Page 1: Table Of Contents
Table of Contents LRP-101CE 1. Package Contents ................ 1-1 2. Application Diagram ..............1-1 3. Physical Introduction ..............1-3 4. Hardware Specifications ............... 1-5 LRP-101UE 5. Package Contents ................ 2-1 6. Application Diagram ..............2-2 7. Physical Introduction ..............2-3 8. Hardware Specifications ............... 2-5... - Page 2 PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that may have occurred.
- Page 3 Do not dispose of WEEE as unsorted municipal waste and have to collect such WEEE separately. Revision PLANET Long Reach PoE over Coaxial / UTP Extender User’s Manual MODELS: LRP-101CE / LRP-101UE REVISION: 1.0 (January 2015)
-
Page 4: Lrp-101Ce
Long Reach PoE over Coaxial Extender LRP-101CE User’s Manual... -
Page 5: Package Contents
1. Package Contents Thank you for purchasing PLANET Long Reach PoE over Coaxial Extender, the LRP-101CE. “Long Reach PoE over Coaxial Extender” mentioned in this manual refers to the LRP-101CE. Open the box of the Long Reach PoE over Coaxial Extender and carefully unpack it. - Page 6 400m 100m LRP-101CE PoE IP Camera It is recommended to use PLANET Long Reach Ethernet coaxial extenders on the LRP Managed Switch-LRP-822CS. If you insert a coaxial extender that is not supported, the LRP Note Managed Switch may damage it.
-
Page 7: Physical Introduction
3. Physical Introduction LRP-101CE Physical Dimensions Dimensions (W x D x H): 94 x 70.3 x 26 mm Rear Panel PoE In-use LNK/ACT PoE OUT 10/100BASE-TX Top Panel Bottom LRP-101CE LRP IN Extender Long Reach PoE Extender - Coax... - Page 8 LED Descriptions LRP-101CE LRP IN Extender Long Reach PoE Extender - Coax System & LRP Coax Interface Color Function Green Light: indicates the power is on. Light: indicates that the coaxial link is established. Green Off: indicates that the coaxial link is down.
-
Page 9: Hardware Specifications
4. Hardware Specifications Model LRP-101CE Functions Long Reach PoE Extender Hardware Specifications 10/100BASE-TX RJ45 Copper Auto-negotiation / Auto-MDI/MDI-X Power over IEEE 802.3at/af PoE PSE Ethernet (Power Source Equipment) Standard PoE Output 48~56V DC, 600mA max. PoE Budget Up to 25 watts Ethernet Interface... - Page 10 Modulation Wavelet-OFDM Type Security 128-bit AES encryption Frequency 2 ~ 28 MHz Band LRP-101CE 802.3af/at PoE Output Capability** Data Rate* Distance (Upload / LRP-101CH LRP-101CH Download) W/56V DC W/30W PoE+ IN 93 / 93 Long 200m Mbps Reach Performance 93 / 93...
- Page 11 Operating: 5~95% (non-condensing) Humidity Storage: 5~95% (non-condensing) * 1. Upload: LRP-101CE to LRP-101CH. Download: LRP-101CH to LRP- 101CE. 2. As there are various resistance values in the category of RG-59/U or RG-6/U cable, the actual data rate will vary on the quality of the copper wire and environment factors.
-
Page 12: Lrp-101Ue
Long Reach PoE over UTP Extender LRP-101UE User’s Manual... -
Page 13: Package Contents
5. Package Contents Thank you for purchasing PLANET Long Reach PoE over UTP Extender, the LRP-101UE. “Long Reach PoE over UTP Extender” mentioned in this manual refers to the LRP-101UE. Open the box of the Long Reach PoE over UTP Extender and carefully unpack it. -
Page 14: Application Diagram
6. Application Diagram Point to Point PoE+ Switch 802.3at 500m PoE+ Long Reach Power over Ethernet Long UTP 100m PoE IP Camera LRP-101UH LRP-101UE Long Reach PoE Injector Long Reach PoE Extender Power over UTP 802.3at PoE+... -
Page 15: Physical Introduction
7. Physical Introduction LRP-101UE Physical Dimensions Dimensions (W x D x H): 94 x 70.3 x 26 mm Rear Panel PoE In-use LNK/ACT PoE OUT 10/100BASE-TX Top Panel Bottom LRP-101UE LRP IN Extender Long Reach PoE Extender - UTP Front Panel... - Page 16 LED Descriptions LRP-101UE LRP IN Extender Long Reach PoE Extender - UTP System & LRP UTP Interface Color Function Light: indicates the power is on. Green Light: indicates that the UTP link is established. Green Off: indicates that the UTP link is down. PoE In-use LNK/ACT PoE OUT...
-
Page 17: Hardware Specifications
8. Hardware Specifications Model LRP-101UE Hardware Specifications 10/100BASE-TX RJ45 Copper Auto-negotiation / Auto-MDI/MDI-X IEEE 802.3at/af PoE PSE PoE Standard (Power Source Equipment) PoE Output 48~56V DC, 600mA max. PoE Budget Up to 25 watts Ethernet PoE Mode End-span, RJ45 Pin 1/2(+), 3/6(-) Interface Data Rate 100/100Mbps Cabling... - Page 18 Frequency 2 ~ 28 MHz Band LRP-101UE 802.3af/at PoE Output Capability** Data Rate* Distance (Upload / LRP-101UH LRP-101UH Download) W/56V DC W/30W PoE+ IN 94 / 94 100m Long Mbps Reach 82 / 82 Performance 200m Mbps Interface 63 / 67 300m Mbps 44 / 48...
- Page 19 Standards Conformance IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3af Power over Ethernet (802.3at Standards Compliance Type 1) IEEE 802.3at Power over Ethernet (802.3at Type 2) Regulation Compliance FCC Part 15 Class A, CE Environment Operating: -20~70 degrees C Temperature Storage: -40~75 degrees C Operating: 5~95% (non-condensing)
- Page 20 1-Port 10/100TX PoE PSE + 1-Port Coax Long Reach PoE Extender 1-Port 10/100TX PoE PD + 1-Port UTP Long Reach PoE Injector 1-Port 10/100TX PoE PSE + 1-Port UTP Long Reach PoE Extender *Model Number: LRP-101CH, LRP-101CE LRP-101UH, LRP-101UE * Produced by: Manufacturer’s Name : Planet Technology Corp.
