**Connect a Monitor to the Camera: (This only apply for FB-500A /(W)FB-300N /FB-H200N series)**
Use an A/V Cable to view the camera's video feed and manually adjust the lens iris, focus, and zoom to get
the desired image quality.
1.
Connect the A/V Cable to the monitor.
【FB-500/300/200 Series】
Step 3.Camera Connection
i)
Basic Connection (Without PoE)
1.
To attach external devices, such as sensors and alarms, connect them to the extension I/O
terminal block.
2.
Connect the camera to a switch using an Ethernet cable.
3.
Connect the supplied power cable to the camera and plug it into a power outlet.
FB-500/300/200 Series
【(W)FB-300Np V5 & FB-H Series】
(W)FB-300Np V5 & FB-H Series
6
