INSTALLATION

4
4.1 IN CASE OF A STANDBY OF THE MACHINE (STANDBY = 2 MONTHS):
The first thing to do is to test your machine in a lab.
If the machine stop ruming for a long time, you could have scale in some places.
More precisely in small area like the spray nozzle.
4.2 PROTECTIONS
It is necessary to place before the machine:
o A water shutoff valve.
o An electrical protection standard, suitable for voltage and power consumption.
4.3 WATER SUPPLY
Recommended operating pressure from 1.5 MPa to 6 MPa
Water connection pin 3/8"
The water supply pipes must resist to 145 Psi / 10 MPa
4.4 DRAIN
Sans pression.
Spigot at the outlet of the machine and a pipe is supplied with the machine
Ensure a connection that causes no risk of fluid return, and ensure good drainage:
4.5 SUPPLYING VOLTAGE
To be specify when ordering :
Or :
SACOME, CONFIDENTIAL Document,
The drain pipe must be located lower than the machine.
Do not create a bend in the exhaust tube.
Edition 05/2014 - X-ONE - page 5
it is forbidden to duplicate or communicate this document without previous authorization.
230V – 50/60Hz Monofase
400V – 50/60Hz Trifase
