RED COMPACT 35 Easy Clean Installation Manual page 22

3-DRAWINGS AND TECHNICAL CHARACTERISTICS
TECHNICAL CHARACTERISTICS
Product class (EN 303-5/2012)
Rated thermal capacity of the firebox
Nominal output power:
Minimum output power
Efficiency at Max
Efficiency at Min
Temperature of exhaust smoke at Max
Temperature of exhaust smoke at Min
Max configurable temperature
Max operating temperature
Particles/OGC/Nox (10%O
2
CO at 10% O at Min and at Max
2
CO at Min and at Max
2
Recommended draught at Max power
Recommended draught at Min power
Smoke mass
Hopper capacity
Type of pellet fuel
Pellet hourly consumption
Autonomy
Heatable volume m
3
Water content
Max operating temperature
Combustion air inlet
Smoke outlet
Air intlet
Rated electrical power (EN 60335-1)
Supply voltage and frequency
Net weight
Weight with packaging
* Data that may vary depending on the type of pellets used.
** Volume that can be heated, according to the power requirement in m
20 20
)
COMPACT 35 EASY CLEAN
5
34,5 kW (29670 kcal/h)
32,0 kW (27520 kcal/h)
8,1 kW (6966 kcal/h)
92,8%
90,0%
140°C
60,5°C
80°C
95°C
23 mg/Nm - 2 mg/Nm
3
0,014 - 0,005%
5,6 - 10,3%
0,10 mbar - 10 Pa
0,05 mbar - 5 Pa
21,5 g/sec
146 litri
Pellet diameter 6-8 mm and size 3/40 mm
Min ~ 1,3 kg/h* - Max ~ 6,7 kg/h*
Al min ~ 80 h* - Al max ~ 16 h*
688/40 - 786/35 - 917/30**
30 litri
3 bar - 300 kPa
0 80 mm
0 100 mm
100 cm
2
190 W (Max 440 W)
230 Volt / 50 Hz
320 kg
340 kg
(respectively 40-35-30 Kcal/h per m
3
- 196 mg/Nm
3 3
)
3
