación de la instalación
conductor y no pueda lesionar al pasajero en caso
de una parada repentina, tal como una frenada de
del soporte de la cámara (Fig. 12-1)
emergencia.
• Cuando monte esta unidad, cerciórese que ninguno
Se puede instalar el soporte de la cámara de
de los cables queda aprisionado entre esta unidad y
varias formas, cambiando la dirección en
accesorios o partes metálicas circundantes.
• Para prevenir descargas eléctricas, no instale la fuente
la cual se fija la ménsula del soporte de la
de energía de la unidad de procesamiento de imagen
cámara ��, o fijando la ménsula del soporte
en lugares donde pueda entrar en contacto con
de la cámara ��. Cambie de acuerdo con a
líquidos.
la forma de su coche o sitio de instalación.
• No monte esta unidad cerca de la salida del calefactor,
en donde podría ser afectado por el calor o cerca
1. Utilice la llave hexagonal para sacar
de las puertas, en donde la lluvia podría salpicar
los tornillos que fijan las ménsulas ��
sobre la misma. (Para evitar el riego de fallos de
y �� del soporte de la cámara. (Fig. 2)
funcionamiento producidos por las altas temperaturas,
evite la instalación en los lugares arriba.)
2. Cambie la dirección de la ménsula
• Antes de taladrar cualquier orificio de montaje
de instalación ��. (Fig. 3-1)
siempre compruebe lo que hay detrás en donde
desea taladrar los orificios. No taladre en la línea
3. Vuelva a fijar con los tornillos.
de combustible, cableado eléctrico u otras partes
importantes.
Instalación utilizando la ménsula del
• Si esta unidad es instalada en el compartimiento de
soporte de la cámara �� (Fig. 12-4)
pasajeros, fíjela seguramente de modo que no se
desprenda mientras el automóvil se encuentra en
1. Utilice la llave hexagonal para sacar
movimiento, y pueda ocasionar lesiones o accidentes.
los tornillos que fijan las ménsulas ��
• Si esta unidad se instale bajo un asiento delantero,
cerciórese de que no obstruye el movimiento
y �� del soporte de la cámara. (Fig. 2)
del asiento. Pase todos los cables y conductores
cuidadosamente a través de los mecanismo
2. Fije la ménsula del soporte de la
deslizantes, de modo que no queden aprisionados
cámara �� al soporte de la cámara.
o atrapados en el mecanismo y ocasionen un corto
circuito.
(Fig. 3-2)

Advertisement

loading

  Related Manuals for Pioneer ND-BC20PA

  Related Content for Pioneer ND-BC20PA
