  • Page 1 Symbol LS4208 Product Reference Guide...
  • Page 3 Symbol LS4208 Product Reference Guide 72E-69413-07 Revision A November 2012...

  • Page 4: Warranty

    Symbol LS4208 Product Reference Guide © 2009-2012 Motorola Solutions, Inc. All rights reserved. No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means, without permission in writing from Motorola. This includes electronic or mechanical means, such as photocopying, recording, or information storage and retrieval systems.

  • Page 5: Revision History

    Revision History Changes to the original manual are listed below: Change Date Description -01 Rev A 5/2005 Initial release. -02 Rev A 6/2005 Update RSS description. -03 Rev A 1/2007 Update service section, add special IBM command bar codes, add parameter bar codes for Bookland ISBN format and new UPC supplemental decode options, add bar codes for report version, report MIMIC version, and report Synapse cable, add ADF section.
  • Page 6 Symbol LS4208 Product Reference Guide...

  • Page 7: Table Of Contents

    Scan Patterns ....................... 2-4 Single-Line Only ...................... 2-4 Multi-Line Smart Raster ..................2-4 Multi-line Always Raster ..................2-4 Scanning Modes ......................2-5 Scanning in Hand-Held Mode ................. 2-5 Scanning in Hands-Free Mode ................2-9 Symbol LS4208 Decode Zone ..................2-11...
  • Page 8 Symbol LS4208 Product Reference Guide Chapter 3: Maintenance, Troubleshooting & Technical Specifications Introduction ........................3-1 Maintenance ......................... 3-1 Troubleshooting ......................3-2 Technical Specifications ....................3-5 Scanner Signal Descriptions ..................3-7 Chapter 4: User Preferences Introduction ........................4-1 Scanning Sequence Examples ..................4-1 Errors While Scanning ....................
  • Page 9 Table of Contents Chapter 6: RS-232 Interface Introduction ........................6-1 Connecting an RS-232 Interface .................. 6-2 RS-232 Parameter Defaults ..................6-3 RS-232 Host Parameters ....................6-4 RS-232 Host Types ....................6-6 Baud Rate ....................... 6-7 Parity ........................6-8 Stop Bit Select ......................6-9 Data Bits (ASCII Format) ..................
  • Page 10 Symbol LS4208 Product Reference Guide Chapter 9: Wand Emulation Interface Introduction ........................9-1 Connecting Using Wand Emulation ................9-2 Wand Emulation Parameter Defaults ................9-3 Wand Emulation Host Parameters ................9-4 Wand Emulation Host Types .................. 9-4 Leading Margin (Quiet Zone) .................. 9-5 Polarity ........................
  • Page 11 Table of Contents Transmit UPC-E Check Digit .................. 12-15 Transmit UPC-E1 Check Digit ................12-15 UPC-A Preamble ....................12-16 UPC-E Preamble ....................12-17 UPC-E1 Preamble ....................12-18 Convert UPC-E to UPC-A ..................12-19 Convert UPC-E1 to UPC-A ..................12-19 EAN-8/JAN-8 Extend ....................12-20 Bookland ISBN Format ...................
  • Page 12 Symbol LS4208 Product Reference Guide Set Lengths for MSI ....................12-50 MSI Check Digits ....................12-51 Transmit MSI Check Digit(s) ................... 12-52 MSI Check Digit Algorithm ..................12-52 GS1 DataBar (formerly RSS - Reduced Space Symbology) ........12-53 Convert GS1 DataBar to UPC/EAN ................ 12-54 PDF417/MicroPDF417 ....................
  • Page 13 Turn On/Off Rule Sets .................... 14-82 Alphanumeric Keyboard ....................14-83 Appendix A: Standard Default Parameters Default Parameters ....................... A-1 Appendix B: Programming References Symbol Code Identifiers ....................B-1 AIM Code Identifiers ..................... B-2 Appendix C: Sample Bar Codes Code 39 ........................C-1 UPC/EAN ........................C-1 UPC-A, 100% ......................
  • Page 14 Symbol LS4208 Product Reference Guide Appendix D: Numeric Bar Codes Numeric Bar Codes ...................... D-1 Cancel ........................... D-3 Appendix E: ASCII Character Sets Index Tell Us What You Think...

  • Page 15: About This Guide

    About This Guide Introduction The Symbol LS4208 Product Reference Guide provides general instructions for setting up, operating, maintaining, and troubleshooting the Symbol LS4208 scanner. The scanner includes the following variations of the scanner: • Symbol LS4208-SR: Standard version • Symbol LS4208-PR: PDF417 version Chapter Descriptions •...

  • Page 16: Notational Conventions

    The following documents provide more information for the Symbol LS4208 scanner: • The Symbol LS4208 Quick Reference Guide (p/n 72-69411-xx) provides general information to help the user get started with the scanner. It includes basic operation instructions and start up bar codes.

  • Page 17: Service Information

    About This Guide Service Information If you have a problem using the equipment, contact your facility's technical or systems support. If there is a problem with the equipment, they will contact the Motorola Solutions Global Customer Support Center at: http://www.motorolasolutions.com/support. When contacting Motorola Solutions support, please have the following information available: •...
  • Page 18 Symbol LS4208 Product Reference Guide...

  • Page 19: Chapter 1 Getting Started

    For more information about scanning modes and stacked GS1 DataBar codes, see Scan Pattern on page 4-6 GS1 DataBar on page C-3. NOTE Only the Symbol LS4208-PR version supports PDF417 bar codes and variants. Symbol LS4208 Scanner Figure 1-1...

  • Page 20: Unpacking

    1 - 2 Symbol LS4208 Product Reference Guide This scanner supports the following interfaces: • Keyboard Wedge connection to a host. The host interprets scanned data as keystrokes. This interface ® supports the following international keyboards (for Windows environment): North America, German, French, French Canadian, Spanish, Italian, Swedish, UK English, Portuguese-Brazilian, and Japanese.

  • Page 21: Setting Up The Scanner

    Getting Started 1 - 3 Setting Up the Scanner Installing the Interface Cable To connect the interface cable: Insert the interface cable’s modular connector clip into the cable interface port on the bottom of the scanner handle. (See Figure 1-2.). Gently tug the cable to ensure the connector is properly secured.

  • Page 22: Removing The Interface Cable

    NOTE Refer to the Synapse Interface Guide provided with the Synapse cable for detailed setup instructions. Symbol’s Synapse Smart Cables enable interfacing to a variety of hosts. The appropriate Synapse cable has the built-in intelligence to detect the host to which it is connected.

  • Page 23: Configuring The Scanner

    Getting Started 1 - 5 Configuring the Scanner To configure the scanner, use the bar codes included in this manual, or the 123Scan configuration program. Chapter 4, User Preferences, Chapter 12, Symbologies Chapter 13, Miscellaneous Scanner Options information about programming the scanner using bar code menus. Also see each host-specific chapter to set up a connection to a specific host type.
  • Page 24 1 - 6 Symbol LS4208 Product Reference Guide...

  • Page 25: Chapter 2 Scanning

    Chapter 2 Scanning Introduction This chapter provides beeper and LED definitions, techniques involved in scanning bar codes, general instructions and tips about scanning, and decode zone diagram. Scan Window Beeper Trigger Parts Figure 2-1...

  • Page 26: Beeper Definitions

    Beeper Sequence Indication Standard Use Low/medium/high beeps Power up. Short high beeps A bar code symbol was decoded (if decode beeper is enabled). Clicking Occurs during PDF417 decoding to indicate proper alignment, motion, and distance. 4 long low beeps A transmission error was detected in a scanned symbol.

  • Page 27: Led Definitions

    Scanning 2 - 3 Beeper Definitions (Continued) Table 2-1 Beeper Sequence Indication Host Specific USB only 4 short high beeps Scanner has not completed initialization. Wait several seconds and scan again. Scanner gives a power-up beep after Communication with the bus must be established before the scanning a USB Device Type.

  • Page 28: Scan Patterns

    500 ms after the trigger is pulled. If the scanner detects a PDF417 (Symbol LS4208-PR only), GS1 DataBar, or Composite Code, it immediately rasters, opening to a full, optimized raster pattern as soon as the scanner is properly aligned over the bar code.

  • Page 29: Scanning Modes

    2 - 5 Scanning Modes The Symbol LS4208 accommodates both hand-held and hands-free modes. In hand-held use, you pull the trigger to activate the scan pattern and decode the bar code. In hands-free mode, the scanner sits in the Intellistand and automatically decodes a bar code presented in its field of view.
  • Page 30 Figure 2-7 Regardless of the scan mode, the scan line is smaller when the scanner is closer to the symbol and larger when it is farther from the symbol. Scan symbols with smaller bars or elements (mil size) closer to the scanner, and those with larger bars or elements (mil size) farther from the scanner.
  • Page 31 PDF symbol. For large PDF symbols, you may need to manually raster the scanner in order to cover the entire symbol. If the pattern does not cover the top and bottom of a PDF symbol, pull the scanner back until it does. Make sure the scan pattern extends beyond the edges of the bar code.
  • Page 32 Moving Scan Pattern Upward and Downward on “Tall” PDF Symbol Figure 2-10 Keep the scan pattern parallel to the symbol rows. Upon successful decode, the scanner beeps and the LED turns green. (For more information about beeper and LED definitions, see...

  • Page 33: Scanning In Hands-Free Mode

    Scanning 2 - 9 Scanning in Hands-Free Mode The optional Intellistand adds greater flexibility to scanning operation. When the scanner is seated in the stand’s “cup,” the scanner’s built-in sensor places the scanner in hands-free mode. When the scanner is removed from the stand, it automatically switches modes to operate in its normal hand-held triggered mode.
  • Page 34 2 - 10 Symbol LS4208 Product Reference Guide Scanning with Intellistand When the scanner is placed in the Intellistand, the scan pattern selected in hand-held triggered mode continues (see Scan Pattern on page 4-6). To operate the scanner in Intellistand: Ensure the scanner is properly connected to the host (see the appropriate host chapter for information on host connections).

  • Page 35: Symbol Ls4208 Decode Zone

    ** 6.6 mil PDF417 (3:1) ** 10 mil PDF417 (3:1) 11.75 0.75 50.8 38.1 12.7 25.4 63.5 76.2 Depth of Field * Minimum distance determined by symbol length and scan angle ** LS4208-PR (PDF417) version only Symbol LS4208 Decode Zone Figure 2-14...
  • Page 36 2 - 12 Symbol LS4208 Product Reference Guide...

  • Page 37: Chapter 3 Maintenance, Troubleshooting & Technical Specifications

    Chapter 3 Maintenance, Troubleshooting & Technical Specifications Introduction This chapter provides suggested scanner maintenance, troubleshooting, technical specifications, and signal descriptions (pinouts). Maintenance Cleaning the exit window is the only maintenance required. A dirty window may affect scanning accuracy. • Do not allow any abrasive material to touch the window •...
  • Page 38 3 - 2 Symbol LS4208 Product Reference Guide Troubleshooting Troubleshooting Table 3-1 Problem Possible Causes Possible Solutions Beeper Indications The scanner emits frequent No power to the scanner. Check the system power. If the beeps. configuration requires a power supply, re-connect the power supply.
  • Page 39 See Symbol LS4208 Decode Zone on page 2-11. The scan line is not crossing every Move the symbol until the scan line is within bar and space of the symbol. the acceptable aiming pattern. See Figure 2-6 on page 2-6.
  • Page 40 Interface/power cables are loose. Check for loose cable connections and re-connect cables. NOTE If after performing these checks the symbol still does not scan, contact the distributor or Motorola Enterprise Mobility Support. See page xv for contact information.
  • Page 41 Pitch Tolerance ± 60° Yaw Tolerance ± 60° Nominal Working Distance Symbol LS4208 Decode Zone on page 2-11 Minimum Resolution 5 mil (linear bar codes) 5 mil (uPDF & PDF, 3:1, Y:X aspect ratio) Print Contrast Minimum 25% minimum reflectance Multi-Line Aiming Coverage At 5 in.
  • Page 42 3 - 6 Symbol LS4208 Product Reference Guide Technical Specifications (Continued) Table 3-2 Item Description Interfaces Supported RS-232C (Standard, Nixdorf, ICL, & Fujitsu); IBM 468x/469x; Keyboard Wedge; USB (Standard, IBM SurePOS, Macintosh); Laser/Wand Emulation. Synapse Adaptive Connectivity allows for connectivity to interfaces above and many non-standard interfaces.

  • Page 43: Scanner Signal Descriptions

    Maintenance, Troubleshooting & Technical Specifications 3 - 7 Scanner Signal Descriptions Bottom of scanner Cable interface port PIN 1 PIN 10 Interface cable modular connector Scanner Cable Pin-outs Figure 3-1...
  • Page 44 3 - 8 Symbol LS4208 Product Reference Guide The signal descriptions in Table 3-3 apply to the connector on the scanner and are for reference only. Scanner Signal Pin-outs Table 3-3 Keyboard Synapse RS-232 Wand Wedge Reserved SynClock Reserved Reserved...

  • Page 45: Chapter 4 User Preferences

    Chapter 4 User Preferences Introduction If desired, program the scanner to perform various functions, or activate different features. This chapter describes each user preference feature and provides the programming bar codes necessary for selecting these features. The scanner ships with the settings shown in the User Preferences Default Table on page 4-2 (also see Appendix...

  • Page 46: User Preferences Parameter Defaults

    4 - 2 Symbol LS4208 Product Reference Guide User Preferences Parameter Defaults Table 4-1 lists the defaults for user preferences parameters. To change any option, scan the appropriate bar code(s) provided in the User Preferences section beginning on page 4-3.

  • Page 47: User Preferences

    User Preferences 4 - 3 User Preferences Default Parameters The scanner can be reset to two types of defaults: factory defaults or custom defaults. Scan the appropriate bar code below to reset the scanner to its default settings and/or set the scanner’s current settings as the custom default.

  • Page 48: Parameter Bar Code Scanning

    4 - 4 Symbol LS4208 Product Reference Guide Parameter Bar Code Scanning To disable the decoding of parameter bar codes, including the Set Defaults parameter bar codes, scan the Disable Parameter Scanning bar code below. To enable decoding of parameter bar codes, scan Enable Parameter Scanning.

  • Page 49: Beeper Volume

    User Preferences 4 - 5 Beeper Volume To select a beeper volume, scan the Low Volume, Medium Volume, or High Volume bar code. Low Volume Medium Volume High Volume Power Mode This parameter determines whether or not power remains on after a decode attempt. When in reduced power mode, the scanner enters into a low power consumption mode to preserve battery life after each decode attempt.

  • Page 50: Scan Pattern

    4 - 6 Symbol LS4208 Product Reference Guide Scan Pattern This parameter determines the pattern (mode) of scanning. Scan the appropriate bar code below to set the scanning mode. • Single-line Only - Scan Single-line Only for a single-line scan mode. The laser has no up and down scan line movement (no raster).

  • Page 51: Scan Line Width

    User Preferences 4 - 7 Scan Line Width Scan a bar code below to set the scan line width. Full Width Medium Width Small Width...

  • Page 52: Raster Height

    • Adjustable Raster (default) - This option starts as a short raster, then opens to a tall raster and slows half a second later. Use this option when scanning a variety of symbol heights. Short Raster Tall Raster Adjustable Raster...

  • Page 53: Laser On Time

    User Preferences 4 - 9 Laser On Time This parameter sets the maximum time that decode processing continues during a scan attempt. It is programmable in 0.1 second increments from 0.5 to 9.9 seconds. The default Laser On Time is 3.0 seconds. To set a Laser On Time, scan the bar code below.

  • Page 54: Pdf Decode Feedback

    4 - 10 Symbol LS4208 Product Reference Guide PDF Decode Feedback Scan a bar code below to select whether or not the scanner emits a clicking sound during PDF417 decoding. This clicking helps the user ensure proper alignment, motion, and distance during decoding. The scanner issues a standard decode beep upon successfully decoding the bar code.

  • Page 55: Chapter 5 Keyboard Wedge Interface

    Chapter 5 Keyboard Wedge Interface Introduction This chapter describes how to set up a Keyboard Wedge interface with the scanner. With this interface, the scanner is connected between the keyboard and host computer, and translates bar code data into keystrokes. The host computer accepts the keystrokes as if they originated from the keyboard.

  • Page 56: Connecting A Keyboard Wedge Interface

    5 - 2 Symbol LS4208 Product Reference Guide Connecting a Keyboard Wedge Interface Male DIN Connector Female DIN Connector Keyboard Connector Keyboard Wedge Connection with Y-cable Figure 5-1 To connect the Keyboard Wedge interface Y-cable: NOTE Interface cables vary depending on configuration. The connectors illustrated in...

  • Page 57: Keyboard Wedge Parameter Defaults

    Keyboard Wedge Interface 5 - 3 Keyboard Wedge Parameter Defaults Table 5-1 lists the defaults for Keyboard Wedge host parameters. To change any option, scan the appropriate bar code(s) in the Keyboard Wedge Host Parameters section beginning on page 5-4. NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and...

  • Page 58: Keyboard Wedge Host Parameters

    5 - 4 Symbol LS4208 Product Reference Guide Keyboard Wedge Host Parameters Keyboard Wedge Host Types Select the Keyboard Wedge host by scanning one of the bar codes below. IBM PC/AT & IBM PC Compatibles IBM AT Notebook NCR 7052 NOTE User selection is required to configure this interface and this is the most common selection.

  • Page 59: Keyboard Wedge Country Types (Country Codes)

    Keyboard Wedge Interface 5 - 5 Keyboard Wedge Country Types (Country Codes) Scan the bar code corresponding to the keyboard type. If the keyboard type is not listed, see Alternate Numeric Keypad Emulation on page 5-8. North American German Windows French Windows French Canadian Windows 95/98 French Canadian Windows XP/2000...

  • Page 60: Ignore Unknown Characters

    5 - 6 Symbol LS4208 Product Reference Guide Keyboard Wedge Country Types (continued) Swedish Windows UK English Windows Japanese Windows Portuguese-Brazilian Windows Ignore Unknown Characters Unknown characters are characters the host does not recognize. When Send Bar Codes With Unknown Characters is selected, all bar code data is sent except for unknown characters, and no error beeps sound on the scanner.

  • Page 61: Keystroke Delay

    Keyboard Wedge Interface 5 - 7 Keystroke Delay This is the delay in milliseconds between emulated keystrokes. Scan a bar code below to increase the delay when hosts require a slower transmission of data. No Delay Medium Delay (20 msec) Long Delay (40 msec) Intra-Keystroke Delay When enabled, an additional delay is inserted between each emulated key depression and release.

  • Page 62: Alternate Numeric Keypad Emulation

    5 - 8 Symbol LS4208 Product Reference Guide Alternate Numeric Keypad Emulation This allows emulation of most other country keyboard types not listed in Keyboard Wedge Country Types (Country ® Codes) on page 5-5 in a Microsoft operating system environment.

  • Page 63: Caps Lock Override

    Keyboard Wedge Interface 5 - 9 Caps Lock Override When enabled, on AT or AT Notebook hosts, the keyboard ignores the state of the Caps Lock key. Therefore, an ‘A’ in the bar code is sent as an ‘A’ no matter what the state of the keyboard’s Caps Lock key. Note that if both Caps Lock On and Caps Lock Override are enabled, Caps Lock Override takes precedence.

  • Page 64: Convert Wedge Data

    5 - 10 Symbol LS4208 Product Reference Guide Convert Wedge Data When enabled, the scanner will convert all bar code data to the selected case. Convert to Upper Case Convert to Lower Case No Convert Function Key Mapping ASCII values under 32 are normally sent as control key sequences (see Table 5-2 on page 5-13).

  • Page 65: Fn1 Substitution

    Keyboard Wedge Interface 5 - 11 FN1 Substitution When enabled, the scanner replaces FN1 characters in a GS1-128 bar code with a keystroke chosen by the user (see FN1 Substitution Values on page 13-6). Enable FN1 Substitution *Disable FN1 Substitution Send Make and Break When enabled, the scan codes for releasing a key are not sent.

  • Page 66: Keyboard Maps

    5 - 12 Symbol LS4208 Product Reference Guide Keyboard Maps The following keyboard maps are provided for prefix/suffix keystroke parameters. To program the prefix/suffix values, see the bar codes on page 13-3. 7008 5001 5002 7014 7009 7012 7003 5003...

  • Page 67: Ascii Character Set For Keyboard Wedge

    Keyboard Wedge Interface 5 - 13 ASCII Character Set for Keyboard Wedge NOTE Code 39 Full ASCII interprets the bar code special character ($ + % /) preceding a Code 39 character and assigns an ASCII character value to the pair. For example, when Code 39 Full ASCII is enabled and a +B is scanned, it is interpreted as b, %J as ?, and %V as @.
  • Page 68 5 - 14 Symbol LS4208 Product Reference Guide Keyboard Wedge ASCII Character Set (Continued) Table 5-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1022 CTRL V 1023 CTRL W 1024 CTRL X 1025 CTRL Y 1026 CTRL Z...
  • Page 69 Keyboard Wedge Interface 5 - 15 Keyboard Wedge ASCII Character Set (Continued) Table 5-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065 1066 1067...
  • Page 70 5 - 16 Symbol LS4208 Product Reference Guide Keyboard Wedge ASCII Character Set (Continued) Table 5-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1078 1079 1080 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092...
  • Page 71 Keyboard Wedge Interface 5 - 17 Keyboard Wedge ASCII Character Set (Continued) Table 5-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123 1124 1125...
  • Page 72 5 - 18 Symbol LS4208 Product Reference Guide Keyboard Wedge ALT Key Character Set (Continued) Table 5-3 ALT Keys Keystroke 2070 ALT F 2071 ALT G 2072 ALT H 2073 ALT I 2074 ALT J 2075 ALT K 2076 ALT L...
  • Page 73 Keyboard Wedge Interface 5 - 19 Keyboard Wedge GIU Key Character Set (Continued) Table 5-4 GUI Keys Keystrokes 3054 GUI 6 3055 GUI 7 3056 GUI 8 3057 GUI 9 3065 GUI A 3066 GUI B 3067 GUI C 3068 GUI D 3069 GUI E...
  • Page 74 5 - 20 Symbol LS4208 Product Reference Guide Keyboard Wedge F Key Character Set Table 5-5 F Keys Keystroke 5001 5002 5003 5004 5005 5006 5007 5008 5009 5010 5011 5012 5013 5014 5015 5016 5017 5018 5019 5020 5021...
  • Page 75 Keyboard Wedge Interface 5 - 21 Keyboard Wedge Numeric Keypad Character Set Table 5-6 Numeric Keypad Keystroke 6042 6043 6044 undefined 6045 6046 6047 6048 6049 6050 6051 6052 6053 6054 6055 6056 6057 6058 Enter 6059 Num Lock...
  • Page 76 5 - 22 Symbol LS4208 Product Reference Guide Keyboard Wedge Extended Keypad Character Set Table 5-7 Extended Keypad Keystroke 7001 Break 7002 Delete 7003 Pg Up 7004 7005 Pg Dn 7006 Pause 7007 Scroll Lock 7008 Backspace 7009 7010 Print Screen...

  • Page 77: Chapter 6 Rs-232 Interface

    NOTE The scanner uses TTL RS-232 signal levels, which interface with most system architectures. For system architectures requiring RS-232C signal levels, Symbol offers different cables providing TTL-to-RS-232C conversion. Contact Motorola Enterprise Mobility Support for more information.

  • Page 78: Connecting An Rs-232 Interface

    6 - 2 Symbol LS4208 Product Reference Guide Connecting an RS-232 Interface This connection is made directly from the scanner to the host computer. Interface Cable Serial Port Connector to Host Power Supply Cable RS-232 Direct Connection Figure 6-1 NOTE Interface cables vary depending on configuration. The connectors illustrated in...

  • Page 79: Rs-232 Parameter Defaults

    RS-232 Interface 6 - 3 RS-232 Parameter Defaults Table 6-1 lists the defaults for RS-232 host parameters. If any option needs to be changed, scan the appropriate bar code(s) provided in the Parameter Descriptions section beginning on page 6-4. NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and miscellaneous default parameters.

  • Page 80: Host Parameters

    6 - 4 Symbol LS4208 Product Reference Guide RS-232 Host Parameters Various RS-232 hosts are set up with their own parameter default settings (Table 6-2). Selecting the ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, Olivetti, Omron, or terminal sets the defaults listed below.
  • Page 81 RS-232 Interface 6 - 5 RS-232 Host Parameters (continued) Selecting the ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, OPOS terminal enables the transmission of code ID characters listed in Table 6-3 below. These code ID characters are not programmable and are separate from the Transmit Code ID feature.

  • Page 82: Host Types

    6 - 6 Symbol LS4208 Product Reference Guide RS-232 Host Types To select an RS-232 host interface, scan one of the following bar codes. Standard RS-232 ICL RS-232 Wincor-Nixdorf RS-232 Mode A Wincor-Nixdorf RS-232 Mode B Olivetti ORS4500 Omron OPOS/JPOS...

  • Page 83: Baud Rate

    RS-232 Interface 6 - 7 Baud Rate Baud rate is the number of bits of data transmitted per second. Set the scanner's baud rate to match the baud rate setting of the host device. Otherwise, data may not reach the host device or may reach it in distorted form. Baud Rate 600 Baud Rate 1200 Baud Rate 2400...

  • Page 84: Parity

    6 - 8 Symbol LS4208 Product Reference Guide Parity A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host device requirements. • Select Odd parity and the parity bit value is set to 0 or 1, based on data, to ensure that an odd number of 1 bits are contained in the coded character.

  • Page 85: Stop Bit Select

    RS-232 Interface 6 - 9 Stop Bit Select The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and prepares the receiving device for the next character in the serial data stream. The number of stop bits selected (one or two) depends on the number the receiving terminal is programmed to accommodate.

  • Page 86: Check Receive Errors

    6 - 10 Symbol LS4208 Product Reference Guide Check Receive Errors Select whether or not the parity, framing, and overrun of received characters are checked. The parity value of received characters is verified against the parity parameter selected above. Check For Received Errors...
  • Page 87 RS-232 Interface 6 - 11 • None: Scan the bar code below if no Hardware Handshaking is desired. • Standard RTS/CTS: Scan the bar code below to select Standard RTS/CTS Hardware Handshaking. • RTS/CTS Option 1: When RTS/CTS Option 1 is selected, the scanner asserts RTS before transmitting and ignores the state of CTS.

  • Page 88: Software Handshaking

    6 - 12 Symbol LS4208 Product Reference Guide Software Handshaking This parameter offers control of the data transmission process in addition to, or instead of, that offered by hardware handshaking. There are five options. If Software Handshaking and Hardware Handshaking are both enabled, Hardware Handshaking takes precedence.
  • Page 89 RS-232 Interface 6 - 13 Software Handshaking (continued) None ACK/NAK ACK/NAK with ENQ XON/XOFF...

  • Page 90: Host Serial Response Time-Out

    6 - 14 Symbol LS4208 Product Reference Guide Host Serial Response Time-out This parameter specifies how long the scanner waits for an ACK, NAK, ENQ, XON, or CTS before determining that a transmission error occurred. Minimum: 2 Sec Low: 2.5 Sec Medium: 5 Sec High: 7.5 Sec...

  • Page 91: Rts Line State

    RS-232 Interface 6 - 15 RTS Line State This parameter sets the idle state of the Serial Host RTS line. Scan a bar code below to select Low RTS or High RTS line state. Host: Low RTS Host: High RTS Beep on <BEL>...

  • Page 92: Intercharacter Delay

    6 - 16 Symbol LS4208 Product Reference Guide Intercharacter Delay This parameter specifies the intercharacter delay inserted between character transmissions. Minimum: 0 msec Low: 25 msec Medium: 50 msec High: 75 msec Maximum: 99 msec...

  • Page 93: Nixdorf Beep/Led Options

    RS-232 Interface 6 - 17 Nixdorf Beep/LED Options When Nixdorf Mode B is selected, this indicates when the scanner should beep and turn on its LED after a decode. *Normal Operation (Beep/LED immediately after decode) Beep/LED After Transmission Beep/LED After CTS Pulse Ignore Unknown Characters Unknown characters are characters the host does not recognize.

  • Page 94: Ascii Character Set For Rs-232

    6 - 18 Symbol LS4208 Product Reference Guide ASCII Character Set for RS-232 The values in Table 6-4 can be assigned as prefixes or suffixes for ASCII character data transmission. ASCII Character Set for RS-232 Table 6-4 Full ASCII ASCII Value...
  • Page 95 RS-232 Interface 6 - 19 ASCII Character Set for RS-232 (Continued) Table 6-4 Full ASCII ASCII Value ASCII Character Code 39 Encode Character 1027 1028 1029 1030 1031 1032 Space Space 1033 1034 " 1035 1036 1037 1038 & 1039 ‘...
  • Page 96 6 - 20 Symbol LS4208 Product Reference Guide ASCII Character Set for RS-232 (Continued) Table 6-4 Full ASCII ASCII Value ASCII Character Code 39 Encode Character 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065 1066 1067 1068...
  • Page 97 RS-232 Interface 6 - 21 ASCII Character Set for RS-232 (Continued) Table 6-4 Full ASCII ASCII Value ASCII Character Code 39 Encode Character 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100 1101 1102 1103 1104 1105 1106...
  • Page 98 6 - 22 Symbol LS4208 Product Reference Guide ASCII Character Set for RS-232 (Continued) Table 6-4 Full ASCII ASCII Value ASCII Character Code 39 Encode Character 1117 1118 1119 1120 1121 1122 1123 1124 1125 1126 1127 Undefined 7013 ENTER...

  • Page 99: Chapter 7 Usb Interface

    Chapter 7 USB Interface Introduction This chapter covers the connection and setup of the scanner to a USB host. The scanner attaches directly to a USB host, or a powered USB hub, and is powered by it. No additional power supply is required. Throughout the programming bar code menus, default values are indicated with asterisks ( North American Standard USB Keyboard Indicates Default...

  • Page 100: Connecting A Usb Interface

    7 - 2 Symbol LS4208 Product Reference Guide Connecting a USB Interface Interface cable USB Series A Connector USB Connection Figure 7-1 The scanner connects with USB capable hosts including: • Desktop PCs and Notebooks • Apple™ iMac, G4, iBooks (North America only) •...
  • Page 101 USB Interface 7 - 3 To set up the scanner: NOTE Interface cables vary depending on configuration. The connectors illustrated in Figure 7-1 are examples only. The connectors may be different than those illustrated, but the steps to connect the scanner are the same.

  • Page 102: Usb Parameter Defaults

    7 - 4 Symbol LS4208 Product Reference Guide USB Parameter Defaults Table 7-1 lists the defaults for USB host parameters. If any option needs to be changed, scan the appropriate bar code(s) provided in the Parameter Descriptions section beginning on page 7-5.

  • Page 103: Usb Host Parameters

    USB Interface 7 - 5 USB Host Parameters USB Device Type Select the desired USB device type. NOTE When changing USB Device Types, the scanner automatically restarts. The scanner issues the standard startup beep sequences. HID Keyboard Emulation IBM Table Top USB IBM Hand-Held USB USB OPOS Handheld Simple COM Port Emulation...

  • Page 104: Usb Country Keyboard Types (Country Codes)

    7 - 6 Symbol LS4208 Product Reference Guide USB Country Keyboard Types (Country Codes) Scan the bar code corresponding to the keyboard type. This setting applies only to the USB HID Keyboard Emulation device. When changing USB country keyboard types the scanner automatically resets. The scanner NOTE issues the standard startup beep sequences.
  • Page 105 USB Interface 7 - 7 USB Country Keyboard Types (Country Codes continued) Italian Windows Swedish Windows UK English Windows Japanese Windows (ASCII) Portuguese-Brazilian Windows...

  • Page 106: Usb Keystroke Delay

    7 - 8 Symbol LS4208 Product Reference Guide USB Keystroke Delay This parameter sets the delay, in milliseconds, between emulated keystrokes. Scan a bar code below to increase the delay when hosts require a slower transmission of data. No Delay...

  • Page 107: Usb Ignore Unknown Characters

    USB Interface 7 - 9 USB Ignore Unknown Characters This option applies only to the HID Keyboard Emulation device and IBM device. Unknown characters are characters the host does not recognize. When Send Bar Codes With Unknown Characters is selected, all bar code data is sent except for unknown characters, and no error beeps sound.

  • Page 108: Usb Keyboard Fn 1 Substitution

    7 - 10 Symbol LS4208 Product Reference Guide USB Keyboard FN 1 Substitution This option applies only to the USB HID Keyboard Emulation device. When enabled, this allows replacement of any FN 1 characters in a GS1-128 bar code with a Key Category and value chosen by the user (see Substitution Values on page 13-6 to set the Key Category and Key Value).

  • Page 109: Simulated Caps Lock

    USB Interface 7 - 11 Simulated Caps Lock When enabled, the scanner will invert upper and lower case characters on the scanner bar code as if the Caps Lock state is enabled on the keyboard. This inversion is done regardless of the current state of the keyboard’s Caps Lock state.

  • Page 110: Ascii Character Set For Usb

    7 - 12 Symbol LS4208 Product Reference Guide ASCII Character Set for USB ASCII Character Set for USB Table 7-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1000 CTRL 2 1001 CTRL A 1002 CTRL B 1003 CTRL C...
  • Page 111 USB Interface 7 - 13 ASCII Character Set for USB (Continued) Table 7-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1025 CTRL Y 1026 CTRL Z 1027 CTRL [/ESC 1028 CTRL \ 1029 CTRL ] 1030 CTRL 6 1031 CTRL - 1032...
  • Page 112 7 - 14 Symbol LS4208 Product Reference Guide ASCII Character Set for USB (Continued) Table 7-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1053 1054 1055 1056 1057 1058 1059 1060 < 1061 1062 > 1063 1064 1065...
  • Page 113 USB Interface 7 - 15 ASCII Character Set for USB (Continued) Table 7-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1081 1082 1083 1084 1085 1086 1087 1088 1089 1090 1091 1092 1093 1094 1095 1096 1097 1098 1099 1100 1101...
  • Page 114 7 - 16 Symbol LS4208 Product Reference Guide ASCII Character Set for USB (Continued) Table 7-2 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118 1119 1120 1121 1122 1123...
  • Page 115 USB Interface 7 - 17 USB ALT Key Character Set Table 7-3 ALT Keys Keystroke 2064 ALT 2 2065 ALT A 2066 ALT B 2067 ALT C 2068 ALT D 2069 ALT E 2070 ALT F 2071 ALT G 2072 ALT H 2073 ALT I...
  • Page 116 7 - 18 Symbol LS4208 Product Reference Guide USB GUI Key Character Set Table 7-4 GUI Key Keystroke 3000 Right Control Key 3048 GUI 0 3049 GUI 1 3050 GUI 2 3051 GUI 3 3052 GUI 4 3053 GUI 5...
  • Page 117 USB Interface 7 - 19 USB GUI Key Character Set (Continued) Table 7-4 GUI Key Keystroke 3081 GUI Q 3082 GUI R 3083 GUI S 3084 GUI T 3085 GUI U 3086 GUI V 3087 GUI W 3088 GUI X 3089 GUI Y 3090...
  • Page 118 7 - 20 Symbol LS4208 Product Reference Guide USB F Key Character Set (Continued) Table 7-5 F Keys Keystroke 5016 5017 5018 5019 5020 5021 5022 5023 5024 USB Numeric Keypad Character Set Table 7-6 Numeric Keypad Keystroke 6042 6043...
  • Page 119 USB Interface 7 - 21 USB Extended Keypad Character Set Table 7-7 Extended Keypad Keystroke 7001 Break 7002 Delete 7003 PgUp 7004 7005 Pg Dn 7006 Pause 7007 Scroll Lock 7008 Backspace 7009 7010 Print Screen 7011 Insert 7012 Home 7013 Enter 7014...
  • Page 120 7 - 22 Symbol LS4208 Product Reference Guide...

  • Page 121: Chapter 8 Ibm Interface

    Chapter 8 IBM Interface Introduction This chapter describes how to set up the scanner with an IBM 468X/469X host. Throughout the programming bar code menus, default values are indicated with asterisks ( Disable Convert to Code 39 Feature/Option Indicates Default...

  • Page 122: Connecting To An Ibm 468X/469X Host

    8 - 2 Symbol LS4208 Product Reference Guide Connecting to an IBM 468X/469X Host This connection is made directly from the scanner to the host interface. Interface cable Host Port Connector IBM Direct Connection Figure 8-1 NOTE Interface cables vary depending on configuration. The connectors illustrated in...

  • Page 123: Ibm Parameter Defaults

    IBM Interface 8 - 3 IBM Parameter Defaults Table 8-1 lists the defaults for IBM host parameters. To change any option, scan the appropriate bar code(s) provided in the Parameter Descriptions section beginning on page 8-4. NOTE See Appendix A, Standard Default Parameters for all user preferences, hosts, symbologies, and miscellaneous default parameters.

  • Page 124: Ibm 468X/469X Host Parameters

    8 - 4 Symbol LS4208 Product Reference Guide IBM 468X/469X Host Parameters Port Address This parameter sets the IBM 468X/469X port used. Scanning one of these bar codes enables the RS-485 interface on the scanner. NOTE None Selected Hand-held Scanner Emulation (Port 9B)

  • Page 125: Convert Unknown To Code 39

    IBM Interface 8 - 5 Convert Unknown to Code 39 Scan a bar code below to enable or disable the conversion of unknown bar code type data to Code 39. Enable Convert Unknown to Code 39 Disable Convert Unknown to Code 39...

  • Page 126: Optional Ibm Parameters

    8 - 6 Symbol LS4208 Product Reference Guide Optional IBM Parameters If you configure the scanner and find the settings were not saved, or changed, when the system is restarted scan the bar codes that follow to override IBM interface defaults.

  • Page 127: Chapter 9 Wand Emulation Interface

    Chapter 9 Wand Emulation Interface Introduction This chapter describes how to set up the scanner with a wand emulation host when Wand Emulation communication is needed. The scanner connects to an external wand decoder or to a decoder integrated in a mobile computer or Point-of-Sale (POS) terminal.

  • Page 128: Connecting Using Wand Emulation

    9 - 2 Symbol LS4208 Product Reference Guide Connecting Using Wand Emulation To perform Wand Emulation, connect the scanner to a portable data terminal, or a controller which collects the wand data and interprets it for the host. Mobile Computer...

  • Page 129: Wand Emulation Parameter Defaults

    Wand Emulation Default Table Table 9-1 Page Parameter Default Number Wand Emulation Host Parameters Wand Emulation Host Types Symbol OmniLink Interface Controller Leading Margin 80 msec Polarity Bar High/Margin Low Ignore Unknown Characters Send Convert All Bar Codes to Code 39...

  • Page 130: Wand Emulation Host Parameters

    9 - 4 Symbol LS4208 Product Reference Guide Wand Emulation Host Parameters Wand Emulation Host Types Select a Wand Emulation host by scanning one of the bar codes below. Symbol OmniLink Interface Controller Symbol PDT Terminal (MSI) Symbol PTC Terminal (Telxon) NOTE User selection is required to configure this interface and this is the most common selection.

  • Page 131: Leading Margin (Quiet Zone)

    Wand Emulation Interface 9 - 5 Leading Margin (Quiet Zone) Scan a bar code below to select a leading margin duration. A leading margin is the time that precedes the first bar of the scan, (in milliseconds). The minimum allowed value is 80 msec and the maximum is 250 msec. This parameter accommodates older wand decoders which cannot handle short leading margins.

  • Page 132: Polarity

    9 - 6 Symbol LS4208 Product Reference Guide Polarity Scan a bar code below to select the polarity required by the decoder. Polarity determines how the scanner's Wand Emulation interface creates the Digitized Barcode Pattern (DBP). DBP is a digital signal that represents the scanned bar code.

  • Page 133: Convert All Bar Codes To Code 39

    Wand Emulation Interface 9 - 7 Convert All Bar Codes to Code 39 By default, the Wand Emulation interface sends data to the attached host in the same symbology that was decoded. This can be a problem for customers with older systems that do not recognize newer symbologies (for example, GS1 DataBar).

  • Page 134: Convert Code 39 To Full Ascii

    9 - 8 Symbol LS4208 Product Reference Guide Convert Code 39 to Full ASCII By default, any characters that do not have a corresponding character in the Code 39 symbology set are replaced by a space. If this parameter is enabled, the data sent to the wand interface is encoded in Code 39 Full ASCII. This setting requires that the host be able to interpret Code 39 Full ASCII data.

  • Page 135: Chapter 10 Scanner Emulation Interface

    Chapter 10 Scanner Emulation Interface Introduction This chapter describes how to set up the scanner with a Scanner Emulation host. Use this mode when Scanner Emulation communication is needed. In this mode, the scanner connects to an external decoder or to a decoder integrated in a mobile computer or Point-of-Sale (POS) terminal.

  • Page 136: Connecting Using Scanner Emulation

    10 - 2 Symbol LS4208 Product Reference Guide Connecting Using Scanner Emulation To perform Scanner Emulation, connect the scanner to a mobile computer, or a controller which collects the data and interprets it for the host. Interface Cable Host Port...

  • Page 137: Scanner Emulation Parameter Defaults

    Scanner Emulation Interface 10 - 3 Scanner Emulation Parameter Defaults Table 10-1 lists the defaults for the Scanner Emulation host. To change any option, scan the appropriate bar code(s) provided in the Scanner Emulation Host Parameters section beginning on page 10-4.

  • Page 138: Scanner Emulation Host

    10 - 4 Symbol LS4208 Product Reference Guide Scanner Emulation Host Scan the bar code below to enable the Scanner Emulation host. Undecoded Scanner Emulation Host Scanner Emulation Host Parameters Beep Style The Scanner Emulation host supports three beep styles.

  • Page 139: Parameter Pass-Through

    The Scanner Emulation host can process parameter bar code messages and send them to the attached decoder. In this way, customers using Symbol compliant decoders can control the behavior of the entire system by scanning the necessary parameters only once.

  • Page 140: Convert Newer Code Types

    10 - 6 Symbol LS4208 Product Reference Guide Convert Newer Code Types The scanner supports a variety of code types that are not decodable by attached decoder systems. To allow compatibility in these environments, the scanner converts these code types to more commonly decodable symbologies, as per the following chart.

  • Page 141: Module Width

    Scanner Emulation Interface 10 - 7 Module Width The standard module width is 20 µs. For an extremely slow decoder system, select 50 µs Module Width. 20 µs Module Width 50 µs Module Width Convert All Bar Codes to Code 39 Scan the bar code below to enable or disable the conversion of all bar code data to Code 39.

  • Page 142: Code 39 Full Ascii Conversion

    10 - 8 Symbol LS4208 Product Reference Guide Code 39 Full ASCII Conversion By default, any characters that do not have a corresponding character in the Code 39 symbology set are replaced by a space. If this parameter is enabled, the data sent to the Scanner Emulation host is encoded in Code 39 Full ASCII.

  • Page 143: Transmission Timeout

    Scanner Emulation Interface 10 - 9 Transmission Timeout The Scanner Emulation host transmits bar code data to the attached decoder and waits for the decoder to assert the Decode signal, indicating successful transmission. If, after a specified amount of time, the Decode signal is not asserted (indicating that the attached decoder has not successfully received the bar code data), the scanner issues transmit error beeps.

  • Page 144: Ignore Unknown Characters

    10 - 10 Symbol LS4208 Product Reference Guide Ignore Unknown Characters Unknown characters are characters the decoder does not recognize. When Ignore Unknown Characters is selected, all bar code data is sent except for unknown characters, and no error beeps sound. When Convert Error on Unknown Characters is selected, bar codes containing at least one unknown character are not sent to the decoder, and a convert error beep sounds.

  • Page 145: Check For Decode Led

    Scanner Emulation Interface 10 - 11 Leading Margin (continued) 5 ms Leading Margin 10 ms Leading Margin Check For Decode LED The attached decoder normally asserts the Decode line to signal to the Scanner Emulation host that it successfully decoded the transmitted bar code. Some decoders, however, do not assert the Decode signal. In this case, the scanner emits transmit error beeps to indicate that the bar code was not successfully transmitted.
  • Page 146 10 - 12 Symbol LS4208 Product Reference Guide...

  • Page 147: Chapter 11 123Scan

    Chapter 11 123Scan Introduction 123Scan² is an easy-to-use, PC-based software tool that enables the quick and easy setup of Motorola scanners. 123Scan² uses a wizard tool to guide users through a streamlined set up process. Once parameters are set, the values are saved to a configuration file that can be distributed via e-mail, electronically downloaded via a USB or RS-232 cable, or used to generate a sheet of programming bar codes that can be scanned.

  • Page 148: 123Scan2 Requirements

    11 - 2 Symbol LS4208 Product Reference Guide 123Scan2 Requirements • Host computer with Windows XP SP2 or Windows 7 • Scanner • Cradle (cordless scanning only) • USB cable. For more information on 123Scan², go to: http://www.motorolasolutions.com/123Scan For a one minute tour of 123Scan², go to: http://www.motorolasolutions.com/scannerhowtovideos...
  • Page 149 123Scan 11 - 3 Scanner SDK, Other Software Tools, and Videos Tackle all your scanner programming needs with our diversified set of software tools. Whether you need to simply stage a device, or develop a fully featured application with image and data capture as well as asset management, these tools help you every step of the way.
  • Page 150 11 - 4 Symbol LS4208 Product Reference Guide...

  • Page 151: Chapter 12 Symbologies

    Chapter 12 Symbologies Introduction This chapter describes symbology features and provides the programming bar codes for selecting these features. Before programming, follow the instructions in Chapter 1, Getting Started. The scanner is shipped with the settings shown in Table 12-1 on page 12-2 (also see Appendix A, Standard Default Parameters...

  • Page 152: Errors While Scanning

    12 - 2 Symbol LS4208 Product Reference Guide Errors While Scanning Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter. Symbology Parameter Defaults Table 12-1 lists the defaults for all symbologies parameters. To change any option, scan the appropriate bar...
  • Page 153 Symbologies 12 - 3 Symbology Parameter Defaults (Continued) Table 12-1 Page Parameter Default Number UCC Coupon Extended Code Disable 12-22 Code 128 Code 128 Enable 12-23 GS1-128 (formerly UCC/EAN-128) Enable 12-23 ISBT 128 (non-concatenated) Enable 12-24 Code 39 Code 39 Enable 12-25 Trioptic Code 39...
  • Page 154 12 - 4 Symbol LS4208 Product Reference Guide Symbology Parameter Defaults (Continued) Table 12-1 Page Parameter Default Number Discrete 2 of 5 (DTF) Discrete 2 of 5 Disable 12-44 Set Length(s) for D 2 of 5 12-44 Chinese 2 of 5...
  • Page 155 Symbologies 12 - 5 Symbology Parameter Defaults (Continued) Table 12-1 Page Parameter Default Number Character Escape Character None 12-58 Delete Character Set ECI’s Transmit 12-59 Composite Composite CC-C Disable 12-60 Composite CC-A/B Disable 12-60 UPC Composite Mode UPC Always Linked 12-61 Composite Beep Mode Beep as Each Code...

  • Page 156: Upc/Ean

    12 - 6 Symbol LS4208 Product Reference Guide UPC/EAN Enable/Disable UPC-A/UPC-E To enable or disable UPC-A or UPC-E, scan the appropriate bar code below. Enable UPC-A Disable UPC-A Enable UPC-E Disable UPC-E...

  • Page 157: Enable/Disable Upc-E1

    Symbologies 12 - 7 Enable/Disable UPC-E1 UPC-E1 is disabled by default. To enable or disable UPC-E1, scan the appropriate bar code below. NOTE UPC-E1 is not a UCC (Uniform Code Council) approved symbology. Enable UPC-E1 Disable UPC-E1...

  • Page 158: Enable/Disable Ean-13/Ean

    12 - 8 Symbol LS4208 Product Reference Guide Enable/Disable EAN-13/EAN-8 To enable or disable EAN-13 or EAN-8, scan the appropriate bar code below. Enable EAN-13 Disable EAN-13 Enable EAN-8 Disable EAN-8...

  • Page 159: Enable/Disable Bookland Ean

    If you select one of the following Supplemental Mode options, the scanner immediately transmits EAN-13 bar codes starting with that prefix that have supplemental characters. If the symbol does not have a supplemental, the scanner must decode the bar code the number of times set via...
  • Page 160 12 - 10 Symbol LS4208 Product Reference Guide • Enable 977 Supplemental Mode • Enable 414/419/434/439 Supplemental Mode • Enable 491 Supplemental Mode • Enable Smart Supplemental Mode - applies to EAN-13 bar codes starting with any prefix listed previously.
  • Page 161 Symbologies 12 - 11 Decode UPC/EAN/JAN Supplementals (continued) Ignore UPC/EAN/JAN With Supplementals Decode UPC/EAN/JAN Only With Supplementals Autodiscriminate UPC/EAN/JAN Supplementals Enable 378/379 Supplemental Mode Enable 978/979 Supplemental Mode Enable 977 Supplemental Mode...
  • Page 162 12 - 12 Symbol LS4208 Product Reference Guide Decode UPC/EAN/JAN Supplementals (continued) Enable 414/419/434/439 Supplemental Mode Enable 491 Supplemental Mode Enable Smart Supplemental Mode Supplemental User-Programmable Type 1 Supplemental User-Programmable Type 1 and 2...
  • Page 163 Symbologies 12 - 13 Decode UPC/EAN/JAN Supplementals (continued) Smart Supplemental Plus User-Programmable 1 Smart Supplemental Plus User-Programmable 1 and 2 Supplemental User-Programmable 1 Supplemental User-Programmable 2...

  • Page 164: Upc/Ean/Jan Supplemental Redundancy

    Transmit UPC-A Check Digit The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-A check digit. It is always verified to guarantee the integrity of the data.

  • Page 165: Transmit Upc-E Check Digit

    Transmit UPC-E Check Digit The check digit is the last character of the symbol used to verify the integrity of the data. Scan the appropriate bar code below to transmit the bar code data with or without the UPC-E check digit. It is always verified to guarantee the integrity of the data.

  • Page 166: Upc-A Preamble

    12 - 16 Symbol LS4208 Product Reference Guide UPC-A Preamble Preamble characters are part of the UPC symbol consisting of Country Code and System Character. Three options are given for transmitting UPC-A preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0”...

  • Page 167: Upc-E Preamble

    Symbologies 12 - 17 UPC-E Preamble Preamble characters are part of the UPC symbol consisting of Country Code and System Character. Three options are given for transmitting UPC-E preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0” for USA), and no preamble transmitted. Scan a bar code below to match the host system.

  • Page 168: Upc-E1 Preamble

    12 - 18 Symbol LS4208 Product Reference Guide UPC-E1 Preamble Preamble characters are part of the UPC symbol consisting of Country Code and System Character. Three options are given for transmitting UPC-E1 preamble to the host device: transmit System Character only, transmit System Character and Country Code (“0”...

  • Page 169: Convert Upc-E To Upc-A

    Symbologies 12 - 19 Convert UPC-E to UPC-A Enable this to convert UPC-E (zero suppressed) decoded data to UPC-A format before transmission. After conversion, the data follows UPC-A format and is affected by UPC-A programming selections (e.g., Preamble, Check Digit). When disabled, UPC-E decoded data is transmitted as UPC-E data, without conversion.

  • Page 170: Ean-8/Jan-8 Extend

    12 - 20 Symbol LS4208 Product Reference Guide EAN-8/JAN-8 Extend When enabled, this parameter adds five leading zeros to decoded EAN-8 symbols to make them compatible in format to EAN-13 symbols. When disabled, EAN-8 symbols are transmitted as is. Enable EAN/JAN Zero Extend...

  • Page 171: Bookland Isbn Format

    Symbologies 12 - 21 Bookland ISBN Format If you enabled Bookland EAN using Enable/Disable Bookland EAN on page 12-9, select one of the following formats for Bookland data: • Bookland ISBN-10 - The scanner reports Bookland data starting with 978 in traditional 10-digit format with the special Bookland check digit for backward-compatibility.

  • Page 172: Ucc Coupon Extended Code

    12 - 22 Symbol LS4208 Product Reference Guide UCC Coupon Extended Code When enabled, this parameter decodes UPCA bar codes starting with digit ‘5’, EAN-13 bar codes starting with digit ‘99’, and UPCA/GS1-128 Coupon Codes. UPCA, EAN-13 and GS1-128 must be enabled to scan all types of Coupon Codes.

  • Page 173: Code 128

    Symbologies 12 - 23 Code 128 Enable/Disable Code 128 To enable or disable Code 128, scan the appropriate bar code below. Enable Code 128 Disable Code 128 Enable/Disable GS1-128 (formerly UCC/EAN-128) To enable or disable GS1-128, scan the appropriate bar code below. Enable GS1-128 Disable GS1-128...

  • Page 174: Enable/Disable Isbt 128

    12 - 24 Symbol LS4208 Product Reference Guide Enable/Disable ISBT 128 ISBT 128 is a variant of Code 128 used in the blood bank industry. Scan the appropriate bar code below to enable or disable ISBT 128. If necessary, the host must perform concatenation of the ISBT data.

  • Page 175: Code 39

    Symbologies 12 - 25 Code 39 Enable/Disable Code 39 To enable or disable Code 39, scan the appropriate bar code below. Enable Code 39 Disable Code 39 Enable/Disable Trioptic Code 39 Trioptic Code 39 is a variant of Code 39 used in the marking of computer tape cartridges. Trioptic Code 39 symbols always contain six characters.

  • Page 176: Convert Code 39 To Code 32

    12 - 26 Symbol LS4208 Product Reference Guide Convert Code 39 to Code 32 Code 32 is a variant of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable converting Code 39 to Code 32.

  • Page 177: Set Lengths For Code 39

    Cancel on page D-3. • Length Within Range - Select this option to decode a Code 39 symbol with a specific length range. Select lengths using numeric bar codes in Appendix D, Numeric Bar Codes. For example, to decode Code 39 symbols containing between 4 and 12 characters, first scan Code 39 - Length Within Range.

  • Page 178: Code 39 Check Digit Verification

    12 - 28 Symbol LS4208 Product Reference Guide Set Lengths for Code 39 Code 39 - One Discrete Length Code 39 - Two Discrete Lengths Code 39 - Length Within Range Code 39 - Any Length Code 39 Check Digit Verification When this feature is enabled, the scanner checks the integrity of all Code 39 symbols to verify that the data complies with specified check digit algorithm.

  • Page 179: Transmit Code 39 Check Digit

    Symbologies 12 - 29 Transmit Code 39 Check Digit Scan the appropriate bar code below to transmit Code 39 data with or without the check digit. Transmit Code 39 Check Digit (Enable) Do Not Transmit Code 39 Check Digit (Disable) NOTE Code 39 Check Digit Verification must be enabled for this parameter to function.

  • Page 180: Code 39 Full Ascii Conversion

    12 - 30 Symbol LS4208 Product Reference Guide Code 39 Full ASCII Conversion Code 39 Full ASCII is a variant of Code 39 which pairs characters to encode the full ASCII character set. To enable or disable Code 39 Full ASCII, scan the appropriate bar code below.

  • Page 181: Code 39 Buffering (Scan & Store)

    The leading space is not buffered. Decode of a valid Code 39 symbol with no leading space causes transmission in sequence of all buffered data in a first-in first-out format, plus transmission of the “triggering” symbol. See the following pages for further details.
  • Page 182 12 - 32 Symbol LS4208 Product Reference Guide Clear Transmission Buffer To clear the transmission buffer, scan the Clear Buffer bar code below, which contains only a start character, a dash (minus), and a stop character. • The scanner issues a short high/low/high beep.
  • Page 183 Symbologies 12 - 33 Overfilling Transmission Buffer The Code 39 buffer holds 200 characters. If the symbol just read results in an overflow of the transmission buffer: • The scanner indicates that the symbol was rejected by issuing three long, high beeps.

  • Page 184: Code 93

    Cancel on page D-3. • Length Within Range - Select this option to decode a Code 93 symbol with a specific length range. Select lengths using the numeric bar codes in Appendix D, Numeric Bar Codes. For example, to decode Code 93 symbols containing between 4 and 12 characters, first scan Code 93 - Length Within Range.

  • Page 185: Set Lengths For Code 93

    Symbologies 12 - 35 Set Lengths for Code 93 (continued) Code 93 - One Discrete Length Code 93 - Two Discrete Lengths Code 93 - Length Within Range Code 93 - Any Length...

  • Page 186: Code 11

    Cancel on page D-3. • Length Within Range - Select this option to decode a Code 11 symbol with a specific length range. Select lengths using numeric bar codes in Appendix D, Numeric Bar Codes. For example, to decode Code 11 symbols containing between 4 and 12 characters, first scan Code 11 - Length Within Range.

  • Page 187: Set Lengths For Code 11

    Symbologies 12 - 37 Set Lengths for Code 11 (continued) Code 11 - One Discrete Length Code 11 - Two Discrete Lengths Code 11 - Length Within Range Code 11 - Any Length...

  • Page 188: Code 11 Check Digit Verification

    12 - 38 Symbol LS4208 Product Reference Guide Code 11 Check Digit Verification This feature allows the scanner to check the integrity of all Code 11 symbols to verify that the data complies with the specified check digit algorithm. This selects the check digit mechanism for the decoded Code 11 bar code. The options are to check for one check digit, check for two check digits, or disable the feature.

  • Page 189: Transmit Code 11 Check Digits

    Symbologies 12 - 39 Transmit Code 11 Check Digits This feature selects whether or not to transmit the Code 11 check digit(s). Transmit Code 11 Check Digit(s) (Enable) Do Not Transmit Code 11 Check Digit(s) (Disable) NOTE Code 11 Check Digit Verification must be enabled for this parameter to function.

  • Page 190: Interleaved 2 Of 5 (Itf)

    D-3. • Length Within Range - Select this option to decode an I 2 of 5 symbol with a specific length range. Select lengths using numeric bar codes in Appendix D, Numeric Bar Codes. For example, to decode I 2 of 5 symbols containing between 4 and 12 characters, first scan I 2 of 5 - Length Within Range.

  • Page 191: Set Lengths For Interleaved 2 Of 5

    Symbologies 12 - 41 Set Lengths for Interleaved 2 of 5 (continued) I 2 of 5 - One Discrete Length I 2 of 5 - Two Discrete Lengths I 2 of 5 - Length Within Range I 2 of 5 - Any Length...

  • Page 192: I 2 Of 5 Check Digit Verification

    12 - 42 Symbol LS4208 Product Reference Guide I 2 of 5 Check Digit Verification When this feature is enabled, the scanner checks the integrity of all I 2 of 5 symbols to verify the data complies with either the specified Uniform Symbology Specification (USS), or the Optical Product Code Council (OPCC) check digit algorithm.

  • Page 193: Transmit I 2 Of 5 Check Digit

    Symbologies 12 - 43 Transmit I 2 of 5 Check Digit Scan the appropriate bar code below to transmit I 2 of 5 data with or without the check digit. Transmit I 2 of 5 Check Digit (Enable) Do Not Transmit I 2 of 5 Check Digit (Disable) Convert I 2 of 5 to EAN-13 Enable this parameter to convert 14-character I 2 of 5 codes to EAN-13, and transmit to the host as EAN-13.

  • Page 194: Discrete 2 Of 5 (Dtf)

    D-3. • Length Within Range - Select this option to decode a D 2 of 5 symbol with a specific length range. Select lengths using numeric bar codes in Appendix D, Numeric Bar Codes. For example, to decode D 2 of 5 symbols containing between 4 and 12 characters, first scan D 2 of 5 - Length Within Range.

  • Page 195: Set Lengths For Discrete 2 Of 5

    Symbologies 12 - 45 Set Lengths for Discrete 2 of 5 (continued) D 2 of 5 - One Discrete Length D 2 of 5 - Two Discrete Lengths D 2 of 5 - Length Within Range D 2 of 5 - Any Length...

  • Page 196: Chinese 2 Of 5

    12 - 46 Symbol LS4208 Product Reference Guide Chinese 2 of 5 Enable/Disable Chinese 2 of 5 To enable or disable Chinese 2 of 5, scan the appropriate bar code below. Enable Chinese 2 of 5 Disable Chinese 2 of 5...

  • Page 197: Codabar (Nw - 7)

    Cancel on page D-3. • Length Within Range - Select this option to decode a Codabar symbol with a specific length range. Select lengths using numeric bar codes in Appendix D, Numeric Bar Codes. For example, to decode Codabar symbols containing between 4 and 12 characters, first scan Codabar - Length Within Range.
  • Page 198 12 - 48 Symbol LS4208 Product Reference Guide Set Lengths for Codabar (continued). Codabar - One Discrete Length Codabar - Two Discrete Lengths Codabar - Length Within Range Codabar - Any Length...

  • Page 199: Clsi Editing

    When enabled, this parameter strips the start and stop characters and inserts a space after the first, fifth, and tenth characters of a 14-character Codabar symbol. Enable this feature if your host system requires this data format. NOTE Symbol length does not include start and stop characters.

  • Page 200: Msi

    0, 2, 1, and then 4. To correct an error or to change the selection, scan Cancel on page D-3. • Length Within Range - Select this option to decode a MSI symbol with a specific length range. Select lengths using numeric bar codes in Appendix D, Numeric Bar Codes. For example, to decode MSI symbols containing between 4 and 12 characters, first scan MSI - Length Within Range.

  • Page 201: Msi Check Digits

    Symbologies 12 - 51 Set Lengths for MSI (continued) MSI - One Discrete Length MSI - Two Discrete Lengths MSI - Length Within Range MSI - Any Length MSI Check Digits With MSI symbols, one check digit is mandatory and always verified by the reader. The second check digit is optional.

  • Page 202: Transmit Msi Check Digit(S)

    12 - 52 Symbol LS4208 Product Reference Guide Transmit MSI Check Digit(s) Scan the appropriate bar code below to transmit MSI data with or without the check digit. Transmit MSI Check Digit(s) (Enable) Do Not Transmit MSI Check Digit(s) (Disable) MSI Check Digit Algorithm Two algorithms are possible for the verification of the second MSI check digit.

  • Page 203: Gs1 Databar (Formerly Rss - Reduced Space Symbology)

    Symbologies 12 - 53 GS1 DataBar (formerly RSS - Reduced Space Symbology) The variants of GS1 DataBar are DataBar-14, GS1 DataBar Expanded and GS1 DataBar Limited. GS1 DataBar 14 and GS1 DataBar Expanded include stacked versions. Scan the appropriate bar code below to enable or disable each variant of GS1 DataBar.

  • Page 204: Convert Gs1 Databar To Upc/Ean

    This parameter only applies to GS1 DataBar-14 and GS1 DataBar Limited symbols not decoded as part of a Composite symbol. Enable this to strip the leading '010' from GS1 DataBar-14 and GS1 DataBar Limited symbols encoding a single zero as the first digit, and report the bar code as EAN-13.

  • Page 205: Pdf417/Micropdf417

    Symbologies 12 - 55 PDF417/MicroPDF417 Enable/Disable PDF417 NOTE PDF417 is enabled by default for the Symbol LS4208-PR (PDF417 version) scanner only. *Enable PDF417 Disable PDF417 Enable/Disable MicroPDF417 Enable MicroPDF417 Disable MicroPDF417...

  • Page 206: Micropdf Performance

    12 - 56 Symbol LS4208 Product Reference Guide MicroPDF Performance If your scanner is having trouble decoding MicroPDF symbols, select Selective Performance. Note that this may decrease decoding aggressiveness on some symbols. *Standard Performance for MicroPDF Selective Performance for MicroPDF...

  • Page 207: Transmit Symbols In Codeword Format

    Transmit Symbols in Codeword Format Enabling this activates transmission of each PDF symbol as directly decoded data codewords, whether that symbol is part of a macro PDF sequence or not. Note that data is output as codeword values — not as interpreted data.

  • Page 208: Transmit Unknown Codewords

    12 - 58 Symbol LS4208 Product Reference Guide Transmit Unknown Codewords This enables using the output codeword format for transmitting any non-GLI or non-macro PDF codeword. If this is not enabled and an unknown codeword is found, a decode error beep sounds.

  • Page 209: Delete Character Set Ecis

    Symbologies 12 - 59 Delete Character Set ECIs This parameter enables the scanner to delete any escape sequences representing Character Set ECIs (also known as GLIs) from its buffer before transmission. In many receiving systems, Character Set ECIs can be removed without affecting the way data is displayed or processed.

  • Page 210: Composite Codes

    1D symbology. For example, to allow all CC-A/B types, enable UPC-A, UPC-E, EAN-8, EAN-13, GS1-128, GS1 DataBar-14, GS1 DataBar-14 Limited and GS1 DataBar-14 Expanded. Disabling any of these prevents that type of CC-A symbol from being decoded. Enable CC-A/B...

  • Page 211: Upc Composite Mode

    Symbologies 12 - 61 UPC Composite Mode UPC symbols can be “linked” with a 2D symbol during transmission as if they were one symbol. Three options are offered for these symbols: • If UPC Never Linked is selected, UPC bar codes are transmitted regardless of whether a 2D symbol is detected.

  • Page 212: Composite Beep Mode

    12 - 62 Symbol LS4208 Product Reference Guide Composite Beep Mode To select the number of decode beeps when a composite bar code is decoded, scan the appropriate bar code. Single Beep After Both are Decoded *Beep as Each Code Type is Decoded...

  • Page 213: Symbology - Specific Security Levels

    Symbologies 12 - 63 Symbology - Specific Security Levels Redundancy Level The scanner offers four levels of decode redundancy. Select higher redundancy levels for decreasing levels of bar code quality. As redundancy levels increase, the scanner’s aggressiveness decreases. Select the redundancy level appropriate for the bar code quality. Redundancy Level 1 The following code types must be successfully read twice before being decoded: Code Type...
  • Page 214 12 - 64 Symbol LS4208 Product Reference Guide Redundancy Level (continued) *Redundancy Level 1 Redundancy Level 2 Redundancy Level 3 Redundancy Level 4...

  • Page 215: Security Level

    Symbologies 12 - 65 Security Level The scanner offers four levels of decode security for delta bar codes, which include the Code 128 family, UPC/EAN, and Code 93. Select increasing levels of security for decreasing levels of bar code quality. There is an inverse relationship between security and scanner aggressiveness, so choose only that level of security necessary for any given application.

  • Page 216: Bi-Directional Redunda\Ncy

    The Code 39 and Codabar symbologies have an intercharacter gap that is customarily quite small. Due to various bar code printing technologies, this gap may grow larger than the maximum size allowed, causing the scanner to be unable to decode the symbol. If this problem is encountered, scan Large Intercharacter Gaps to tolerate out-of-specification bar codes.

  • Page 217: Chapter 13 Miscellaneous Scanner Options

    Chapter 13 Miscellaneous Scanner Options Introduction This chapter includes commonly used bar codes to customize how data is transmitted to the host device. Refer to the Advanced Data Formatting Programming Guide p/n 72-69680-xx for further customization options. The scanner ships with the settings shown in the Miscellaneous Scanner Options Default Table on page 13-2 (also Appendix A, Standard Default Parameters...

  • Page 218: Miscellaneous Parameter Defaults

    13 - 2 Symbol LS4208 Product Reference Guide Miscellaneous Parameter Defaults Table 13-1 lists the defaults for miscellaneous scanner options parameters. If you wish to change any option, scan the appropriate bar code(s) provided in the Miscellaneous Scanner Parameters section beginning on page 13-3.

  • Page 219: Miscellaneous Scanner Parameters

    In addition to any single character prefix already selected, the Code ID character is inserted between the prefix and the decoded symbol. Select no Code ID character, a Symbol Code ID character, or an AIM Code ID character. For Code ID Characters, Symbol Code Identifiers on page B-1 AIM Code Identifiers on page B-2.

  • Page 220: Scan Data Transmission Format

    13 - 4 Symbol LS4208 Product Reference Guide Prefix/Suffix Values (continued) Scan Prefix Scan Suffix Scan Data Transmission Format To change the scan data format, scan Scan Options and one of the following four bar codes corresponding to the desired format: •...
  • Page 221 Miscellaneous Scanner Options 13 - 5 Scan Data Transmission Format (continued) Scan Options Data As Is <DATA> <SUFFIX> <PREFIX> <DATA> <PREFIX> <DATA> <SUFFIX> Enter Data Format Cancel...

  • Page 222: Fn1 Substitution Values

    Scan a bar code below to select whether or not to transmit a No Read message. When enabled, the characters NR are transmitted when a bar code is not decoded. When disabled, if a symbol does not decode, nothing is sent to the host.

  • Page 223: Synapse Interface

    Miscellaneous Scanner Options 13 - 7 Synapse Interface The auto-detection of a Synapse cable varies in duration depending on the type of Synapse connection. If a scanner is connected to another scanner using a Synapse cable, use the Auxiliary Synapse Port connection. In all other cases, where the cable is used, the default setting is recommended.

  • Page 224: Report Version

    13 - 8 Symbol LS4208 Product Reference Guide Report Version Scan the bar code below to report the software revision installed in the scanner’s primary microprocessor. Report Software Version Report Synapse Cable Scan the bar code below to report the software revision of the attached Synapse cable. If the scanner does not detect an attached Synapse cable, it reports Synapse not attached.

  • Page 225: Chapter 14 Advanced Data Formatting

    Chapter 14 Advanced Data Formatting Introduction Advanced Data Formatting (ADF) is a means of customizing data before transmission to the host device. Edit scan data to suit particular requirements. To implement ADF, scan a related series of bar codes, which begin on page 14-8, or install the 123Scan utility (see Chapter 11,...

  • Page 226: Using Adf Bar Codes

    14 - 2 Symbol LS4208 Product Reference Guide Using ADF Bar Codes When programming a rule, make sure the rule is logically correct. Plan ahead before you start scanning. To program each data formatting rule: • Start the Rule. Scan the Begin New Rule bar code on page 14-8.

  • Page 227: Rule 1: The Code 128 Scanning Rule

    Advanced Data Formatting 14 - 3 Rule 1: The Code 128 Scanning Rule Step Bar Code On Page Beep Indication Begin New Rule 14-8 High High Code 128 14-11 High High Send next 5 characters 14-23 High High Send <CTRL M> 14-44 High High Send next 5 characters...

  • Page 228: Rules Hierarchy (In Bar Codes)

    14 - 4 Symbol LS4208 Product Reference Guide But, when there is a sale, send only the following: 24 (class key) 56712437 (stock key) and the cashier keys the price manually. To implement this, first enter an ADF rule that applies to the normal situation, such as: When scanning a bar code of length 15, send the next 2 characters, send the class key, send the next 8 characters, send the stock key, send the data that remains, send the Enter key.

  • Page 229: Default Rules

    Code 128 bar code of length 12, the THIRD rule applies, and the SECOND rule does not function. Note that using the standard data editing functions also creates ADF rules. Scan options are entered as ADF rules, and the hierarchy mentioned above also applies to them. For the Symbol LS4208, this applies to prefix/suffix programming in Scan Data Transmission Format on page 13-4.
  • Page 230 14 - 6 Symbol LS4208 Product Reference Guide ADF Bar Codes (Continued) Table 14-1 Page Parameter Number Specific String At Start 14-19 Specific String Any Location 14-20 Specific String Search 14-20 Any Message OK 14-20 Numeric Keypad 14-21 Rule Belongs To Set...
  • Page 231 Advanced Data Formatting 14 - 7 ADF Bar Codes (Continued) Table 14-1 Page Parameter Number Send F1 Key Send F24 Key 14-68 Send PF1 Key Send PF30 Key 14-71 Send Right Control Key 14-75 Send Graphic User Interface (GUI) Characters 14-76 Send GUI 0 Send GUI 9...

  • Page 232: Special Commands

    14 - 8 Symbol LS4208 Product Reference Guide Special Commands Pause Duration This parameter, along with Send Pause on page 14-28, inserts a pause in the data transmission. To set the pause scan a two-digit number (i.e., two bar codes) representing a 0.1 second interval in the range of 0.1 to 9.9. For example, scanning bar codes inserts a 0.1 second pause;...

  • Page 233: Erase

    Advanced Data Formatting 14 - 9 Erase Use these bar codes to erase criteria, actions, or rules. Erase Criteria And Start Again Erase Actions And Start Again Erase Previously Saved Rule Erase All Rules Quit Entering Rules Scan this bar code to quit entering rules. Quit Entering Rules...

  • Page 234: Disable Rule Set

    14 - 10 Symbol LS4208 Product Reference Guide Disable Rule Set Use these bar codes to disable rule sets. Disable Rule Set 1 Disable Rule Set 2 Disable Rule Set 3 Disable Rule Set 4 Disable All Rule Sets...

  • Page 235: Criteria

    Advanced Data Formatting 14 - 11 Criteria Code Types Select any number of code types to be affected by the rule. Scan all selected codes in succession, prior to selecting other criteria. To select all code types, do not scan any code type. Code 39 Codabar GS1 DataBar-14...
  • Page 236 14 - 12 Symbol LS4208 Product Reference Guide Code Types (continued) D 2 OF 5 IATA 2 OF 5 I 2 OF 5 Code 93 UPC-A UPC-E EAN-8 EAN-13...
  • Page 237 Advanced Data Formatting 14 - 13 Code Types (continued) GS1-128 UPC-E1 Bookland EAN Trioptic Code 39 Code 11...
  • Page 238 14 - 14 Symbol LS4208 Product Reference Guide Code Types (continued) PDF417 MicroPDF UPC/EAN Composites GS1 DataBar and GS1-128 Composites...

  • Page 239: Code Lengths

    Advanced Data Formatting 14 - 15 Code Lengths Scan these bar codes to define the number of characters the selected code type must contain. Select one length per rule only. Do not select any code length to select code types of any length. 1 Character 2 Characters 3 Characters...
  • Page 240 14 - 16 Symbol LS4208 Product Reference Guide Code Lengths (continued) 8 Characters 9 Characters 10 Characters 11 Characters 12 Characters 13 Characters 14 Characters...
  • Page 241 Advanced Data Formatting 14 - 17 Code Lengths (continued) 15 Characters 16 Characters 17 Characters 18 Characters 19 Characters 20 Characters 21 Characters 22 Characters...
  • Page 242 14 - 18 Symbol LS4208 Product Reference Guide Code Lengths (continued) 23 Characters 24 Characters 25 Characters 26 Characters 27 Characters 28 Characters 29 Characters 30 Characters...

  • Page 243: Message Containing A Specific Data String

    Advanced Data Formatting 14 - 19 Message Containing A Specific Data String Use this feature to select whether the formatting affects data that begins with a specific character or data string, or contains a specific character or data string. There are five features: •...

  • Page 244: Specific String Search

    14 - 20 Symbol LS4208 Product Reference Guide Specific String Search Scan the following bar code. Scan the bar codes representing the desired character or characters (up to a total of 10) using the Alphanumeric Keyboard on page 14-83. Scan End of Message on page 14-91.

  • Page 245: Numeric Keypad

    Advanced Data Formatting 14 - 21 Numeric Keypad Bar codes on this page should not be confused with those on the alphanumeric keyboard.

  • Page 246: Rule Belongs To Set 1

    14 - 22 Symbol LS4208 Product Reference Guide Numeric Keypad (continued) Cancel Rule Belongs To Set Select the set a rule belongs to. (There are four possible rule sets.) See Alternate Rule Sets on page 14-3 for more information about rule sets.

  • Page 247: Actions

    Advanced Data Formatting 14 - 23 Actions Select how to format the data for transmission. Send Data Send all data that remains, send all data up to a specific character selected from the Alphanumeric Keyboard on page 14-83, or send the next N characters. N = any number from 1 to 254, selected from the Alphanumeric Keyboard on page 14-83.
  • Page 248 14 - 24 Symbol LS4208 Product Reference Guide Send Data (continued) Send Next 6 Characters Send Next 7 Characters Send Next 8 Characters Send Next 9 Characters Send Next 10 Characters Send Next 11 Characters Send Next 12 Characters Send Next 13 Characters...

  • Page 249: Send Next 20 Characters

    Advanced Data Formatting 14 - 25 Send Data (continued) Send Next 14 Characters Send Next 15 Characters Send Next 16 Characters Send Next 17 Characters Send Next 18 Characters Send Next 19 Characters Send Next 20 Characters...

  • Page 250: Setup Field(S)

    14 - 26 Symbol LS4208 Product Reference Guide Setup Field(s) Setup Field(s) Definitions Table 14-2 Parameter Description Page Move Cursor Move Cursor to a Character Scan the Move Cursor To Character bar code on page 14-27, 14-27 then any printable ASCII character from the Alphanumeric Keyboard.

  • Page 251: Move Cursor

    Advanced Data Formatting 14 - 27 Setup Field(s) Definitions (Continued) Table 14-2 Parameter Description Page Skip Ahead “N” Characters Scan one of these bar codes to select the desired number of 14-29 positions to move the cursor ahead. Skip Back “N” Characters Scan one of these bar codes to select the desired number of 14-31 positions to move the cursor back.

  • Page 252: Send Pause

    14 - 28 Symbol LS4208 Product Reference Guide Move Cursor (continued) Move Cursor to Specific String and Replace Move Cursor to Last Occurrence of String and Replace All Skip to End Send Pause Scan the bar code below to insert a pause in the transmission of data. The length of this pause is controlled by the value of the Pause Duration parameter.

  • Page 253: Skip Ahead

    Advanced Data Formatting 14 - 29 Skip Ahead Use the following bar codes to skip ahead characters. Skip Ahead 1 Character Skip Ahead 2 Characters Skip Ahead 3 Characters Skip Ahead 4 Characters Skip Ahead 5 Characters Skip Ahead 6 Characters...
  • Page 254 14 - 30 Symbol LS4208 Product Reference Guide Skip Ahead (continued) Skip Ahead 7 Characters Skip Ahead 8 Characters Skip Ahead 9 Characters Skip Ahead 10 Characters...

  • Page 255: Skip Back

    Advanced Data Formatting 14 - 31 Skip Back Use the following bar codes to skip back characters. Skip Back 1 Character Skip Back 2 Characters Skip Back 3 Characters Skip Back 4 Characters Skip Back 5 Characters Skip Back 6 Characters Skip Back 7 Characters...

  • Page 256: Send Preset Value

    14 - 32 Symbol LS4208 Product Reference Guide Skip Back (continued) Skip Back 8 Characters Skip Back 9 Characters Skip Back 10 Characters Send Preset Value Use these bar codes to send preset values. These values must be set using the Scan Prefix and Scan Suffix bar...

  • Page 257: Modify Data

    Advanced Data Formatting 14 - 33 Modify Data Modify data in the ways listed. The following actions work for all send commands that follow it within a rule. If pad zeros to length 6, send next 3 characters, stop padding, send next 5 characters is programmed, three zeros are added to the first send, and the next send is unaffected by the padding.

  • Page 258: Pad Data With Spaces

    14 - 34 Symbol LS4208 Product Reference Guide Pad Data with Spaces To pad data to the left, scan the bar code containing the desired number of spaces. This parameter is activated by Send commands. Pad Spaces To Length 1...
  • Page 259 Advanced Data Formatting 14 - 35 Pad Data with Spaces (continued) Pad Spaces To Length 9 Pad Spaces To Length 10 Pad Spaces To Length 11 Pad Spaces To Length 12 Pad Spaces To Length 13 Pad Spaces To Length 14 Pad Spaces To Length 15 Pad Spaces To Length 16...
  • Page 260 14 - 36 Symbol LS4208 Product Reference Guide Pad Data with Spaces (continued) Pad Spaces To Length 17 Pad Spaces To Length 18 Pad Spaces To Length 19 Pad Spaces To Length 20 Pad Spaces To Length 21 Pad Spaces To Length 22...
  • Page 261 Advanced Data Formatting 14 - 37 Pad Data with Spaces (continued) Pad Spaces To Length 24 Pad Spaces To Length 25 Pad Spaces To Length 26 Pad Spaces To Length 27 Pad Spaces To Length 28 Pad Spaces To Length 29 Pad Spaces To Length 30 Stop Pad Spaces...

  • Page 262: Pad Data With Zeros

    14 - 38 Symbol LS4208 Product Reference Guide Pad Data with Zeros To pad data to the left, scan the bar code containing the desired number of zeros. This parameter is activated by Send commands. Pad Zeros To Length 1...
  • Page 263 Advanced Data Formatting 14 - 39 Pad Data with Zeros (continued) Pad Zeros To Length 9 Pad Zeros To Length 10 Pad Zeros To Length 11 Pad Zeros To Length 12 Pad Zeros To Length 13 Pad Zeros To Length 14 Pad Zeros To Length 15 Pad Zeros To Length 16...
  • Page 264 14 - 40 Symbol LS4208 Product Reference Guide Pad Data with Zeros (continued) Pad Zeros To Length 17 Pad Zeros To Length 18 Pad Zeros To Length 19 Pad Zeros To Length 20 Pad Zeros To Length 21 Pad Zeros To Length 22...
  • Page 265 Advanced Data Formatting 14 - 41 Pad Data with Zeros (continued) Pad Zeros To Length 25 Pad Zeros To Length 26 Pad Zeros To Length 27 Pad Zeros To Length 28 Pad Zeros To Length 29 Pad Zeros To Length 30 Stop Pad Zeros...

  • Page 266: Beeps

    14 - 42 Symbol LS4208 Product Reference Guide Beeps Select a beep sequence for each ADF rule. Beep Once Beep Twice Beep Three Times...

  • Page 267: Send Keystroke (Control Characters And Keyboard Characters)

    Advanced Data Formatting 14 - 43 Send Keystroke (Control Characters and Keyboard Characters) Control Characters Scan the “Send __” bar code for the desired keystroke Send Control 2 Send Control A Send Control B Send Control C Send Control D Send Control E Send Control F Send Control G...
  • Page 268 14 - 44 Symbol LS4208 Product Reference Guide Control Characters (continued) Send Control H Send Control I Send Control J Send Control K Send Control L Send Control M Send Control N Send Control O...
  • Page 269 Advanced Data Formatting 14 - 45 Control Characters (continued) Send Control P Send Control Q Send Control R Send Control S Send Control T Send Control U Send Control V Send Control W...
  • Page 270 14 - 46 Symbol LS4208 Product Reference Guide Control Characters (continued) Send Control X Send Control Y Send Control Z Send Control [ Send Control \ Send Control ] Send Control 6 Send Control -...

  • Page 271: Keyboard Characters

    Advanced Data Formatting 14 - 47 Keyboard Characters Scan the “Send __” bar code for the desired keyboard characters Send Space Send ! Send “ Send # Send $ Send % Send & Send ‘...
  • Page 272 14 - 48 Symbol LS4208 Product Reference Guide Keyboard Characters (continued) Send ( Send ) Send * Send + Send , Send - Send . Send /...
  • Page 273 Advanced Data Formatting 14 - 49 Keyboard Characters (continued) Send 0 Send 1 Send 2 Send 3 Send 4 Send 5 Send 6 Send 7...
  • Page 274 14 - 50 Symbol LS4208 Product Reference Guide Keyboard Characters (continued) Send 8 Send 9 Send : Send ; Send < Send = Send > Send ?
  • Page 275 Advanced Data Formatting 14 - 51 Keyboard Characters (continued) Send @ Send A Send B Send C Send D Send E Send F Send G...
  • Page 276 14 - 52 Symbol LS4208 Product Reference Guide Keyboard Characters (continued) Send H Send I Send J Send K Send L Send M Send N Send O...
  • Page 277 Advanced Data Formatting 14 - 53 Keyboard Characters (continued) Send P Send Q Send R Send S Send T Send U Send V Send W...
  • Page 278 14 - 54 Symbol LS4208 Product Reference Guide Keyboard Characters (continued) Send X Send Y Send Z Send [ Send \ Send ] Send ^ Send _...
  • Page 279 Advanced Data Formatting 14 - 55 Keyboard Characters (continued) Send ` Send a Send b Send c Send d Send e Send f Send g...
  • Page 280 14 - 56 Symbol LS4208 Product Reference Guide Keyboard Characters (continued) Send h Send i Send j Send k Send l Send m Send n Send o...
  • Page 281 Advanced Data Formatting 14 - 57 Keyboard Characters (continued) Send p Send q Send r Send s Send t Send u Send v Send w...
  • Page 282 14 - 58 Symbol LS4208 Product Reference Guide Keyboard Characters (continued) Send x Send y Send z Send { Send | Send } Send ~...
  • Page 283 Advanced Data Formatting 14 - 59 Send ALT Characters Send Alt 2 Send Alt A Send Alt B Send Alt C Send Alt D Send Alt E Send Alt F Send Alt G...
  • Page 284 14 - 60 Symbol LS4208 Product Reference Guide Send ALT Characters (continued) Send Alt H Send Alt I Send Alt J Send Alt K Send Alt L Send Alt M Send Alt N Send Alt O...
  • Page 285 Advanced Data Formatting 14 - 61 Send ALT Characters (continued) Send Alt P Send Alt Q Send Alt R Send Alt S Send Alt T Send Alt U Send Alt V Send Alt W...
  • Page 286 14 - 62 Symbol LS4208 Product Reference Guide Send ALT Characters (continued) Send Alt X Send Alt Y Send Alt Z Send Alt [ Send Alt \ Send Alt ] Send Alt 6 Send Alt -...
  • Page 287 Advanced Data Formatting 14 - 63 Send Keypad Characters Send Keypad * Send Keypad + Send Keypad - Send Keypad . Send Keypad / Send Keypad 0 Send Keypad 1 Send Keypad 2...
  • Page 288 14 - 64 Symbol LS4208 Product Reference Guide Send Keypad Characters (continued) Send Keypad 3 Send Keypad 4 Send Keypad 5 Send Keypad 6 Send Keypad 7 Send Keypad 8 Send Keypad 9 Send Keypad Enter...
  • Page 289 Advanced Data Formatting 14 - 65 Send Keypad Characters (continued) Send Keypad Numlock NUM LOCK Send Break Key Send Delete Key Send Page Up Key Send End Key Send Page Down Key Send Pause Key Send Scroll Lock Key...
  • Page 290 14 - 66 Symbol LS4208 Product Reference Guide Send Keypad Characters (continued) Send Backspace Key Send Tab Key Send Print Screen Key Send Insert Key Send Home Key Send Enter Key Send Escape Key Send Up Arrow Key...
  • Page 291 Advanced Data Formatting 14 - 67 Send Keypad Characters (continued) Send Down Arrow Key Send Left Arrow Key Send Right Arrow Key...
  • Page 292 14 - 68 Symbol LS4208 Product Reference Guide Send Function Key Send F1 Key Send F2 Key Send F3 Key Send F4 Key Send F5 Key Send F6 Key...
  • Page 293 Advanced Data Formatting 14 - 69 Send Function Key (continued) Send F7 Key Send F8 Key Send F9 Key Send F10 Key Send F11 Key Send F12 Key Send F13 Key Send F14 Key...
  • Page 294 14 - 70 Symbol LS4208 Product Reference Guide Send Function Key (continued) Send F15 Key Send F16 Key Send F17 Key Send F18 Key Send F19 Key Send F20 Key Send F21 Key Send F22 Key...
  • Page 295 Advanced Data Formatting 14 - 71 Send Function Key (continued) Send F23 Key Send F24 Key Send PF1 Key Send PF2 Key Send PF3 Key Send PF4 Key Send PF5 Key Send PF6 Key...
  • Page 296 14 - 72 Symbol LS4208 Product Reference Guide Send Function Key (continued) Send PF7 Key Send PF8 Key Send PF9 Key Send PF10 Key Send PF11 Key Send PF12 Key Send PF13 Key Send PF14 Key...
  • Page 297 Advanced Data Formatting 14 - 73 Send Function Key (continued) Send PF15 Key Send PF16 Key Send PF17 Key Send PF18 Key Send PF19 Key Send PF20 Key Send PF21 Key Send PF22 Key...
  • Page 298 14 - 74 Symbol LS4208 Product Reference Guide Send Function Key (continued) Send PF23 Key Send PF24 Key Send PF25 Key Send PF26 Key Send PF27 Key Send PF28 Key Send PF29 Key Send PF30 Key...

  • Page 299: Send Right Control Key

    Advanced Data Formatting 14 - 75 Send Right Control Key The “Send Right Control Key” action sends a tap (press and release) of the Right Control Key. Send Right Control Key...

  • Page 300: Send Graphic User Interface (Gui) Characters

    14 - 76 Symbol LS4208 Product Reference Guide Send Graphic User Interface (GUI) Characters The “Send Graphic User Interface Character” actions tap the specified key while holding the System Dependent Graphic User Interface (GUI) Key. The definition of the Graphic User Interface key is dependent upon the attached...
  • Page 301 Advanced Data Formatting 14 - 77 Send Graphic User Interface (GUI) Characters (continued) Send GUI 6 Send GUI 7 Send GUI 8 Send GUI 9 Send GUI A Send GUI B Send GUI C...
  • Page 302 14 - 78 Symbol LS4208 Product Reference Guide Send Graphic User Interface (GUI) Characters (continued) Send GUI D Send GUI E Send GUI F Send GUI G Send GUI H Send GUI I Send GUI J...
  • Page 303 Advanced Data Formatting 14 - 79 Send Graphic User Interface (GUI) Characters (continued) Send GUI K Send GUI L Send GUI M Send GUI N Send GUI O Send GUI P Send GUI Q...
  • Page 304 14 - 80 Symbol LS4208 Product Reference Guide Send Graphic User Interface (GUI) Characters (continued) Send GUI R Send GUI S Send GUI T Send GUI U Send GUI V Send GUI W Send GUI X...
  • Page 305 Advanced Data Formatting 14 - 81 Send Graphic User Interface (GUI) Characters (continued) Send GUI Y Send GUI Z...

  • Page 306: Turn On/Off Rule Sets

    14 - 82 Symbol LS4208 Product Reference Guide Turn On/Off Rule Sets Use these bar codes to turn rule sets on and off. Turn On Rule Set 1 Turn On Rule Set 2 Turn On Rule Set 3 Turn On Rule Set 4...

  • Page 307: Alphanumeric Keyboard

    Advanced Data Formatting 14 - 83 Alphanumeric Keyboard Space (Dash) (Comma)
  • Page 308 14 - 84 Symbol LS4208 Product Reference Guide Alphanumeric Keyboard (continued) “ & ‘...
  • Page 309 Advanced Data Formatting 14 - 85 Alphanumeric Keyboard (continued) < >...
  • Page 310 14 - 86 Symbol LS4208 Product Reference Guide Alphanumeric Keyboard (continued) (Underscore) (Single Open Quote)
  • Page 311 Advanced Data Formatting 14 - 87 Alphanumeric Keyboard (continued) NOTE Bar codes on this page should not be confused with those on the numeric keypad.
  • Page 312 14 - 88 Symbol LS4208 Product Reference Guide Alphanumeric Keyboard (continued)
  • Page 313 Advanced Data Formatting 14 - 89 Alphanumeric Keyboard (continued)
  • Page 314 14 - 90 Symbol LS4208 Product Reference Guide Alphanumeric Keyboard (continued)
  • Page 315 Advanced Data Formatting 14 - 91 Alphanumeric Keyboard (continued) Cancel End of Message...
  • Page 316 14 - 92 Symbol LS4208 Product Reference Guide Alphanumeric Keyboard (continued)
  • Page 317 Advanced Data Formatting 14 - 93 Alphanumeric Keyboard (continued)
  • Page 318 14 - 94 Symbol LS4208 Product Reference Guide Alphanumeric Keyboard (continued)
  • Page 319 Advanced Data Formatting 14 - 95 Alphanumeric Keyboard (continued)
  • Page 320 14 - 96 Symbol LS4208 Product Reference Guide...

  • Page 321: Appendix A Standard Default Parameters

    Appendix A Standard Default Parameters Default Parameters Standard Default Parameters Table Table A-1 Page Parameter Default Number User Preferences Set Default Parameter Restore Defaults Parameter Bar Code Scanning Enable Beeper Tone Medium Beeper Volume High Power Mode Continuous On Scan Pattern Multi-line Always Raster Scan Line Width Full Width...
  • Page 322 A - 2 Symbol LS4208 Product Reference Guide Standard Default Parameters Table (Continued) Table A-1 Page Parameter Default Number Keystroke Delay No Delay Intra-Keystroke Delay Disable Alternate Numeric Keypad Emulation Disable Caps Lock On Disable Caps Lock Override Disable Convert Wedge Data...
  • Page 323 Disable Ignore Beep Disable Ignore Bar Code Configuration Disable Wand Emulation Host Parameters Wand Emulation Host Types Symbol OmniLink Interface Controller Leading Margin 80 msec Polarity Bar High/Margin Low Ignore Unknown Characters Send Convert All Bar Codes to Code 39...
  • Page 324 A - 4 Symbol LS4208 Product Reference Guide Standard Default Parameters Table (Continued) Table A-1 Page Parameter Default Number Leading Margin 2 ms 10-10 Check for Decode LED Check for Decode LED 10-11 11-1 123Scan Configuration Tool UPC/EAN UPC-A Enable...
  • Page 325 Standard Default Parameters A - 5 Standard Default Parameters Table (Continued) Table A-1 Page Parameter Default Number Code 39 Code 39 Enable 12-25 Trioptic Code 39 Disable 12-25 Convert Code 39 to Code 32 Disable 12-26 (Italian Pharmacy Code) Code 32 Prefix Disable 12-26 Set Length(s) for Code 39...
  • Page 326 A - 6 Symbol LS4208 Product Reference Guide Standard Default Parameters Table (Continued) Table A-1 Page Parameter Default Number Chinese 2 of 5 Enable/Disable Chinese 2 of 5 Disable 12-46 Codabar (NW - 7) Codabar Disable 12-47 Set Lengths for Codabar...
  • Page 327 Standard Default Parameters A - 7 Standard Default Parameters Table (Continued) Table A-1 Page Parameter Default Number Character Escape Character None 12-58 Delete Character Set ECI’s Transmit 12-59 Composite Composite CC-C Disable 12-60 Composite CC-A/B Disable 12-60 UPC Composite Mode UPC Always Linked 12-61 Composite Beep Mode...
  • Page 328 A - 8 Symbol LS4208 Product Reference Guide...

  • Page 329: Appendix B Programming References

    Appendix B Programming References Symbol Code Identifiers Symbol Code Characters Table B-1 Code Character Code Type UPC/EAN Code 39, Code 39 Full ASCII, Code 32 Codabar Code 128, ISBT 128 Code 93 Interleaved 2 of 5 Discrete 2 of 5, or Discrete 2 of 5 IATA...

  • Page 330: Aim Code Identifiers

    B - 2 Symbol LS4208 Product Reference Guide AIM Code Identifiers Each AIM Code Identifier contains the three-character string ]cm where: Flag Character (ASCII 93) Code Character (see Table B-2) Modifier Character (see Table B-3) Aim Code Characters Table B-2...
  • Page 331 No option specified at this time. Always transmit 0. Example: A Trioptic bar code 412356 is transmitted as ]X0412356 Code 128 Standard data packet, no Function code 1 in first symbol position. Function code 1 in first symbol character position.
  • Page 332 B - 4 Symbol LS4208 Product Reference Guide Modifier Characters (Continued) Table B-3 Code Type Option Value Option Bookland EAN No options specified at this time. Always transmit 0. Example: A Bookland EAN bar code 123456789X is transmitted as ]X0123456789X...

  • Page 333: Appendix C Sample Bar Codes

    Appendix C Sample Bar Codes Code 39 123ABC UPC/EAN UPC-A, 100% 12345 67890...

  • Page 334: Code 128

    C - 2 Symbol LS4208 Product Reference Guide EAN-13, 100% 3 4 5 67 8 9 0 1 2 3 4 0 Code 128 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4...

  • Page 335: Gs1 Databar

    Sample Bar Codes C - 3 GS1 DataBar GS1 DataBar variants must be enabled to read the bar codes below (see NOTE GS1 DataBar (formerly RSS - Reduced Space Symbology) on page 12-53). GS1 DataBar 10293847560192837465019283746029478450366523 (GS1 DataBar Expanded Stacked) 1234890hjio9900mnb (GS1 DataBar Expanded) 08672345650916...

  • Page 336: Gs1 Databar-14

    C - 4 Symbol LS4208 Product Reference Guide GS1 DataBar-14 55432198673467 (GS1 DataBar-14 Truncated) 90876523412674 (GS1 DataBar-14 Stacked) 78123465709811 (GS1 DataBar-14 Stacked Omni-Directional)
  • Page 337 Appendix D Numeric Bar Codes Numeric Bar Codes For parameters requiring specific numeric values, scan the appropriately numbered bar code(s).
  • Page 338 D - 2 Symbol LS4208 Product Reference Guide Numeric Bar Codes (continued) For parameters requiring specific numeric values, scan the appropriately numbered bar code(s).
  • Page 339 Numeric Bar Codes D - 3 Cancel To correct an error or change a selection, scan the bar code below. Cancel...
  • Page 340 D - 4 Symbol LS4208 Product Reference Guide...
  • Page 341 Appendix E ASCII Character Sets ASCII Value Standard Default Parameters Table Table E-1 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1000 CTRL 2 1001 CTRL A 1002 CTRL B 1003 CTRL C 1004 CTRL D 1005 CTRL E 1006 CTRL F 1007...
  • Page 342 E - 2 Symbol LS4208 Product Reference Guide ASCII Value Standard Default Parameters Table (Continued) Table E-1 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1016 CTRL P 1017 CTRL Q 1018 CTRL R 1019 CTRL S 1020 CTRL T...
  • Page 343 ASCII Character Sets E - 3 ASCII Value Standard Default Parameters Table (Continued) Table E-1 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1044 1045 1046 1047 1048 1049 1050 1051 1052 1053 1054 1055 1056 1057 1058 1059 1060 <...
  • Page 344 E - 4 Symbol LS4208 Product Reference Guide ASCII Value Standard Default Parameters Table (Continued) Table E-1 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1072 1073 1074 1075 1076 1077 1078 1079 1080 1081 1082 1083 1084 1085...
  • Page 345 ASCII Character Sets E - 5 ASCII Value Standard Default Parameters Table (Continued) Table E-1 Full ASCII Code 39 ASCII Value Keystroke Encode Character 1100 1101 1102 1103 1104 1105 1106 1107 1108 1109 1110 1111 1112 1113 1114 1115 1116 1117 1118...
  • Page 346 E - 6 Symbol LS4208 Product Reference Guide ALT Key Standard Default Tables Table E-2 ALT Keys Keystroke 2064 ALT 2 2065 ALT A 2066 ALT B 2067 ALT C 2068 ALT D 2069 ALT E 2070 ALT F 2071...
  • Page 347 ASCII Character Sets E - 7 Misc. Key Standard Default Table Table E-3 Misc. Key Keystroke 3001 PA 1 3002 PA 2 3003 CMD 1 3004 CMD 2 3005 CMD 3 3006 CMD 4 3007 CMD 5 3008 CMD 6 3009 CMD 7 3010...
  • Page 348 E - 8 Symbol LS4208 Product Reference Guide GUI Shift Keys (Continued) Table E-4 Other Value Keystroke 3056 GUI 8 3057 GUI 9 3065 GUI A 3066 GUI B 3067 GUI C 3068 GUI D 3069 GUI E 3070 GUI F...
  • Page 349 ASCII Character Sets E - 9 GUI Shift Keys (Continued) Table E-4 Other Value Keystroke 3088 GUI X 3089 GUI Y 3090 GUI Z GUI Shift Keys The Apple™ iMac keyboard has an apple key on either side of the space bar.
  • Page 350 E - 10 Symbol LS4208 Product Reference Guide F key Standard Default Table Table E-6 F Keys Keystroke 5001 5002 5003 5004 5005 5006 5007 5008 5009 5010 F 10 5011 F 11 5012 F 12 5013 F 13 5014...
  • Page 351 ASCII Character Sets E - 11 Numeric Key Standard Default Table Table E-7 Numeric Keypad Keystroke 6042 6043 6044 Undefined 6045 6046 6047 6048 6049 6050 6051 6052 6053 6054 6055 6056 6057 6058 Enter 6059 Num Lock...
  • Page 352 E - 12 Symbol LS4208 Product Reference Guide Extended Keypad Standard Default Table Table E-8 Extended Keypad Keystroke 7001 Break 7002 Delete 7003 Pg Up 7004 7005 Pg Dn 7006 Pause 7007 Scroll Lock 7008 Backspace 7009 7010 Print Screen...
  • Page 353 Index skip ahead "n" characters ....14-27 skip ahead characters ....14-29 actions .
  • Page 354 Index - 2 Symbol LS4208 Product Reference Guide send preset value ..... . 14-32 FN1 sub values ..... . 13-6 setup fields .
  • Page 355 ....12-66 Symbol code IDs ......B-1 ISBT 128, enable/disable .
  • Page 356 PDF-417 tall symbol ......2-7 keyboard wedge connection ....5-2 pinouts keyboard wedge defaults .
  • Page 357 Index - 5 bookland ISBN ..... 12-21 unpacking ......1-2 signal descriptions .
  • Page 358 Index - 6 Symbol LS4208 Product Reference Guide...

  • Page 359: Tell Us What You Think

    Tell Us What You Think... We’d like to know what you think about this Manual. Please take a moment to fill out this questionnaire and fax this form to: (631) 627-7184, or mail to: Motorola Solutions, Inc. One Motorola Plaza M/S B-10 Holtsville, NY 11742-1300 Attention: Technical Publications Manager Data Capture Solutions Division...
  • Page 362 Motorola Solutions, Inc. One Motorola Plaza Holtsville, New York 11742, USA 1-800-927-9626 http://www.motorolasolutions.com MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M Logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners. ©...

Table of Contents

Save PDF
