MiniScan MS-120X and MS-220X Integration Guide...
Page 3
MiniScan MS-120X and MS-220X Integration Guide 72-63538-02 Revision A November 2003...
Page 4
The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on a licensed basis. Symbol grants to the user a non-transferable and non-exclusive license to use each software or firmware program delivered hereunder (licensed program).
About This Manual The MiniScan MS-120X and MS-220X Integration Guide provides general instructions for mounting, setting up, and programming the MiniScan MS-120X and MS-220X. Note: It is recommended that an opto-mechanical engineer perform an opto-mechanical analysis prior to integration. Chapter Descriptions Topics covered in this guide are as follows: •...
MS-120X and MS-220X Integration Guide • Chapter 9, Parameter Menus describes the programmable parameters, provides bar codes for programming, and hexadecimal equivalents for host download programming. • Chapter 10, RS-232 Interface (MS-1207/MS-2207 Only) describes how to set up the scanner for RS-232 operation. •...
Call the Support Center from a phone near the scanning equipment so that the service person can try to talk you through your problem. If the equipment is found to be working properly and the problem is symbol readability, the Support Center will request samples of your bar codes for analysis at our plant.
Page 18
MS-120X and MS-220X Integration Guide Australia Austria/Österreich Symbol Technologies Pty. Ltd. Symbol Technologies Austria GmbH 432 St. Kilda Road Prinz-Eugen Strasse 70 / 2.Haus Melbourne, Victoria 3004 1040 Vienna, Austria 1-800-672-906 (Inside Australia) 01-5055794-0 (Inside Austria) +61-3-9866-6044 (Outside Australia) +43-1-5055794-0 (Outside Austria)
Page 19
Symbol Technologies Norway Postbus 24 7050 AA Hoybratenveien 35 C Varsseveld, Netherlands N-1055 OSLO, Norway 315-271700 (Inside Netherlands) +31-315-271700 (Outside Netherlands) Symbol’s repair depot and shipping address: Symbol Technologies Norway Enebakkveien 123 N-0680 OSLO, Norway +47 2232 4375 South Africa Spain/España Symbol Technologies Africa Inc.
Page 20
Switchboard: 08 445 29 00 (domestic) Call Center: +46 8 445 29 29 (international) Support E-Mail: Sweden.Support@se.symbol.com If you purchased your Symbol product from a Symbol Business Partner, contact that Business Partner for service. For the latest version of this guide go to:http://www.symbol.com/manuals. xviii...
Chapter 1 Introduction Caution Use of controls, adjustments or procedures other than those specified here can result in hazardous laser light exposure. Overview The MiniScan family of industrial fixed-mount scanners are specifically designed for stand- alone applications, and OEM applications such as kiosks.
Page 22
MS-120X and MS-220X Integration Guide Figure 1-1. MiniScan Family of Scanners MS-120X and MS-220X scanners provide easy and flexible integration of bar code scanning into a host device, and include the following models: • The MS-1207WA has a 60 scan angle that accommodates wide 1D bar codes within close range, including RSS codes.
Introduction MiniScan MS-120X and MS-220X Features • Stand-alone or OEM applications • Quick and easy integration for OEM devices • Excellent scanning performance on all types of bar codes • Rugged IP54 sealed housing with integrated beeper • RS-232 or multi-interface (USB, Synapse, TTL RS-232) •...
The filtered signal is digitized into a Digitized Barcode Pattern (DBP). Timing information is analyzed by the decoder micro-controller to decode and transmit the data contained in the bar code. Data transmission is carried out using Symbol's proprietary SSI Interface.
Page 25
Introduction Interface Board - The interface board adapts the scan engine's interface into usable signals and data for the intended host. It also contains a beeper and red/green LED for audio/visual feedback, and provides for an external trigger and external beeper. •...
MS-120X and MS-220X Integration Guide Scanning Patterns The MiniScan generates different scanning patterns based on the software command received at the interface. The patterns are Smart Raster and Single Scan Line (standard and high density). The raster pattern can be used to read 1D bar codes and PDF symbols. Smart Raster Scan Pattern (MS-220X only) The MS-220X can create a single line which opens vertically to read PDF417 symbols using the Smart Raster feature.
Introduction Single Scan Line Standard Single Scan Line (MS-120X versions) The MS-120X scanner emits a single scan line to quickly decode quality 1D bar codes. Figure 1-4. Single Scan Line Scan Pattern High Density Single Scan Line (MS-220X versions) The High Density single scan line appears as a "mini" raster and scans multiple areas of 1D codes to swiftly and accurately capture data on poorly printed and damaged bar codes.
If three (MS-220X only) beeps occur during normal operation, it is due to a reset and any work in progress is lost. If this occurs often, contact the Symbol Support Center. Parameter Menu Scanning 2 Beeps - short high tone Correct entry scanned or correct menu sequence performed.
Unpacking Remove the MiniScan from its packing and inspect for damage. If the scanner is damaged, call the Symbol Support Center at the telephone number listed on page KEEP THE PACKING. It is the approved shipping container and should be used if the...
MS-120X and MS-220X Integration Guide Mounting There are three mounting holes (threaded inserts) on the bottom of the chassis. Figure 2-1 provides mounting dimensions for the MiniScan scanner housing. For a mounting template, see Mounting Template on page 15-1. Note: Use only non-magnetic M3x.5 screws with a maximum length of 3.6M to mount the MiniScan scanner chassis.
Installation Mounting the Scanner on the Stand (optional) To mount the scanner on the optional stand: 1. Place the bottom of the scanner on the stand’s scanner mount, aligning the scanner’s center threaded insert (beneath the scan window) with the center mounting hole on the front of the stand.
MS-120X and MS-220X Integration Guide Note: efore tightening the wingnut under the base, ensure that the flat areas on the flexible neck fit securely in the grooves in the base. Mounting the Stand (optional) You can attach the base of the scanner’s stand to a flat surface using two screws or double- sided tape (not provided).
Installation Connecting the MiniScan To connect the MiniScan to the host, connect the scanner cables in the order shown in Figure 2-4. To Host Beeper (Optional) Trigger Jack (Optional) Figure 2-5 Trigger or Photo Sensor (Optional) Figure 2-4. Typical Connection Diagram...
Page 34
MS-120X and MS-220X Integration Guide Male jack shown for reference Insertion Direction 1 - Ground (Sleeve) Note: Due to many variations of 1 - Ground (Sleeve) 2 - Vcc (Middle Contact) jack and socket styles, identify 2 - Battery (Middle Contact) 3 - Trigger (Tip) terminals as shown before 3 - Trigger (Tip)
Installation Mechanical Drawings MS-1207WA Notes: Unless otherwise specified: • Dimensions are in inches, dimensions in [ ] are mm. • User mounting tolerances are not included. Figure 2-6. MS-1207WA Mechanical Drawing...
Page 36
MS-120X and MS-220X Integration Guide Notes: Unless otherwise specified: • Dimensions are in inches, dimensions in [ ] are mm. • User mounting tolerances are not included. Figure 2-7. MS-1207WA Mechanical Drawing...
Installation MS-1204FZY, MS-1207FZY Notes: Unless otherwise specified: • Dimensions are in inches, dimensions in [ ] are mm. • User mounting tolerances are not included. Figure 2-8. MS-1204FZY/MS-1207FZY Mechanical Drawing...
Page 38
MS-120X and MS-220X Integration Guide Notes: Unless otherwise specified: • Dimensions are in inches, dimensions in [ ] are mm. • User mounting tolerances are not included. Figure 2-9. MS-1204FZY/MS-1207FZY Mechanical Drawing 2-10...
Installation MS-2204, MS-2204VHD, MS-2207 Notes: Unless otherwise specified: • Dimensions are in inches, dimensions in [ ] are mm. • User mounting tolerances are not included. Figure 2-10. MS-2204/MS-2204VHD/MS-2207 Mechanical Drawing 2-11...
Page 40
MS-120X and MS-220X Integration Guide Notes: Unless otherwise specified: • Dimensions are in inches, dimensions in [ ] are mm. • User mounting tolerances are not included. Figure 2-11. MS-2204/MS-2204VHD/MS-2207 Mechanical Drawing 2-12...
The MiniScan can be mounted to read symbols that are automatically presented, or that are presented in a pre-determined location. In these applications, MinScan positioning with respect to the symbol is critical. Failure to properly position the MiniScan can result in unsatisfactory scanning performance. A thermal analysis is also recommended.
Page 42
MS-120X and MS-220X Integration Guide Calculating The Usable Scan Length Method Calculate usable scan length as follows (see Figure 2-12 on page 2-15): L = 2 x (D+d+B) x Tan (A/2) Table 2-1. Calculation Constants Constants Notes MS-120XFZY 1.17 42° Default Mode MS-120XFZY 1.17...
Page 43
Figure 2-12. Usable Scan Length Diagram Testing The Usable Scan Length Method Due to the variety of symbol sizes, densities, print quality, etc., there is no simple way to calculate the ideal symbol distance. To optimize performance, use the Testing The Usable Scan Length positioning method: 1.
MS-120X and MS-220X Integration Guide 4. Center the symbol (left to right) in the scan line whenever possible. 5. Position the symbol so that the scan line is as near as possible to perpendicular to the bars and spaces in the symbol.
Page 45
Installation Scan Beam Figure 2-13. Symbol Perpendicular To Conveyor Movement Symbol is Parallel to Conveyor Movement With the symbol bars parallel to the conveyor belt direction (Ladder presentation) the relationship is: V = (R x H) / N where: V = Velocity of the conveyor (inches/second)
Page 46
MS-120X and MS-220X Integration Guide Scan Beam Figure 2-14. Symbol Parallel To Conveyor Movement 2-18...
Installation Accessories The following accessories are available for the MiniScan scanner, and can be found in Symbol’s Solution Builder (ordering guide). • For power connection 110V power supply, US, p/n 50-14000-008 220V power supply, Europe, p/n 50-14000-009 100V power supply, Asia, p/n 50-14000-010...
• Simple Serial Interface documentation. With over 70 programmable parameters, the MS-1204 and MS-2204 can be configured by scanning bar code menus, or through the serial interface using Symbol’s Simple Serial Interface protocol. ® For Windows , DOS, and embedded system environments, the CD enables the user to take full advantage of the scanner’s features and obtain maximum performance.
SYN_CLK Synapse Mode: Synapse Clock line. Signal used as a clock by a Symbol Synapse host. Pin is shorted to RTS/SYN_DAT in USB cables to allow auto-detection of USB mode via signal loopback. Ground Power supply ground input and signal ground reference.
Page 51
CTS line. Optionally used by the scanner to signal another device that data is available to send. Synapse Mode: Synapse Data line. Used to transmit data to and from a Symbol Synapse host. Beeper/ During normal operation this signal functions as an external beeper Download drive line.
MS-120X and MS-220X Integration Guide MS-1207WA Technical Specifications Table 3-2 provides the MS-1207WA technical specifications. Table 3-2. MS-1207WA Technical Specifications @ 23°C Item Description Power Requirements Input Voltage 5.0 VDC ± 10% Scanning Current 110 mA ± 30mA Standby Current 40 mA ±...
Page 53
MS-1207WA Specifications Table 3-2. MS-1207WA Technical Specifications @ 23°C (Continued) Item Description Operating Temperature 32° to 104°F (0° to 40°C) Storage Temperature -40° to 140°F (-40° to 60°C) Humidity 5% to 95% non-condensing Height 1.60 in. (4.06 cm) Width 2.28 in. (5.79 cm) Depth 2.94 in.
Page 54
MS-120X and MS-220X Integration Guide Skew Pitch + 65° from normal + 55° from normal Pitch Angle Skew Angle Scan Beam Scan Beam Roll + 20° from normal Roll Angle Note: Tolerances are reduced at extreme ends of the working range. Scan Beam Figure 3-2.
The minimum element width (or “symbol density”) is the width in mils of the narrowest element (bar or space) in the symbol. The maximum usable length of a symbol at any given range is shown below.
3. Working range specifications at ambient temperature 23 °C. Usable Scan Length The decode zone is a function of various symbol characteristics including density, print contrast, wide-to-narrow ratio, and edge acuity. Consider width of decode zone at any given distance when designing a system.
Multi-interface Miniscan Plus products fall into the TTL RS-232 device category. All standard RS-232 cables available from Symbol for the Miniscan Plus family measure six feet or less, and should not present a problem. If a particular host does not support TTL levels, a separate conversion cable is available (25-62186-xx) which contains electronics to adapt the TTL levels of a multi-interface Miniscan Plus into standard RS-232 levels.
Page 58
MS-120X and MS-220X Integration Guide 3-10...
Chapter 4 MS-120XFZY Specifications Overview This chapter provides the technical specifications for the MS-120XFZY scanner. Scan Angle Selection The MS-120XFZY scanner supports two pre-set scan angles: 30° and 42°. Selecting Scan Angle via SSI To use SSI to select the scan angle (see Simple Serial Interface (SSI) (MS-1204/MS-2204 Only) on page 14-1), issue the SSI PARAM_SEND command with the...
MS-120X and MS-220X Integration Guide MS-1204FZY Electrical Interface Figure 4-1. MiniScan Connector lists the pin functions of the MiniScan MS-1204FZY interface. Table 4-1 Table 4-1. MS-1204FZY Electrical Interface Pin Name Type* Function Trigger Signals scanner to begin scanning session. Serial data transmit output. Drives the serial data receive input on the device communicating with the scanner.
1.5k Ohm resistor to begin USB enumeration. In this mode it is a differential bi-directional signal. SYN_CLK Synapse Mode: Synapse Clock line. Used as a clock by a Symbol Synapse host. Pin is shorted to RTS/SYN_DAT in USB cables to allow for auto-detection of USB mode via signal loopback.
Multi-interface Miniscan Plus products fall into the TTL RS-232 device category. All standard RS-232 cables available from Symbol for the Miniscan Plus family measure six feet or less, and should not present a problem. If a particular host does not support TTL levels, a separate conversion cable is available (25-62186-xx) which contains electronics to adapt the TTL levels of a multi-interface Miniscan Plus into standard RS-232 levels.
MS-120XFZY Specifications • Frequent scanner resets • Scanner occasionally loses power (due to host initiated shutdown) • Occasional host lockups. Because multi-interface Miniscan Plus products are often exposed to these environments due to the nature of scanner placement, they have been safeguarded as much as possible to prevent physical damage.
Page 64
MS-120X and MS-220X Integration Guide Table 4-3. MS-120XFZY Technical Specifications @ 23°C (Continued) Item Description Ambient Light Immunity Sunlight 8,000 ft. candles (86,112 lux) Artificial Light 450 ft. candles (4,844 lux) Drop Multiple 30” drops Vibration Unpowered scanner withstands a random vibration along each of the X, Y and Z axes for a period of one hour per axis, defined as follows: 20 to 80 Hz...
Page 65
MS-120XFZY Specifications Skew Pitch + 50° from normal + 65° from normal Pitch Angle Skew Angle Scan Beam Scan Beam Roll + 20° from normal Roll Angle Note: Tolerances are reduced at extreme ends of the working range. Scan Beam Figure 4-3.
The minimum element width (or “symbol density”) is the width in mils of the narrowest element (bar or space) in the symbol. The maximum usable length of a symbol at any given range is shown below. To calculate this distance, see...
Page 67
MS-120XFZY Specifications Table 4-4. MS-120XFZY Decode Distances (42 Scan Angle) Symbol Density/ Typical Working Guaranteed Working Bar Code Symbol p/n / Ranges Ranges Content/ Bar Code Type/ Contrast Near Near W-N Ratio 5.0 mil ABCDEFGH 3.25 in. 7.00 in. 4.75 in.
MS-120X and MS-220X Integration Guide Usable Scan Length The decode zone is a function of various symbol characteristics including density, print contrast, wide-to-narrow ratio, and edge accuracy. Consider the width of the scan line at any given distance when designing a system.
MS-120X and MS-220X Integration Guide MS-2204 Electrical Interface Figure 5-1. MiniScan Connector lists the pin functions of the MiniScan MS-2204 interface. Table 5-1 Table 5-1. MS-2204 Electrical Interface Pin Name Type* Function Trigger Signals scanner to begin scanning session. Serial data transmit output. Drives the serial data receive input on the device communicating with the scanner.
SYN_CLK Synapse Mode: Synapse Clock line. Signal used as a clock by a Symbol Synapse host. Pin is shorted to RTS/SYN_DAT in USB cables to allow autodetection of USB mode via signal loopback. Ground Power supply ground input and signal ground reference.
Multi-interface Miniscan Plus products fall into the TTL RS-232 device category. All standard RS-232 cables available from Symbol for the Miniscan Plus family measure six feet or less, and should not present a problem. If a particular host does not support TTL levels, a separate conversion cable is available (25-62186-xx) which contains electronics to adapt the TTL levels of a multi-interface Miniscan Plus into standard RS-232 levels.
Page 76
MS-120X and MS-220X Integration Guide Skew Pitch + 49° from normal + 55° from normal Pitch Angle Skew Angle Scan Beam Scan Beam Roll + 20° from normal Roll Angle Note: Tolerances are reduced at extreme ends of the working range. Scan Beam Figure 5-3.
Table 5-5 on page 5-12 list the typical and guaranteed distances for selected bar code densities. The minimum element width (or “symbol density”) is the width in mils of the narrowest element (bar or space) in the symbol. The maximum usable length of a symbol at any given range is shown below.
MS-120X and MS-220X Integration Guide MS-220X 1D Decode Distances Table 5-4. MS-220X 1D Decode Distances Typical Working Guaranteed Working Symbol Density/ Bar Code Content/ Ranges Ranges Symbol p/n / Contrast Bar Code Type Near Near 6.0 mil 2.0 in. 5.25 in. 2.75 in.
MS-220X Specifications MS-220X 2D Decode Zone Note: Typical performance at 68˚F (20˚C) on high quality symbols in normal room light. Y-module dimension = 3X. Vcc = 5V 12.7 6.35 MS-220X 6.35 6.6 mil 12.7 10 mil Minimum Element Width, 35% 10 mil Minimum Element Width, 80% 15 mil Minimum Element Width 15.0...
Note: Not optimized for omnidirectional mode. Usable Scan Length The decode zone is a function of various symbol characteristics including density, print contrast, wide-to-narrow ratio, and edge acuity. Consider width of decode zone at any given distance when designing a system.
MS-120X and MS-220X Integration Guide Electrical Interface Figure 6-1. MiniScan Connector lists the pin functions of the MS-2204VHD. Table 6-1 Table 6-1. MS-2204VHD Electrical Interface Pin Name Type* Function Trigger Signals scanner to begin scanning session. Serial data transmit output. Drives the serial data receive input on the device communicating with the scanner.
640 scans/sec. Frame Rate 24 frames/sec. 12 Hz ±1 Hz (vertical) Print Contrast Minimum 35% absolute dark/light reflectance differential Skew Tolerance ± 15 from plane parallel to symbol (see Figure 6-2 on page 6-5) Pitch Angle ± 30 from normal (see...
Page 84
MS-120X and MS-220X Integration Guide Table 6-2. MS-2204VHD Technical Specifications @ 23°C (Continued) Item Description Storage Temperature -40° to 158°F (-40° to 70°C) Humidity 5% to 95% non-condensing Drop Multiple 30” drops Vibration Unpowered scanner withstands a random vibration along each of the X, Y and Z axes for a period of one hour per axis, defined as follows: 20 to 80 Hz...
Page 85
MS-2204VHD Specifications Skew Pitch + 15° from normal Pitch + 30° from normal Angle Skew Angle Scan Beam Scan Beam Roll + 4° from normal Roll Angle Note: Tolerances are reduced at extreme ends of the working range. Scan Beam Figure 6-2.
Table 6-4 on page 6-9 list the typical and guaranteed distances for selected bar code densities. The minimum element width (or “symbol density”) is the width in mils of the narrowest element (bar or space) in the symbol. The maximum usable length of a symbol at any given range is shown below.
MS-2204VHD Specifications MS-2204VHD 1D Decode Distances Table 6-3. MS-2204VHD 1D Decode Distances Guaranteed Working Symbol Density/ Bar Code Typical Working Ranges Ranges Symbol p/n / Content/ Bar Code Type Contrast Near Near 4 mil STI4026 2.0 in. 3.4 in. 2.75 in.
MS-120X and MS-220X Integration Guide MS-2204VHD 2D Decode Zone Note: Typical performance at 68˚F (20˚C) on high quality symbols in normal room light. Y-module dimension = 3X. Vcc = 5V 6.35 1.25 3.18 MS-2204VHD 1.25 3.18 4.0 mil 3.00 1.90 6.35 6.6 mil 4.75...
Note: Not optimized for omnidirectional mode. Usable Scan Length The decode zone is a function of various symbol characteristics including density, print contrast, wide-to-narrow ratio, and edge acuity. Consider width of decode zone at any given distance when designing a system.
Page 90
MS-120X and MS-220X Integration Guide 6-10...
This chapter provides information on scanning and the various triggering options. Scanning Tips When scanning, make sure the symbol to be scanned is within the scanning range. See Calculating The Usable Scan Length Method on page 2-14. Align the bar code with the scan beam.
MS-120X and MS-220X Integration Guide Position at an Angle Do not position the scanner exactly perpendicular to the bar code. In this position, light can bounce back into the scanner's exit window and prevent a successful decode. Triggering Options Continuous (Default) The laser is enabled continuously and decode processing is continuously active.
Scanning Pulse Trigger The laser is enabled and decode processing begins when the trigger line is activated. Decode processing continues regardless of the trigger line until a good decode occurs, or until the Laser On Time expires. The laser is disabled once decode processing is complete. The next decode attempt will not occur until the trigger line is released and then reactivated.
Chapter 8 Maintenance and Troubleshooting Overview The chapter provides information on maintenance and troubleshooting. Maintenance Cleaning the exit window is the only maintenance required. Do not allow any abrasive material to touch the window. Clean the scan window with a damp cloth and, if necessary, a non-ammonia based detergent.
Page 96
MS-1207/MS-2207 scans briefly, decodes, and switches to continuous trigger mode. Note: If after performing these checks the symbol still does not scan, contact the distributor or call the Symbol Support Center at the telephone number listed on...
Chapter 9 Parameter Menus This chapter describes the programmable parameters, and provides bar codes for programming and hexadecimal equivalents for host download programming. Throughout the programming bar code menus, default values are indicated with asterisks North American, Standard USB Keyboard Indicates Default Feature/Option...
9-11. • Download data through the scanner’s serial port using Symbol’s Simple Serial Interface (SSI). This option is only available for MS-1204 and MS-2204 models. Hexadecimal parameter numbers are shown in this chapter below the parameter title, and options are shown in parenthesis beneath the accompanying bar codes.
Page 99
MS-2207: Omnidirectional Aiming Mode F0h 7Eh Disabled 9-18 Raster Height 9-20 Raster Expansion Rate 9-20 Time-out Between Same Symbol 0.6 sec 9-21 Time-out Between Different Symbols 0.0 sec 9-21 Beep After Good Decode Enable 9-22 Transmit “No Decode” Message Disable...
Page 100
MS-120X and MS-220X Integration Guide Table 9-1. Default Table (Continued) Parameter Page Parameter Default Number Number Linear Code Type Security Levels MS-120X: 1 9-25 MS-220X: 2 Bi-directional Redundancy Disable 9-27 UPC/EAN UPC-A Enable 9-28 UPC-E Enable 9-28 UPC-E1 Disable 9-30 EAN-8 Enable 9-31...
Page 101
Parameter Menus Table 9-1. Default Table (Continued) Parameter Page Parameter Default Number Number Convert UPC-E1 to A Disable 9-45 EAN-8 Zero Extend Disable 9-46 UPC/EAN Security Level 9-47 Linear UPC/EAN Decode Disable 9-49 Code 128 Code 128 Enable 9-50 UCC/EAN-128 Enable 9-51 ISBT 128...
Page 102
MS-120X and MS-220X Integration Guide Table 9-1. Default Table (Continued) Parameter Page Parameter Default Number Number Code 39 Full ASCII Conversion Disable 9-63 Code 39 Decode Performance Enable 9-64 Code 39 Decode Performance Level Level 3 9-65 Code 93 Code 93 Disable 9-66 Set Length(s) for Code 93...
Page 103
Parameter Menus Table 9-1. Default Table (Continued) Parameter Page Parameter Default Number Number Discrete 2 of 5 Discrete 2 of 5 Disable 9-80 Set Length(s) for D 2 of 5 1 Discrete Length: 12 9-81 Codabar Codabar Disable 9-83 Set Lengths for Codabar Length within Range: 9-84 05-55...
Parameter Menus Set Default Parameter Scan this bar code to return all parameters to the values listed in Table 9-1 on page 9-3. Set All Defaults 9-11...
MS-120X and MS-220X Integration Guide Scanning Options Beeper Volume Parameter # 8Ch To select a decode beep volume, scan the Low Volume, Medium Volume, or High Volume bar code. Low Volume Medium Volume *High Volume 9-12...
Parameter Menus Beeper Tone Parameter # 91h To select a decode beep frequency (tone), scan the appropriate bar code. Low Frequency (02h) Medium Frequency (01h) *High Frequency (00h) 9-13...
MS-120X and MS-220X Integration Guide Beeper Frequency Adjustment Parameter # F0h 91H This parameter adjusts the frequency of the high beeper tone from the nominal 2500 Hz to another frequency matching the resonances of the installation. It is programmable in 10 Hz increments from 1220 Hz to 3770 Hz.
Parameter Menus Laser On Time Parameter # 88h This parameter sets the maximum time decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds. To set a Laser On Time, scan the bar code below. Next scan two numeric bar codes beginning on page 9-144 that correspond to the desired on time.
MS-120X and MS-220X Integration Guide Power Mode Parameter # 80h This parameter determines whether or not power remains on after a decode attempt. In Low Power mode, the scanner enters into a low power consumption mode when possible, provided all WAKEUP signals are released. In Continuous On mode, power remains on after each decode attempt.
Parameter Menus Trigger Modes Parameter # 8Ah • Level - A trigger pull activates the laser and decode processing. The laser remains on and decode processing continues until a trigger release, a valid decode, or the Laser On Time-out is reached. •...
MS-120X and MS-220X Integration Guide Scanning Mode (MS-2204 and MS-2207 Only) Parameter # 8Dh Select one of the following scanning modes: • Smart Raster • Always Raster • Slab Only Raster • Programmable Raster • Omnidirectional (Cyclone) • Semi-Omnidirectional Note: If Omnidirectional is selected, disabling the following parameters is recommended: PDF417, MicroPDF417, RSS-Limited, CC-C, CC-AB, TLC-39 and Linear UPC.
Parameter Menus Aiming Mode Parameter # F0h 7Eh For handheld mode only, select an aiming dot to appear for a normal or extended period of time. *No Aiming Dot (00h) Aiming Dot Normal (200 ms) Timeout (01h) Aiming Dot Extended (400 ms) Timeout (02h) 9-19...
MS-120X and MS-220X Integration Guide Programmable Raster Height and Raster Expansion Speed (MS-2204 and MS-2207 Only) Parameter # E4h, E5h This parameter selects the laser pattern’s height and rate of expansion, and is only used when Programmable Raster or Always Raster is enabled. This parameter is intended for very specific applications, and is usually not necessary.
(different) bar code. This is used in Continuous mode to prevent the scanner from decoding when a different symbol appears in the scanner's field of view before the timeout period between decodes expires. This is programmable in 0.1 second increments from 0.0 to 9.9 seconds.
Scan this symbol to set the scanner to beep after a good decode. *Beep After Good Decode (01h) Scan this symbol to set the scanner not to beep after a good decode. The beeper still operates during parameter menu scanning and indicates error conditions. Do Not Beep After Good Decode...
Parameter Menus Transmit “No Read” Message Parameter # 5Eh Enable this option to transmit “NR” if a 1-D symbol does not decode, and “FR” if a 2-D symbol does not decode. Any enabled prefix or suffixes are appended around this message.
MS-120X and MS-220X Integration Guide Parameter Scanning Parameter # ECh To disable the decoding of parameter bar codes, scan the bar code below. The Set Defaults parameter bar code can still be decoded. To enable decoding of parameter bar codes, either scan *Enable Parameter Scanning, Set All Defaults...
Parameter Menus Linear Code Type Security Level Parameter # 4Eh Note: Does not apply to Code 128. The MS-120X and MS-220X offer four levels of decode security for linear code types (e.g., Code 39, Interleaved 2 of 5). Select higher security levels for decreasing levels of bar code quality.
MS-120X and MS-220X Integration Guide Linear Security Level 3 Code types other than the following must be successfully read twice before being decoded. The following codes must be read three times: Code Type Length MSI Plessey 4 or less D 2 of 5 8 or less I 2 of 5 8 or less...
Parameter Menus Bi-directional Redundancy Parameter # 43h This parameter is only valid when a Linear Code Type Security Level is enabled (see page 9-25). When this parameter is enabled, a bar code must be successfully scanned in both directions (forward and reverse) before being decoded. Enable Bi-directional Redundancy (01h) *Disable Bi-directional Redundancy...
MS-120X and MS-220X Integration Guide UPC/EAN Coupon Code Parameter # 55h When enabled, this parameter decodes UPC-A bar codes starting with digit ‘5’, EAN-13 bar codes starting with digit ‘99’, and UPC-A/EAN-128 Coupon Codes. UPC-A, EAN-13 and EAN-128 must be enabled to scan all types of Coupon Codes. Enable UPC/EAN Coupon Code *Disable UPC/EAN...
UPC/EAN symbols without supplemental characters. • If UPC/EAN without supplemental characters is selected, and the MS-120X/220X is presented with a UPC/EAN plus supplemental symbol, the scanner decodes the UPC/EAN and ignores the supplemental characters. • If autodiscriminate is selected, scan...
Page 133
Parameter # 50h With Autodiscriminate UPC/EAN Supplementals selected, this option adjusts the number of times (from 2 to 30) a symbol without supplementals is decoded before transmission. Five or above is recommended when decoding a mix of UPC/EAN symbols with and without supplementals, and the autodiscriminate option is selected.
MS-120X and MS-220X Integration Guide Transmit UPC-A Check Digit Parameter # 28h Scan the appropriate bar code below to transmit the symbol with or without the UPC-A check digit. *Transmit UPC-A Check Digit (01h) Do Not Transmit UPC-A Check Digit...
Parameter Menus Transmit UPC-E Check Digit Parameter # 29h Scan the appropriate bar code below to transmit the symbol with or without the UPC-E check digit. *Transmit UPC-E Check Digit (01h) Do Not Transmit UPC-E Check Digit (00h) 9-39...
MS-120X and MS-220X Integration Guide Transmit UPC-E1 Check Digit Parameter # 2Ah Scan the appropriate bar code below to transmit the symbol with or without the UPC-E1 check digit. *Transmit UPC-E1 CHECK DIGIT (01h) Do Not Transmit UPC-E1 Check Digit...
Parameter # 22h Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-A symbol. Select one of the following options for transmitting UPC-A preamble to the host device: transmit system character only, transmit system character and country code (“0”...
Parameter # 23h Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-E symbol. Select one of the following options for transmitting UPC-E preamble to the host device: transmit system character only, transmit system character and country code (“0”...
Parameter # 24h Preamble characters (Country Code and System Character) can be transmitted as part of a UPC-E1 symbol. Select one of the following options for transmitting UPC-E1 preamble to the host device: transmit system character only, transmit system character and country code (“0”...
MS-120X and MS-220X Integration Guide Convert UPC-E to UPC-A Parameter # 25h This parameter converts UPC-E (zero suppressed) decoded data to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit). Scan DO NOT CONVERT UPC-E TO UPC-A to transmit UPC-E (zero suppressed) decoded data.
Parameter Menus Convert UPC-E1 to UPC-A Parameter # 26h Enable this parameter to convert UPC-E1 (zero suppressed) decoded data to UPC-A format before transmission. After conversion, data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit). Scan DO NOT CONVERT UPC-E TO UPC-A to transmit UPC-E1 (zero suppressed) decoded data.
MS-120X and MS-220X Integration Guide EAN Zero Extend Parameter # 27h When this parameter is enabled, five leading zeros are added to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. Disable this parameter to transmit EAN-8 symbols as is. Enable EAN Zero Extend (01h) *Disable EAN Zero Extend...
Parameter Menus UPC/EAN Security Level Parameter # 4Dh The MS-120X and MS-220X offer four levels of decode security for UPC/EAN bar codes. Select higher levels of security for decreasing levels of bar code quality. Increasing security decreases the scanner’s aggressiveness, so choose only that level of security necessary for the application.
Page 144
MS-120X and MS-220X Integration Guide UPC/EAN Security Level 2 Select this option if Security level 1 fails to eliminate misdecodes. UPC/EAN Security Level 2 (02h) UPC/EAN Security Level 3 If misdecodes still occur after selecting Security Level 2, select this security level. Be advised, selecting this option is an extreme measure against misdecoding severely out of spec bar codes.
Parameter Menus Linear UPC/EAN Decode Parameter # 44h This option applies to code types containing two adjacent blocks (e.g., UPC-A, EAN-8, EAN-13). When enabled, a bar code is transmitted only when both the left and right blocks are successfully decoded within one laser scan. Enable this option when bar codes are in proximity to each other.
MS-120X and MS-220X Integration Guide Enable/Disable ISBT 128 Parameter # 54h To enable or disable ISBT 128, scan the appropriate bar code below. Enable ISBT 128 (01h) *Disable ISBT 128 (00h) Lengths for Code 128 No length setting is required for Code 128. 9-52...
Parameter Menus Code 128 Decode Performance Parameter # 48h This option offers three levels of decode performance or “aggressiveness” for Code 128 symbols. Increasing the performance level reduces the amount of required bar code orientation, which is useful when scanning very long and/or truncated bar codes. Increased levels reduce decode security.
MS-120X and MS-220X Integration Guide Enable/Disable Trioptic Code 39 Parameter # 0Dh Trioptic Code 39 is a variant of Code 39 used in marking computer tape cartridges. Trioptic Code 39 symbols always contain six characters. Do not enable Trioptic Code 39 and Code 39 Full ASCII simultaneously.
Parameter Menus Convert Code 39 to Code 32 Parameter # 56h Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable converting Code 39 to Code 32. Note: Code 39 must be enabled for this parameter to function.
MS-120X and MS-220X Integration Guide Code 32 Prefix Parameter # E7h Enable this parameter to add the prefix character “A” to all Code 32 bar codes. Convert Code 39 to Code 32 must be enabled for this parameter to function. *Enable Code 32 Prefix (01h) Disable Code 32 Prefix...
Parameter Menus Set Lengths for Code 39 Parameter # L1 = 12h, L2 = 13h The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Lengths for Code 39 may be set for any length, one or two discrete lengths, or lengths within a specific range.
Page 156
MS-120X and MS-220X Integration Guide Length Within Range - This option limits decodes to only those Code 39 symbols within a specified range. The range is selected using the numeric bar codes beginning on page 9-144. For example, to decode Code 39 symbols containing between 4 and 12 characters, first scan Code 39 Length Within Range.
Parameter Menus Code 39 Check Digit Verification Parameter # 30h When this feature is enabled, the scanner checks the integrity of all Code 39 symbols to verify that the data complies with specified check digit algorithm. Only those Code 39 symbols which include a modulo 43 check digit are decoded.
MS-120X and MS-220X Integration Guide Transmit Code 39 Check Digit Parameter # 2Bh Scan this symbol to transmit the check digit with the data. Transmit Code 39 Check Digit (Enable) (01h) Scan this symbol to transmit data without the check digit.
Parameter Menus Enable/Disable Code 39 Full ASCII Parameter # 11h To enable or disable Code 39 Full ASCII, scan the appropriate bar code below. When enabled, the ASCII character set assigns a code to letters, punctuation marks, numerals, and most control keystrokes on the keyboard. The first 32 codes are non-printable and are assigned to keyboard control characters such as BACKSPACE and RETURN.
MS-120X and MS-220X Integration Guide Code 39 Decode Performance Parameter # 46h This option offers three levels of decode performance or “aggressiveness” for Code 39 symbols. Increasing the performance level reduces the amount of required bar code orientation, which is useful when scanning very long and/or truncated bar codes. Increased levels reduce decode security.
Parameter Menus Set Lengths for Code 93 Parameter # L1 = 1Ah, L2 = 1Bh The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Lengths for Code 93 can be set for any length, one or two discrete lengths, or lengths within a specific range.
Page 164
MS-120X and MS-220X Integration Guide Length Within Range - Select this option to decode only those codes within a specified range. For example, to decode Code 93 symbols containing between 4 and 12 characters, first scan Code 93 Length Within Range, then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).
MS-120X and MS-220X Integration Guide Set Lengths for Code 11 Parameter # L1 = 1Ch, L2 = 1Dh The length of a code refers to the number of characters (i.e., human readable characters), including check digit(s) the code contains. Lengths for Code 11 can be set for any length, one or two discrete lengths, or lengths within a specific range.
Page 167
Parameter Menus Length Within Range - Select this option to decode only those codes within a specified range. For example, to decode Code 11 symbols containing between 4 and 12 characters, first scan Code 11 Length Within Range, then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).
Code 11 Check Digit Verification Parameter # 34h When enabled, this parameter checks the integrity of a Code 11 symbol to ensure it complies with a specified check digit algorithm. Select either to check for one check digit, check for two check digits, or to disable the feature.
Parameter Menus Transmit Code 11 Check Digit Parameter # 2Fh Scan this symbol to transmit the check digit with the data. Transmit Code 11 Check Digit (Enable) (01h) Scan this symbol to transmit data without the check digit. *Do Not Transmit Code 11 Check Digit...
MS-120X and MS-220X Integration Guide Interleaved 2 of 5 Enable/Disable Interleaved 2 of 5 Parameter # 06h To enable or disable Interleaved 2 of 5, scan the appropriate bar code below. Enable Interleaved 2 Of 5 (01h) *Disable Interleaved 2 Of 5 (00h) 9-74...
Parameter Menus Set Lengths for Interleaved 2 of 5 Parameter # L1 = 16h, L2 = 17h The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits. Lengths for I 2 of 5 can be set for any length, one or two discrete lengths, or lengths within a specific range.
Page 172
MS-120X and MS-220X Integration Guide Length Within Range - Select this option to decode only codes within a specified range. For example, to decode I 2 of 5 symbols containing between 4 and 12 characters, first scan I 2 of 5 Length Within Range, then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).
I 2 of 5 Check Digit Verification Parameter # 31h When enabled, this parameter checks the integrity of an I 2 of 5 symbol to ensure it complies with a specified algorithm, either USS (Uniform Symbology Specification), or OPCC (Optical Product Code Council).
MS-120X and MS-220X Integration Guide Transmit I 2 of 5 Check Digit Parameter # 2Ch Scan this symbol to transmit the check digit with the data. Transmit I 2 of 5 Check Digit (Enable) (01h) Scan this symbol to transmit data without the check digit.
Parameter Menus Convert I 2 of 5 to EAN-13 Parameter # 52h This parameter converts a 14 character I 2 of 5 code into EAN-13, and transmits to the host as EAN-13. To accomplish this, I 2 of 5 must be enabled, one length must be set to 14, and the code must have a leading zero and a valid EAN-13 check digit.
MS-120X and MS-220X Integration Guide Discrete 2 of 5 Enable/Disable Discrete 2 of 5 Parameter # 05h To enable or disable Discrete 2 of 5, scan the appropriate bar code below. Enable Discrete 2 Of 5 (01h) *Disable Discrete 2 Of 5 (00h) 9-80...
Parameter Menus Set Lengths for Discrete 2 of 5 Parameter # L1 = 14h, L2 = 15h The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits. Lengths for D 2 of 5 can be set for any length, one or two discrete lengths, or lengths within a specific range.
Page 178
MS-120X and MS-220X Integration Guide Length Within Range - Select this option to decode codes within a specified range. For example, to decode D 2 of 5 symbols containing between 4 and 12 characters, first scan D 2 of 5 Length Within Range, then scan 0, 4, 1 and 2 (single digit numbers must be preceded by a leading zero).
MS-120X and MS-220X Integration Guide Set Lengths for Codabar Parameter # L1 = 18h, L2 = 19h The length of a code refers to the number of characters (i.e., human readable characters) the code contains, including start or stop characters. Lengths for Codabar may be set for any length, one or two discrete lengths, or lengths within a specific range.
Page 181
Parameter Menus Length Within Range - Select this option to decode a code within a specified range. For example, to decode Codabar symbols containing between 4 and 12 characters, first scan Codabar Length Within Range, then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).
Parameter # 36h When enabled, this parameter strips the start and stop characters and inserts a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Note: Symbol length does not include start and stop characters. Enable CLSI Editing...
Parameter Menus Set Lengths for MSI Plessey Parameter # L1 = 1Eh, L2 = 1Fh The length of a code refers to the number of characters (i.e., human readable characters) the code contains, and includes check digits. Lengths for MSI Plessey can be set for any length, one or two discrete lengths, or lengths within a specific range.
Page 186
MS-120X and MS-220X Integration Guide Length Within Range - Select this option to decode codes within a specified range. For example, to decode MSI Plessey symbols containing between 4 and 12 characters, first scan MSI Plessey Length Within Range, then scan 0, 4, 1 and 2 (single digit numbers must always be preceded by a leading zero).
Parameter Menus MSI Plessey Check Digits Parameter # 32h These check digits at the end of the bar code verify the integrity of the data. At least one check digit is required. Check digits are not automatically transmitted with the data. *One MSI Plessey Check Digit (00h) If two check digits is selected, also select an...
MS-120X and MS-220X Integration Guide Transmit MSI Plessey Check Digit Parameter # 2Eh Scan this symbol to transmit the check digit with the data. Transmit MSI Plessey Check Digit (Enable) (01h) Scan this symbol to transmit data without the check digit.
Parameter Menus MSI Plessey Check Digit Algorithm Parameter # 33h When the Two MSI Plessey check digits option is selected, an additional verification is required to ensure integrity. Select one of the following algorithms. *MOD 10/ MOD 11 (00h) MOD 10/ MOD 10 (01h) 9-93...
MS-120X and MS-220X Integration Guide MicroPDF Performance Parameter # F0h 65h If there are problems decoding MicroPDF symbols, select Selective Performance. F0h 65h This can decrease decoding aggressiveness on some symbols. *Standard Performance for MicroPDF (00h) Selective Performance for MicroPDF (03h) 9-96...
Parameter Menus Code 128 Emulation Parameter # 7Bh When this parameter is enabled, the scanner transmits data from certain MicroPDF417 symbols as if it was encoded in Code 128 symbols. Transmit AIM Symbology Identifiers must be enabled for this parameter to work. If Code 128 Emulation is enabled, these MicroPDF417 symbols are transmitted with one of the following prefixes: if the first codeword is 903-907, 912, 914, 915...
This parameter only applies to RSS-14 and RSS Limited symbols not decoded as part of a Composite symbol. When this conversion is enabled, RSS-14 and RSS Limited symbols encoding a single zero as the first digit have the leading '010' stripped and the bar code reported as EAN-13.
MS-120X and MS-220X Integration Guide Composite (MS-2204 Only) Composite CC-C Parameter # F0h 55h Scan a bar code below to enable or disable Composite bar codes of type CC-C. Enable CC-C (01h) Disable CC-C (00h) 9-102...
Parameter Menus Composite CC-A/B Parameter # F0h 56h Scan a bar code below to enable or disable Composite bar codes of type CC-A/B. Enable CC-A/B (01h) *Disable CC-A/B (00h) 9-103...
MS-120X and MS-220X Integration Guide Composite TLC-39 Parameter # F0h 73h Scan a bar code below to enable or disable Composite bar codes of type TLC-39. Enable TLC39 (01h) *Disable TLC39 (00h) 9-104...
Parameter Menus UPC Composite Mode Parameter # F0h 58h UPC symbols can be “linked” with a 2D symbol during transmission as if they were one symbol. Select one of the following options for these symbols: • Select UPC Never Linked to transmit UPC bar codes regardless of whether a 2D symbol is detected.
The code ID character is inserted between the prefix character (if selected) and the decoded symbol. Select no code ID character, a Symbol Code ID character, or an AIM Code ID character. The Symbol Code ID characters are listed below.
Page 203
Parameter Menus Transmit Code ID Character (continued) Symbol Code ID Character (02h) AIM Code ID Character (01h) *None (00h) 9-107...
MS-120X and MS-220X Integration Guide Prefix/Suffix Values Parameter # P = 69h, S1 = 68h, S2 = 6Ah Note: This section only applies to setting prefix/suffix values for the MS-1204 and MS-2204. To set prefix and suffix values for the MS 1207 and MS-2207, use ADF programming (see Send Preset Value on page 13-31.) A prefix and/or one or two suffixes can be appended to scan data for use in data editing.
MS-120X and MS-220X Integration Guide Scan Data Transmission Format (MS-XX04) Parameter # EBh To change the Scan Data Transmission Format, scan one of the following eight bar codes corresponding to the desired format. *Data As Is (00h) <DATA> <SUFFIX 1> (01h) <DATA>...
MS-120X and MS-220X Integration Guide Scan Data Transmission Format (MS-XX07) To change the Scan Data Transmission Format, scan the Scan Options bar code below, then select one of four options: • Data As Is • <DATA> <SUFFIX> • <PREFIX> <DATA> •...
Page 209
Parameter Menus Scan Data Transmission Format (MS-XX07) (continued) <DATA> <SUFFIX> <PREFIX> <DATA> <PREFIX> <DATA> <SUFFIX> Enter Data Format Cancel 9-113...
MS-120X and MS-220X Integration Guide Simple Serial Interface (SSI) Options (MS-1204/2204 Only) Baud Rate Parameter # 9Ch Baud rate is the number of bits of data transmitted per second. The scanner's baud rate setting should match the data rate setting of the host device. If not, data may not reach the host device or may reach it in distorted form.
MS-120X and MS-220X Integration Guide Parity Parameter # 9Eh A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. If you select Odd parity, the parity bit has a value 0 or 1, based on data, to ensure that an odd number of 1 bits is contained in the coded character.
Page 213
Parameter Menus Parity (continued) Select Mark parity and the parity bit is always 1. Mark (02h) Select Space parity and the parity bit is always 0. Space (03h) If no parity is required, select None. *None (04h) 9-117...
MS-120X and MS-220X Integration Guide Check Parity Parameter # 97h Select whether or not to check the parity of received characters. Select the type of parity through the Parity parameter. *Check Parity (01h) Do Not Check Parity (00h) 9-118...
Parameter Menus Software Handshaking Parameter # 9Fh This parameter offers control of the data transmission process in addition to that offered by hardware handshaking. Hardware handshaking is always enabled and cannot be disabled by the user. Disable ACK/NAK Handshaking When this option is selected, the decoder neither generates nor expects ACK/NAK handshaking packets.
MS-120X and MS-220X Integration Guide Host RTS Line State Parameter # 9Ah This parameter is used to set the idle state of the Serial Host RTS line. The SSI Interface is intended to be used with host applications which also implement the SSI protocol.
Parameter Menus Decode Data Packet Format Parameter # EEh This parameter selects whether decoded data is transmitted in raw format (unpacketed), or transmitted with the packet format as defined by the serial protocol. If the raw format is selected, ACK/NAK handshaking is disabled for decode data. *Send Raw Decode Data (00h) Send Packeted Decode Data...
MS-120X and MS-220X Integration Guide Stop Bit Select Parameter # 9Dh The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving (host) device for the next character in the serial data stream.
Parameter Menus Intercharacter Delay Parameter # 6Eh The intercharacter delay gives the host system time to service its receiver and perform other tasks between characters. Select the intercharacter delay option matching host requirements. The delay period can range from no delay to 99 msec in 1 msec increments. After scanning the bar code below, scan two bar codes beginning on page 9-144 to set the...
MS-120X and MS-220X Integration Guide Host Character Time-out Parameter # EFh This parameter determines the maximum time the decoder waits between characters transmitted by the host before discarding the received data and declaring an error. The time-out is set in 0.01 second increments from 0.01 seconds to 0.99 seconds. After scanning the bar code below, scan two bar codes beginning on page 9-144 to set the...
Parameter Menus Event Reporting The host can request the decoder to provide certain information (events) relative to the decoder’s behavior. Enable or disable the events listed in Table 9-3 by scanning the appropriate bar codes on the following pages. Parameter number format for these parameters follows those shown in the Simple Serial Interface (SSI) Programmer’s Guide for parameters numbered 256 or higher.
MS-120X and MS-220X Integration Guide Decode Event Parameter # F0h 00h When enabled, the scanner sends a message to the host whenever a bar code is successfully decoded. When disabled, no message is sent. Enable (01h) *Disable (00h) 9-126...
Parameter Menus Boot Up Event Parameter # F0h 02h When enabled, the sends a message a message to the host whenever power is applied. When disabled, no message is sent. Enable (01h) *Disable (00h) 9-127...
MS-120X and MS-220X Integration Guide Parameter Event Parameter # F0h 03h When enabled, the scanner sends a message to the host when one of the events specified Table 9-3 on page 9-125 occurs. When disabled, no message is sent. Enable (01h) *Disable (00h)
Parameter # Afh Enable this to transmit each PDF symbol as directly decoded data codewords, whether or not that symbol is part of a macro PDF sequence. Note that data is output as codeword values, not as interpreted data. “Codeword values” is an ASCII representation of a number from 000 to 928 for each codeword, preceded by an escape character.
Page 226
MS-120X and MS-220X Integration Guide Transmit Symbols in Codeword Format (continued) Scan the appropriate bar code to enable or disable this. Enable Transmit In Codeword Format (01h) *Disable Transmit In Codeword Format (00h) 9-130...
Parameter Menus Transmit Unknown Codewords Parameter # BAh Select Transmit Unknown Codewords to use the output codeword format for transmitting any non-GLI or non-macro PDF codeword. Select Do Not Transmit Unknown Codewords to sound a decode error beep when an unknown codeword is found. Transmit Unknown Codewords (01h) *Do Not Transmit Unknown Codewords...
MS-120X and MS-220X Integration Guide Escape Characters Parameter # E9h This enables the backslash (\) character as an Escape character for systems that can process transmissions containing special data sequences. Scan a bar code below to either format special data (e.g., GLI escapes, MacroPDF417 Control Block optional fields) according to the GLI (Global Label Identifier) protocol or the ECI (Extended Channel Interpretation) protocol, or to disable this parameter.
Parameter Menus Delete Character Set ECIs Parameter # E6h Select Delete Character Set ECIs to delete any escape sequences representing Character Set ECIs (also known as GLIs) from its buffer before transmission. In many receiving systems, Character Set ECIs can be removed without affecting the way data is displayed or processed.
ECIs. This version of the product supports ECIs 000900 through 000913, used for efficient encoding of Common Data Syntax Format 00-99. If this parameter is disabled, and a symbol is scanned that was encoded using an ECI escape, the scanner transmits the ECI escape followed by the uninterpreted data.
Parameter Menus Transmit Macro PDF User-Selected Fields (MS-2204 and MS-2207 Only) Enable or disable each of the following parameters to indicate whether or not to transmit the specified field in subsequently scanned Macro PDF417 symbols. The options cannot be changed in the middle of a Macro PDF set entry. All user-selected fields are prefixed by \923 for GLIs, and \C923C for ECIs.
MS-120X and MS-220X Integration Guide Transmit Block Count Parameter # B1h Transmit Block Count activates transmission of the block count field. The field character tag is \923\001. For example, the field may be: \923\0011856. Enable Transmit Block Count (01h) *Disable Transmit Block Count (00h) 9-136...
Parameter Menus Transmit Time Stamp Parameter # B2h Transmit Time Stamp activates transmission of the time stamp field. The field character tag is \923\002. For example, the field may be: \923\0022123443243234. Enable Transmit Time Stamp (01h) *Disable Transmit Time Stamp (00h) 9-137...
MS-120X and MS-220X Integration Guide Transmit Sender Parameter # B3h Transmit Sender activates transmission of the sender field. The field character tag is \923\003. For example, the field may be: \923\003Symbol Technologies Holtsville, NY. Enable Sender Transmit (01h) *Disable Sender Transmit (00h) 9-138...
Parameter Menus Transmit Addressee Parameter # B4h Transmit Addressee activates transmission of the addressee field. The field character tag is \923\004. For example, the field may be: \923\004AIM USA. Enable Addressee Transmit (01h) *Disable Addressee Transmit (00h) 9-139...
MS-120X and MS-220X Integration Guide Transmit Checksum Parameter # B6h Transmit Checksum activates transmission of the checksum field. The field character tag is \923\006. For example, the field may be: \923\00663823. Enable Checksum Transmit (01h) *Disable Checksum Transmit (00h) 9-140...
Parameter Menus Transmit File Size Parameter # B5h Transmit File Size activates transmission of the file size field. The field character tag is \923\005. For example, the field may be: \923\005179234. Enable File Size Transmit (01h) *Disable File Size Transmit (00h) 9-141...
MS-120X and MS-220X Integration Guide Transmit Macro PDF Control Header Parameter # B7h Transmit Macro PDF Control Header activates transmission of the control header, which contains the segment index and the file ID. For example, the field can be: \92800000\725\120\343. The five digits after the \928 are the segment index (or block index), and \725\120\343 is the file ID.
Parameter Menus Last Blocker Marker Parameter # B9h Enable Last Block Marker marks the last block in the set by the codeword \922. Enable Last Block Marker (01h) *Disable Last Block Marker (00h) 9-143...
MS-120X and MS-220X Integration Guide Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriately numbered bar code(s). 9-144...
Page 241
Parameter Menus Numeric Bar Codes (continued) 9-145...
MS-120X and MS-220X Integration Guide Numeric Bar Codes (continued) Cancel To change a selection or cancel an incorrect entry, scan the bar code below. Cancel 9-146...
Refer to the documentation for the host device. This scanner uses TTL RS-232 levels which interfaces with all PC's with no additional hardware. Note: Particularly noisy electrical environments may require a cable with an RS-232 transceiver. To obtain this cable contact the Symbol Support Center. 10-1...
MS-120X and MS-220X Integration Guide Throughout the programming bar code menus, asterisks ( ) indicate default values. Baud Rate 9600 Feature/Option Indicates Default RS-232 Default Parameters Table 10-1 lists the defaults for RS-232 host parameters. To change any option, scan the appropriate bar code(s) provided in the Parameter Descriptions section beginning on page 10-6.
Page 245
RS-232 Interface Table 10-1. RS-232 Host Default Table (Continued) Page Parameter Default Number Host Serial Response Time-out 2 Sec 10-19 RTS Line State Low RTS 10-20 Beep on <BEL> Disable 10-20 Intercharacter Delay 0 msec 10-21 Nixdorf Beep/LED Options Normal Operation 10-22 Ignore Unknown Characters Send Bar Code...
MS-120X and MS-220X Integration Guide RS-232 Host Parameters Various RS-232 hosts are configured with their own parameter default settings (Table 10- 2). Selecting the ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, Olivetti, Omron, or terminal sets the defaults listed below. Table 10-2.
Page 247
RS-232 Interface RS-232 Host Parameters (continued) Selecting the ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, or OPOS terminal enables the transmission of code ID characters listed in Table 10-3. These code ID characters are not programmable and are separate from the Transmit Code ID feature. Do not enable the Transmit Code ID feature for these terminals.
MS-120X and MS-220X Integration Guide RS-232 Host Types To select an RS-232 host interface, scan one of the following bar codes. Note: You must select an interface as there is no default; Standard RS-232 is the most common selection. Standard RS-232 ICL RS-232 Wincor-Nixdorf RS-232 Mode A Wincor-Nixdorf RS-232 Mode B...
MS-120X and MS-220X Integration Guide Baud Rate Baud rate is the number of bits of data transmitted per second. The scanner's baud rate setting should match the baud rate setting of the host device. If not, data may not reach the host device or may reach it in distorted form.
MS-120X and MS-220X Integration Guide Parity A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. Select Odd parity and the parity bit value is set to 0 or 1, based on data, to ensure that an odd number of 1 bits are contained in the coded character.
Page 253
RS-232 Interface Parity (continued) Select Space parity and the parity bit is always 0. Space Select None when no parity bit is required. None 10-11...
MS-120X and MS-220X Integration Guide Stop Bit Select The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream. Select the number of stop bits (one or two) the host device is programmed to accommodate.
RS-232 Interface Check Receive Errors Select whether or not the parity, framing, and overrun of received characters are checked. The parity value of received characters is verified against the parity parameter selected earlier. Check For Received Errors Do Not Check For Received Errors 10-13...
MS-120X and MS-220X Integration Guide Hardware Handshaking The data interface consists of an RS-232 port designed to operate either with or without the hardware handshaking lines, Request to Send (RTS), and Clear to Send (CTS). If Standard RTS/CTS handshaking is not selected, scan data is transmitted as it becomes available.
Page 257
RS-232 Interface None Scan the bar code below if no Hardware Handshaking is desired. None Standard RTS/CTS Scan the bar code below to select Standard RTS/CTS Hardware Handshaking. Standard RTS/CTS RTS/CTS Option 1 When RTS/CTS Option 1 is selected, the scanner asserts RTS before transmitting and ignores the state of CTS.
MS-120X and MS-220X Integration Guide RTS/CTS Option 3 When Option 3 is selected, the scanner asserts RTS prior to any data transmission, regardless of the state of CTS. The scanner waits up to the Host Serial Response Time-out (default) for CTS to be asserted. If CTS is not asserted during this time, the scanner issues an error indication and discards the data.
Page 259
RS-232 Interface ACK/NAK When this option is selected, after transmitting data, the scanner expects either an ACK or NAK response from the host. When the scanner receives a NAK, it re-transmits the data and waits for either an ACK or NAK. After three unsuccessful attempts to send data, the scanner issues an error indication and discards the data.
Page 260
MS-120X and MS-220X Integration Guide ACK/NAK with ENQ This combines the two previous options. ACK/NAK with ENQ XON/XOFF An XOFF character turns the scanner transmission off until the scanner receives an XON character. There are two situations for XON/XOFF: • XOFF is received before the scanner has data to send.
RS-232 Interface Host Serial Response Time-out This parameter specifies how long the scanner waits for an ACK, NAK, or CTS before determining that a transmission error has occurred. This only applies when an ACK/NAK Software Handshaking mode or RTS/CTS Hardware Handshaking is enabled. Minimum: 2 Sec Low: 2.5 Sec Medium: 5 Sec...
MS-120X and MS-220X Integration Guide RTS Line State This parameter sets the idle state of the Serial Host RTS line. Scan a bar code below to select Low RTS or High RTS line state. Host: Low RTS Host: High RTS Beep on <BEL>...
MS-120X and MS-220X Integration Guide Nixdorf Beep/LED Options When Nixdorf Mode B is selected, this indicates when the scanner beeps and turns on its LED after a decode. *Normal Operation (Beep/LED immediately after decode) Beep/LED After Transmission Beep/LED After CTS Pulse 10-22...
RS-232 Interface Ignore Unknown Characters Unknown characters are characters the host does not recognize. When Send Bar Codes with Unknown Characters is selected, all bar code data is sent except for unknown characters, and no error beeps sound on the scanner. When Do Not Send Bar Codes With Unknown Characters is selected, bar code data is sent up to the first unknown character, then four (error) beeps sound on the scanner.
Page 266
MS-120X and MS-220X Integration Guide 10-24...
Chapter 11 USB Interface (MS-1207/MS-2207 Only) Introduction This chapter describes how to connect and configure the scanner with a USB host, and only applies to the MS-1207 and MS-2207. The MiniScan attaches directly to a USB host, or a powered USB hub, which powers it. No additional power supply is required. Throughout the programming bar code menus, asterisks ( ) indicated default values.
Windows 98, 2000, ME, XP • MacOS 8.5 and above • IBM 4690 OS. The scanner also interfaces with other USB hosts that support USB Human Interface Devices (HID). For more information on USB technology, hosts, and peripheral devices, visit www.symbol.com/usb. 11-2...
USB Interface (MS-1207/MS-2207 Only) USB Default Parameters Table 11-1 lists the defaults for USB host parameters. To change any option, scan the appropriate bar code(s) provided in USB Host Parameters on page 11-4. Note: See Chapter 9, Parameter Menus for all user preferences, hosts, symbologies, and miscellaneous default parameters.
MS-120X and MS-220X Integration Guide USB Host Parameters USB Device Type Select the desired USB device type. Note: When changing USB Device Types, the scanner automatically restarts and issues the standard startup beep sequences. *HID Keyboard Emulation IBM Table Top USB IBM Hand-Held USB 11-4...
USB Interface (MS-1207/MS-2207 Only) USB Country Keyboard Types (Country Codes) Scan the bar code corresponding to the keyboard type. This setting applies only to the USB HID Keyboard Emulation device. North American Standard USB Keyboard German Windows French Windows 11-5...
Page 272
MS-120X and MS-220X Integration Guide USB Country Keyboard Types (continued) French Canadian Windows 95/98 French Canadian Windows 2000/XP Spanish Windows Italian Windows 11-6...
Page 273
USB Interface (MS-1207/MS-2207 Only) USB Country Keyboard Types (continued) Swedish Windows UK English Windows Japanese Windows (ASCII) Portuguese-Brazilian Windows 11-7...
MS-120X and MS-220X Integration Guide USB Keystroke Delay This parameter sets the delay, in milliseconds, between emulated keystrokes. Scan a bar code below to increase the delay when hosts require a slower transmission of data. No Delay Medium Delay (20 msec) Long Delay (40 msec) 11-8...
USB Interface (MS-1207/MS-2207 Only) USB CAPS Lock Override This option applies only to the HID Keyboard Emulation device. When enabled, the case of the data is preserved regardless of the state of the caps lock key. This setting is always enabled for the Japanese, Windows (ASCII) keyboard type.
MS-120X and MS-220X Integration Guide USB Ignore Unknown Characters This option applies only to the HID Keyboard Emulation device and IBM device. Unknown characters are characters the host does not recognize. Select Send Bar Codes With Unknown Characters to send all bar code data except for unknown characters. No error beeps sound.
USB Interface (MS-1207/MS-2207 Only) Emulate Keypad When enabled, all characters are sent as ASCII sequences over the numeric keypad. For example ASCII A is sent as “ALT make” 0 6 5 “ALT Break”. *Disable Keypad Emulation Enable Keypad Emulation USB Keyboard FN 1 Substitution This option applies only to the USB HID Keyboard Emulation device.
MS-120X and MS-220X Integration Guide Function Key Mapping ASCII values under 32 are normally sent as a control-key sequences (see Table A-2 on page A-7). When this parameter is enabled, the keys in bold are sent in place of the standard key mapping.
USB Interface (MS-1207/MS-2207 Only) Convert Case When enabled, the scanner converts all bar code data to the selected case. *No Case Conversion Convert All to Upper Case Convert All to Lower Case 11-13...
Page 280
MS-120X and MS-220X Integration Guide 11-14...
Chapter 12 123Scan (MS-1207/MS-2207 Only) Introduction ® 123Scan is a Windows -based utility for the MS-1207 and MS-2207 only, that enables programming these scanners with all parameters, including Advanced Data Formatting (ADF) rules. An ADF rule modifies bar code data before it is sent to the host to ensure compatibility between this data and the host application, so there is no need to modify the host software.
MiniScan Family of Scanners Integration Guide 123Scan Parameter To communicate with the 123Scan program, install 123Scan, included in the documentation CD-ROM, onto the PC and scan the bar code below. Refer to 123Scan instructions for programming the scanner. Note: Scanning this bar code enables the 123Scan interface on the scanner.
Chapter 13 Advanced Data Formatting (MS-1207/MS-2207 Only) Introduction Advanced Data Formatting (ADF) is a means of customizing data before transmission to a host device. Scan data can be edited to suit particular requirements. ADF can be implemented through scanning a related series of bar codes, which begin on page 13-8, or by installing the 123Scan utility (see Chapter 12) which allows the MiniScan...
MS-120X and MS-220X Integration Guide If a Code 39 bar code of 1299X15598 is scanned, this rule is ignored because the length criteria is not met. The rule specifies the editing conditions and requirements before data transmission occurs. Using ADF Bar Codes When programming a rule, make sure the rule is logically correct.
Advanced Data Formatting (MS-1207/MS-2207 Only) ADF Bar Code Menu Example This section provides an example of how to enter and use ADF rules for scan data. An auto parts distribution center wants to encode manufacturer ID, part number, and destination code into their own Code 128 bar codes. The distribution center also has products that carry UPC bar codes applied by the manufacturer.
MS-120X and MS-220X Integration Guide Rule 1: The Code 128 Scanning Rule Step Bar Code On Page Beep Indication Begin New Rule 13-8 High High Code 128 13-12 High High Send next 5 characters 13-24 High High Send <CTRL M> 13-44 High High Send next 5 characters...
Page 287
Advanced Data Formatting (MS-1207/MS-2207 Only) where: Class = 24 Stock Number = 56712437 Price = 01500 Ordinarily you would send this data as follows: 24 (class key) 56712437 (stock key) 01500 (enter key) But, when there is a sale, you may want to send only the following: 24 (class key) 56712437 (stock key) and the cashier keys the price manually.
MS-120X and MS-220X Integration Guide The switching back to normal rules can also be done in the “sale” rule. For example: When scanning a bar code of length 15, send the next 2 characters, send the class key, send the next 8 characters, send the stock key, turn off rule set 1. It is recommended that you scan the Disable All Rule Sets bar code on page 13-11 after...
Advanced Data Formatting (MS-1207/MS-2207 Only) Default Rules Every unit has a default rule to send all scan data. Units with custom software can have one or more default rules. The rules hierarchy checks user programmable rules first, then the default rules. To disable default rules, enter the following general rule in the user programmable buffer: When receiving scan data, send all data.
MS-120X and MS-220X Integration Guide Special Commands Pause Duration This parameter along with Send Pause on page 13-28 inserts a pause in the data transmission. To set a pause, which is measured in 0.1 second intervals, scan a two-digit number (i.e., two numeric bar codes). For example, scanning bar codes 0 and 1 inserts a 0.1 second pause;...
Advanced Data Formatting (MS-1207/MS-2207 Only) Save Rule Scan this bar code to save the entered rule. Save Rule Erase Use these bar codes to erase criteria, actions, or rules. Erase Actions And Erase Criteria And Start Again Start Again Erase Previously Erase All Rules Saved Rule 13-9...
Advanced Data Formatting (MS-1207/MS-2207 Only) Disable Rule Set Use these bar codes to disable rule sets. Disable Rule Set 2 Disable Rule Set 1 Disable Rule Set 3 Disable Rule Set 4 Disable All Rule Sets 13-11...
MS-120X and MS-220X Integration Guide Criteria Code Types Select any number of code types to be affected. Scan all selected codes in succession, prior to selecting other criteria. If you don't select a code type, all code types are affected. Codabar Code 39 RSS 14...
Page 295
Advanced Data Formatting (MS-1207/MS-2207 Only) Scan the bar codes for all code types desired before selecting other criteria. D 2 OF 5 IATA 2 OF 5 I 2 OF 5 Code 93 UPC-E UPC-A EAN-13 EAN-8 13-13...
Advanced Data Formatting (MS-1207/MS-2207 Only) Code Lengths Scan these bar codes to define the number of characters the selected code type must contain. If you don't select a code length, selected code types of any length are affected. Select one length per rule only. 2 Characters 1 Character 3 Characters...
MS-120X and MS-220X Integration Guide Message Containing A Specific Data String Use this feature to select whether the formatting affects data that begins with a specific character or data string, or contains a specific character or data string. There are 4 features: •...
Advanced Data Formatting (MS-1207/MS-2207 Only) Specific String, Any Location To enter the position (use a leading “zero” if necessary): 1. Scan the following bar code. 2. Enter a location using the Numeric Keypad on page 13-22. 3. Enter a string of characters (up to a total of 8) using the Alphanumeric Keyboard beginning on page 13-80.
MS-120X and MS-220X Integration Guide Numeric Keypad Do not confuse these bar codes with those on the alphanumeric keyboard. Cancel 13-22...
Page 305
Advanced Data Formatting (MS-1207/MS-2207 Only) Rule Belongs To Set Scan a bar code below to select the set a rule belongs to. There are four possible rule sets. Refer to Alternate Rule Sets on page 13-4 for more information. Rule Belongs To Set 1 Rule Belongs To Set 2 Rule Belongs To Set 4 Rule Belongs To Set 3...
MS-120X and MS-220X Integration Guide Actions Select how to format the data for transmission. Send Data Scan the following bar codes to send all data that remains, send all data up to a specific character selected from the Alphanumeric Keyboard on page 13-80, or send the next N characters.
Page 307
Advanced Data Formatting (MS-1207/MS-2207 Only) Send Data (continued) Send Next Send Next 6 Characters 7 Characters Send Next Send Next 8 9 Characters Characters Send Next Send Next 10 Characters 11 Characters Send Next Send Next 13 Characters 12 Characters Send Next Send Next 15 Characters...
Page 308
MS-120X and MS-220X Integration Guide Send Data (continued) Send Next Send Next 16 Characters 17 Characters Send Next Send Next 18 Characters 19 Characters Send Next 20 Characters 13-26...
Advanced Data Formatting (MS-1207/MS-2207 Only) Setup Field(s) Table 13-1. Setup Field(s) Definitions Parameter Description Page Move Cursor Scan the Move Cursor To Character Move Cursor To a Character bar code on 13-28 , then any printable ASCII character page 13-28 from the Alphanumeric Keyboard.
MS-120X and MS-220X Integration Guide Move Cursor Scan a bar code below to move the cursor in relation to a specified character. Then enter a character by scanning a bar code from the Alphanumeric Keyboard beginning on page 13-80. Note: If there is no match when the rule is interpreted and the rule fails, the next rule is checked.
MS-120X and MS-220X Integration Guide Skip Back Use the following bar codes to skip back characters. Skip Back Skip Back 2 Characters 1 Characters Skip Back Skip Back 3 Characters 4 Characters Skip Back Skip Back 6 Characters 5 Characters Skip Back Skip Back 8 Characters...
Advanced Data Formatting (MS-1207/MS-2207 Only) Send Preset Value Use these bar codes to send preset values. These values must be set using the prefix/suffix values in Table A-1 on page A-1. Send Value 1 Send Value 2 Send Value 4 Send Value 3 Send Value 5 13-31...
MS-120X and MS-220X Integration Guide Modify Data The following bar codes modify data in the ways listed. The following actions work for all send commands that follow it within a rule. Programming pad zeros to length 6, send next 3 characters, stop padding, send next 5 characters, to add three zeros to the first send; the next send is unaffected by the padding.
Page 315
Advanced Data Formatting (MS-1207/MS-2207 Only) Use the bar codes below to modify data. Remove All Spaces Crunch All Spaces Remove Leading Stop Space Removal Zeros Stop Zero Removal 13-33...
MS-120X and MS-220X Integration Guide Pad Data with Spaces To pad data to the left, scan the bar code containing the desired number of spaces. This parameter is activated by Send commands. Pad Spaces To Pad Spaces To Length 1 Length 2 Pad Spaces To Pad Spaces To...
Page 317
Advanced Data Formatting (MS-1207/MS-2207 Only) Pad Data with Spaces (continued) Pad Spaces To Pad Spaces To Length 9 Length 10 Pad Spaces To Pad Spaces To Length 12 Length 11 Pad Spaces To Pad Spaces To Length 13 Length 14 Pad Spaces To Pad Spaces To Length 15...
Page 318
MS-120X and MS-220X Integration Guide Pad Data with Spaces (continued) Pad Spaces To Pad Spaces To Length 17 Length 18 Pad Spaces To Pad Spaces To Length 19 Length 20 Pad Spaces To Pad Spaces To Length 21 Length 22 Pad Spaces To Pad Spaces To Length 23...
Page 319
Advanced Data Formatting (MS-1207/MS-2207 Only) Pad Data with Spaces (continued) Pad Spaces To Pad Spaces To Length 25 Length 26 Pad Spaces To Pad Spaces To Length 28 Length 27 Pad Spaces To Pad Spaces To Length 29 Length 30 Stop Pad Spaces 13-37...
MS-120X and MS-220X Integration Guide Pad Data with Zeros To pad data to the left, scan the bar code containing the desired number of zeros. This parameter is activated by Send commands. Pad Zeros To Pad Zeros To Length 1 Length 2 Pad Zeros To Pad Zeros To...
Page 321
Advanced Data Formatting (MS-1207/MS-2207 Only) Pad Data with Zeros (continued) Pad Zeros To Pad Zeros To Length 9 Length 10 Pad Zeros To Pad Zeros To Length 11 Length 12 Pad Zeros To Pad Zeros To Length 13 Length 14 Pad Zeros To Pad Zeros To Length 15...
Page 322
MS-120X and MS-220X Integration Guide Pad Data with Zeros (continued) Pad Zeros To Pad Zeros To Length 17 Length 18 Pad Zeros To Pad Zeros To Length 20 Length 19 Pad Zeros To Pad Zeros To Length 22 Length 21 Pad Zeros To Pad Zeros To Length 23...
Page 323
Advanced Data Formatting (MS-1207/MS-2207 Only) Pad Data with Zeros (continued) Pad Zeros To Pad Zeros To Length 25 Length 26 Pad Zeros To Pad Zeros To Length 28 Length 27 Pad Zeros To Pad Zeros To Length 30 Length 29 Stop Pad Zeros 13-41...
Advanced Data Formatting (MS-1207/MS-2207 Only) Send Keystroke Control Characters Scan the bar code representing the keystroke you want to send. Send Control 2 Send Control A Send Control B Send Control C Send Control D Send Control E Send Control F Send Control G 13-43...
Page 326
MS-120X and MS-220X Integration Guide Control Characters (continued) Send Control H Send Control I Send Control J Send Control K Send Control L Send Control M Send Control N Send Control O 13-44...
Page 327
Advanced Data Formatting (MS-1207/MS-2207 Only) Control Characters (continued) Send Control Q Send Control P Send Control S Send Control R Send Control T Send Control U Send Control W Send Control V 13-45...
Page 328
MS-120X and MS-220X Integration Guide Control Characters (continued) Send Control X Send Control Y Send Control Z Send Control [ Send Control \ Send Control ] Send Control 6 Send Control - 13-46...
Advanced Data Formatting (MS-1207/MS-2207 Only) Keyboard Characters Scan the bar code representing the keyboard character you want to send. Send Space Send ! Send “ Send # Send $ Send % Send & Send ‘ 13-47...
Page 333
Advanced Data Formatting (MS-1207/MS-2207 Only) Keyboard Characters (continued) Send @ Send A Send B Send C Send D Send E Send F Send G 13-51...
Page 334
MS-120X and MS-220X Integration Guide Keyboard Characters (continued) Send I Send H Send K Send J Send L Send M Send O Send N 13-52...
Page 335
Advanced Data Formatting (MS-1207/MS-2207 Only) Keyboard Characters (continued) Send P Send Q Send R Send S Send T Send U Send V Send W 13-53...
Page 336
MS-120X and MS-220X Integration Guide Keyboard Characters (continued) Send Y Send X Send [ Send Z Send ] Send \ Send _ Send ^ 13-54...
Page 337
Advanced Data Formatting (MS-1207/MS-2207 Only) Keyboard Characters (continued) Send ` Send a Send b Send c Send d Send e Send f Send g 13-55...
Page 338
MS-120X and MS-220X Integration Guide Keyboard Characters (continued) Send h Send i Send j Send k Send l Send m Send n Send o 13-56...
Page 339
Advanced Data Formatting (MS-1207/MS-2207 Only) Keyboard Characters (continued) Send p Send q Send r Send s Send t Send u Send v Send w 13-57...
Page 340
MS-120X and MS-220X Integration Guide Keyboard Characters (continued) Send y Send x Send { Send z Send } Send | Send ~ 13-58...
Advanced Data Formatting (MS-1207/MS-2207 Only) Send ALT Characters Scan the bar code representing the Alt character you want to send. Send Alt 2 Send Alt A Send Alt B Send Alt C Send Alt D Send Alt E Send Alt F Send Alt G 13-59...
Page 342
MS-120X and MS-220X Integration Guide Send ALT Characters (continued) Send Alt I Send Alt H Send Alt K Send Alt J Send Alt L Send Alt M Send Alt O Send Alt N 13-60...
Page 343
Advanced Data Formatting (MS-1207/MS-2207 Only) Send ALT Characters (continued) Send Alt P Send Alt Q Send Alt R Send Alt S Send Alt T Send Alt U Send Alt V Send Alt W 13-61...
Page 344
MS-120X and MS-220X Integration Guide Send ALT Characters (continued) Send Alt Y Send Alt X Send Alt [ Send Alt Z Send Alt \ Send Alt ] Send Alt - Send Alt 6 13-62...
Advanced Data Formatting (MS-1207/MS-2207 Only) Send Right Control Key The Send Right Control Key action sends a tap (press and release) of the Right Control Key. Send Right Control Key Send Graphic User Interface (GUI) Characters The Send Graphic User Interface Character actions tap the specified key while holding the System Dependent Graphic User Interface (GUI) key.
Page 357
Advanced Data Formatting (MS-1207/MS-2207 Only) Send Graphic User Interface (GUI) Characters (continued) Send GUI A Send GUI B Send GUI C Send GUI D Send GUI F Send GUI E 13-75...
Page 358
MS-120X and MS-220X Integration Guide Send Graphic User Interface (GUI) Characters (continued) Send GUI G Send GUI H Send GUI I Send GUI J Send GUI K Send GUI L 13-76...
Page 359
Advanced Data Formatting (MS-1207/MS-2207 Only) Send Graphic User Interface (GUI) Characters (continued) Send GUI M Send GUI N Send GUI P Send GUI O Send GUI Q Send GUI R 13-77...
Page 360
MS-120X and MS-220X Integration Guide Send Graphic User Interface (GUI) Characters (continued) Send GUI T Send GUI S Send GUI U Send GUI V Send GUI X Send GUI W Send GUI Z Send GUI Y 13-78...
Advanced Data Formatting (MS-1207/MS-2207 Only) Turn On/Off Rule Sets Use these bar codes to turn rule sets on and off. Turn On Rule Set 1 Turn On Rule Set 2 Turn On Rule Set 3 Turn On Rule Set 4 Turn Off Rule Set 2 Turn Off Rule Set 1 Turn Off Rule Set 4...
Page 365
Advanced Data Formatting (MS-1207/MS-2207 Only) Alphanumeric Keyboard (continued) Do not confuse bar codes on this page with those on the numeric keypad. 13-83...
Simple Serial Interface (SSI) (MS-1204/MS-2204 Only) Simple Serial Interface (SSI) The MS-1204 and MS-2204 scanners communicate with a host device using Symbol's Simple Serial Interface (SSI). This interface is only available on MS-1204 and MS-2204 models. The Simple Serial Interface (SSI) Programmer’s Guide (p/n 72-40451-xx) provides general information on SSI, includes information on the decoder’s hardware signals, and describes...
MS-120X and MS-220X Integration Guide Revision String When the decoder sends the REPLY_REVISION message, the revision string is in the following format: S/W_REVISION <space> BOARD_TYPE <space> ENGINE_CODE <space> PGM_CHKSUM where: • S/W_REVISION is the release name of the software • BOARD_TYPE is N for non-flash decoder board, F for flash •...
Chapter 15 Mounting Template Overview This chapter provides a mounting template for the MiniScan scanner. Copy this page to use template. Figure 15-1. Mounting Template 15-1...
Page 376
MS-120X and MS-220X Integration Guide 15-2...
Appendix A ASCII Character Sets RS-232 ASCII Character Set The values in Table A-1 can be assigned as prefixes or suffixes for ASCII character data transmission in an RS-232 environment. Table A-1. Prefix/Suffix Values Full ASCII Prefix/Suffix Value ASCII Character Code 39 Encode Character 1000 1001...
ASCII Character Sets USB ASCII Character Set The values in Table A-2 can be used for ASCII character data transmission in a USB environment. Table A-2. USB ASCII Character Set Full ASCII Prefix/ Suffix Value Keystroke Code 39 Encode Char. 1000 CTRL 2 1001...
Page 384
MS-120X and MS-220X Integration Guide Table A-2. USB ASCII Character Set (Continued) 1021 CTRL U 1022 CTRL V 1023 CTRL W 1024 CTRL X 1025 CTRL Y 1026 CTRL Z CTRL [ / ESC* 1027 1028 CTRL \ 1029 CTRL ] 1030 CTRL 6 1031...
Page 385
ASCII Character Sets Table A-2. USB ASCII Character Set (Continued) 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065 1066 1067 1068 1069 1070 1071 1072 *The keystroke in bold is sent only if Function Key Mapping is enabled.
Page 386
MS-120X and MS-220X Integration Guide Table A-2. USB ASCII Character Set (Continued) 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 *The keystroke in bold is sent only if Function Key Mapping is enabled. A-10...
Page 387
ASCII Character Sets Table A-2. USB ASCII Character Set (Continued) 1099 1100 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 *The keystroke in bold is sent only if Function Key Mapping is enabled. A-11...
Page 388
MS-120X and MS-220X Integration Guide Table A-2. USB ASCII Character Set (Continued) 1125 1126 ALT Keys Keystroke 2064 ALT 2 2065 ALT A 2066 ALT B 2067 ALT C 2068 ALT D 2069 ALT E 2070 ALT F 2071 ALT G 2072 ALT H 2073...
Page 389
ASCII Character Sets Table A-2. USB ASCII Character Set (Continued) 2087 ALT W 2088 ALT X 2089 ALT Y 2090 ALT Z GUI Shift Keys ™ The Apple iMac keyboard has an apple key on either side of the space bar. Windows-based systems have a GUI key to the left of the left ALT key, and to the right of the right ALT key.
Page 390
MS-120X and MS-220X Integration Guide Table A-2. USB ASCII Character Set (Continued) 3073 GUI I 3074 GUI J 3075 GUI K 3076 GUI L 3077 GUI M 3078 GUI N 3079 GUI O 3080 GUI P 3081 GUI Q 3082 GUI R 3083 GUI S...
Page 391
ASCII Character Sets Table A-2. USB ASCII Character Set (Continued) 5008 5009 5010 5011 5012 5013 5014 5015 5016 5017 5018 5019 5020 5021 5022 5023 5024 Keypad Keystroke 6042 6043 6044 undefined 6045 6046 6047 6048 6049 *The keystroke in bold is sent only if Function Key Mapping is enabled. A-15...
Page 392
MS-120X and MS-220X Integration Guide Table A-2. USB ASCII Character Set (Continued) 6050 6051 6052 6053 6054 6055 6056 6057 6058 Enter 6059 Num Lock Extended Keypad Keystroke 7001 Break 7002 Delete 7003 PgUp 7004 7005 Pg Dn 7006 Pause 7007 Scroll Lock 7008...
Page 393
ASCII Character Sets Table A-2. USB ASCII Character Set (Continued) 7016 Down Arrow 7017 Left Arrow 7018 Right Arrow *The keystroke in bold is sent only if Function Key Mapping is enabled. A-17...
Page 394
MS-120X and MS-220X Integration Guide A-18...
Page 395
Bar Height The dimension of a bar measured perpendicular to the bar width. Bar Width Thickness of a bar measured from the edge closest to the symbol start character to the trailing edge of the same bar. Baud Rate A measure of the data flow or number of signaling events occurring per second.
Page 396
Those characters available for encodation in a particular bar code symbology. Check Digit A digit used to verify a correct symbol decode. The scanner inserts the decoded data into an arithmetic formula and checks that the resulting number matches the encoded check digit. Check digits are required for UPC but are optional for other symbologies.
Page 397
Continuous Code A bar code or symbol in which all spaces within the symbol are parts of characters. There are no intercharacter gaps in a continuous code. The absence of gaps allows for greater information density.
Page 398
MS-120X and MS-220X Integration Guide European Article Number. This European/International version of the UPC provides its own coding format and symbology standards. Element dimensions are specified metrically. EAN is used primarily in retail. Element Generic term for a bar or space. Encoded Area Total linear dimension occupied by all characters of a code pattern, including start/stop characters and data.
Page 399
A condition which occurs when the data output of a reader or interface (Misdecode) controller does not agree with the data encoded within a bar code symbol. MSI Plessey A numeric-only bar code type. MSI Plessey consists of four bars and four adjacent spaces.
Page 400
Print Contrast Measurement of the contrast (brightness difference) between the bars and Signal (PCS) spaces of a symbol. A minimum PCS value is needed for a bar code symbol to be scannable. PCS = (R ) / R , where R...
Page 401
Index Index Numerics send preset value ....13-27 send value ....13-31 123Scan .
Page 402
MS-120X and MS-220X Integration Guide send keyboard characters ..13-47 set defaults ..... . 9-2 send keypad characters .
Page 403
Index transmit macro PDF control header 9-142 transmit sender ....9-138 host types transmit symbols in codeword RS-232 ..... . . 10-6 format .
We’d like to know what you think about this Manual. Please take a moment to fill out this questionnaire and fax this form to: (631) 738-3318, or mail to: Symbol Technologies, Inc. One Symbol Plaza M/S B-4 Holtsville, NY 11742-1300 Attention: Technical Publications Manager IMPORTANT: If you need product support, please call the appropriate customer support number provided.
Page 410
MS-120X and MS-220X Integration Guide 72-63538-02 Revision A — November 2003 Symbol Technologies, Inc. One Symbol Plaza, Holtsville N.Y. 11742-1300 http://www.symbol.com/manuals...
Need help?
Do you have a question about the MiniScan MS-220X and is the answer not in the manual?
Questions and answers
