- Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
- Page 3 The following models are available: • M2004-I200 (RS-232C) contains on-board discrete RS- 232C communications for connecting to RS-232C asynchro- nous terminals and host systems. It also accommodates Synapse™ Smart Cables which allow you to connect to a wide variety of host systems.
-
Page 4: Setting Up Your Scanner
Setting Up your Scanner 3. Connect power supply (if necessary). 1. Listen for click. Interface Cable 2. Connect to host. If you are using a Synapse cable, the scanner autodetects your host. If you are using another cable, set the M2000 to communicate with your particular POS host by scanning the appropriate bar code(s) in the Cyclone M2000 Series Product... -
Page 5: Removing The Interface Cable
Q u i c k R e f e r e n c e Removing the Interface Cable Different cables are required for different hosts. To remove the interface cable: 1. Unplug the cable’s modular connector by depressing the connector clip through the access hole on the bottom of the scanner with a screwdriver or paper clip. -
Page 6: Electronic Article Surveillance (Eas) (Optional)
800-257-5540, ext. 4300. Outside the U.S., call (609) 848- 1800, ext. 4300. If you are using an EAS cable, refer to the Universal Cable EAS Installation Sheet (Symbol p/n 70-32824-xx). Scanning Modes The M2000 may be used on the counter-top or in a hand-held orientation. -
Page 7: Laser Patterns
Q u i c k R e f e r e n c e Laser Patterns The scanner emits one of four laser patterns: • Cyclone Omnidirectional Scan Pattern is a highly efficient scan pattern which decodes 1D and EAN/UCC reduced space symbologies in any orientation. - Page 8 One pattern can be selected for counter-top mode and another for hand-held mode via programming bar code in the M2000 Series Product Reference Guide (p/n 72-39696-xx). For hand-held mode, you may alternatively select a pattern by pressing the Scan Pattern Mode Selector button when the scanner is lifted off the counter.
-
Page 9: Led Indications
Q u i c k R e f e r e n c e LED Indications The lit LED indicates the selected scan pattern for hand-held and counter-top mode. In hand-held mode, pressing the Scan Pattern Mode Selector button selects the next pattern, and lights the corresponding LED. -
Page 10: Ergonomic Recommendations
• Provide a suitable working environment • Improve work procedures. Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. - Page 11 CE Mark which indicates compliance to applicable Directives and European Normes (EN). Statement of Compliance Symbol Technologies, Inc., hereby declares that this device is in compliance with all the applicable Directives, 89/336/EEC, 73/23/EEC. A Declaration of Conformity may be obtained from http://www2.symbol.com/doc/ Laser Devices Symbol devices using lasers comply with US 21CFR1040.10, and IEC825-1:1993,...
-
Page 12: Scanner Labeling
Scanner Labeling AVOID EXPOSURE LASER LIGHT IS EMITTED FROM THIS APERTURE DANGER. LASER LIGHT WHEN OPEN AVOID DIRECT EYE EXPOSURE C A U T I O N LASER LIGHT-DO NOT STARE INTO BEAM 630-680 nM LASER 1.0 mW MAX OUTPUT CLASS II LASER PRODUCT LASER LIGHT. - Page 13 Q u i c k R e f e r e n c e In accordance with Clause 5, IEC 0825 and EN60825, the following information is provided to the user: ENGLISH HEBREW CLASS 1 CLASS 1 LASER PRODUCT CLASS 2 LASER LIGHT DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT...
-
Page 15: Warranty
Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which... - Page 16 +44 118 945 7360 Customer support is available 24 hours a day, 7 days a week. For the latest version of this guide go to: http://www.symbol.com/manuals. 72-39695-01 Revision C — January 2003 Symbol Technologies, Inc. One Symbol Plaza, Holtsville, N.Y. 11742-1300...
