- Page 1 I n s t r u c t i o n M a n u a l Pass onto user to read and keep for reference Hydro-Pneumatic Power Tool 07391...
- Page 2 AVDEL policy is one of continuous development. Specifications shown in this document may be subject to changes which may be introduced after publication. For the latest information always consult Avdel. S P E C I F I C A T I O N S F O R 0 7 3 9 1 T O O L ■...
-
Page 3: Table Of Contents
O N T E N T S S A F E T Y General Specific to 07391 Tool I N T E N T O F U S E General Tool Dimensions / Selection P U T T I N G I N T O S E R V I C E... -
Page 4: General
RECOMMENDED AND SUPPLIED BY AVDEL. ANY MODIFICATION UNDERTAKEN BY THE CUSTOMER TO THE TOOL/MACHINE, NOSE ASSEMBLIES, ACCESSORIES OR ANY EQUIPMENT SUPPLIED BY AVDEL OR THEIR REPRESENTATIVES, SHALL BE THE CUSTOMER'S ENTIRE RESPONSIBILITY. AVDEL WILL BE PLEASED TO ADVISE UPON ANY PROPOSED MODIFICATION. -
Page 5: Specific To 07391 Tool
In addition to the general safety rules opposite, the following specific safety points must also be observed: THE OPERATING PRESSURE SHALL NOT EXCEED 7 BAR - 100 LBF/IN DO NOT OPERATE THE TOOL WITHOUT FULL NOSE EQUIPMENT IN PLACE. CARE SHALL BE TAKEN TO ENSURE THAT SPENT STEMS ARE NOT ALLOWED TO CREATE A HAZARD. -
Page 6: General
N T E N T O F U S E The hydro-pneumatic 07391 tool is designed to place Avdel breakstem rivets at high speed making it ideal for batch or flow-line assembly in a wide variety of applications throughout all industries. - Page 7 07391 NOSE TIP SELECTION FASTENER NOSE (see drawing opposite for A & B) NAME & HEAD Ø MATERIAL NOSE TIP part Nº A (mm) B (mm) A (in) B (in) " Al. Alloy 07381-04501 12.7 .500 .130 AVEX Snap head...
-
Page 8: Air Supply
U T T I N G I N T O S E R V I C E A I R S U P P L Y All tools are operated with compressed air at an optimum pressure of 5.5 bar. We recommend the use of pressure regulators and automatic oiling/filtering systems on the main air supply. -
Page 9: Accessories
A C C E S S O R I E S Two different accessories are available to make the connection to your air supply: Double Male Connector Hose Connector part nº 07005-00041 part nº 07005-00276 TO FIT 6.4 mm (1/4”) BORE PIPE 1/4”... -
Page 10: Fitting/Servicing/Components
O S E A S S E M B L I E S There are two nose assemblies available for the 07391 tool with only the nose tip varying. See nose assembly component table below for part numbers. If you have purchased a complete tool, it will be fitted with one of these two nose assemblies. -
Page 11: Regular Servicing - Service Kit
E R V I C I N G T H E T O O L Regular servicing should be carried out and a comprehensive inspection performed annually or every 500000 cycles, whichever is sooner. I M P O R T A N T The employer is responsible for ensuring that tool maintenance instructions are given to the appropriate personnel. -
Page 12: Maintenance
For all servicing we recommend the use of the service kit below (part number 07900-03400) supplied in its own plastic case. SERVICE KIT SERVICE KIT (Continued) ITEM PART Nº DESCRIPTION Nº OFF ITEM PART Nº DESCRIPTION Nº OFF 07900-00001 SPRING COMPRESSOR 07900-00087 SOCKET ASSEMBLY 07900-00002... - Page 13 I M P O R T A N T Check the tool against daily and weekly servicing. Priming is ALWAYS necessary after the tool has been dismantled and prior to operating. * refers to items included in the Avdel service kit. For complete list see page 10.
-
Page 14: General Assembly & Parts List
GENERAL ASSEMBLY OF BASE TOOL 07391-00200 SECTION A - A... - Page 15 07391-00200 PARTS LIST ITEM PART Nº DESCRIPTION QTY SPARES ITEM PART Nº DESCRIPTION QTY SPARES 07391-00300 HANDLE ASSEMBLY ( 2 - 17 ) 07003-00038 AIR PISTON CUP ● 07391-00302 PLUG 07340-00502 WASHER ● ● 07004-00019 CIRCLIP 07002-00011 ● ● 07003-00033...
-
Page 16: Priming Oil Details
R I M I N G Priming is ALWAYS necessary after the tool has been dismantled and prior to operating. It may also be necessary to restore the full stroke after considerable use, when the stroke may be reduced and rivets are not fully placed by one operation of the trigger. O I L D E T A I L S The recommended oil for priming is Hyspin VG32 available in 0.5l (part number 07992-00025) or one gallon containers (part number... -
Page 17: Priming Procedure
Care MUST be taken at all times, to ensure that no foreign matter enters the tool, or serious damage may result. The use of a priming kit is necessary to implement the priming procedure. The part number to be used with the 07391 tool is 7900-03401. -
Page 18: Fault Diagnosis Table
A U L T D I A G N O S I S F A U L T D I A G N O S I S T A B L E SYMPTOM POSSIBLE CAUSE REMEDY ➝ Low air pressure. ➝... - Page 19 Engineered Fastening and Assembly Systems Declaration of Conformity Avdel UK Limited, Mundells, Welwyn Garden City, Herts, AL7 1EZ declare under our sole responsibility that the product type 07391 Serial Nº ..........to which this declaration relates is in conformity with the following standards or other formative documents...
- Page 20 Tel: +82 31 798 6340 Email: info@acument.com.au Email: AvdelDeutschland@acument.com Fax: +82 31 798 6342 Email: info@acumentkorea.com CANADA ITALY Avdel Canada, a Division of Acument Avdel Italia S.r.l. SPAIN Canada Limited Viale Lombardia 51/53 Avdel Spain S.A. 87 Disco Road 20047 Brugherio (MI)
