Summary of Contents for Planet IHD-410PT
- Page 1 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR...
- Page 2 Information in this User’s Manual is subject to change without notice and does not represent a commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User’s Manual.
- Page 3 WEEE separately. Trademarks The PLANET logo is a trademark of PLANET Technology. This documentation may refer to numerous hardware and software products by their trade names. In most, if not all cases, these designations are claimed as trademarks or registered trademarks by their respective companies.
-
Page 4: Table Of Contents
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Table of Contents Chapter 1. Product Introduction ................6 1.1 Package Contents ......................6 1.2 Overview .......................... 7 1.3 Features ......................... 11 1.4 Product Specifications ....................12 1.5 Hardware Interface ...................... - Page 5 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.4.2. Serial over IP ....................... 48 APPENDIX A. Troubleshooting & Frequently Asked Questions ....49...
-
Page 6: Chapter 1. Product Introduction
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Chapter 1. Product Introduction 1.1 Package Contents The package should contain the following: Media Extender x 1 Quick Installation Guide x 1 IR Emitter Cable with Transmitter x 1 ... -
Page 7: Overview
The IHD-410 series is the combination of the transmitter, IHD-410PT, and the receiver, IHD-410PR. They can be used as an audio, video and IR extender over IP and applied to point to point, point to multi-point, multi-point to multi-point and eye-catching video walls of up to 16 by 8 displays. - Page 8 IHD-410PT / IHD-410PR Exclusive Video Transmission by IGMP Snooping Technology One IHD-410PT in local site can drive multiple IHD-410PRs in remote sites without consuming extra network loading. Integrated with PoE switch built-in with IGMP snooping function, there are 64 channels selectable via the IHD-410 series, so video and audio can be transmitted simultaneously.
- Page 9 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR with Automatic EDID Copy function, the IHD-410 series allows the system to copy EDID information from EDID compliant displays and assures accurate display performance. Video Channel Setting Matches Well through Network Configuration The IHD-410 series network can be configured by a central computer over the same LAN within a certain distance.
- Page 10 Where there is more than one transmitter in the video extend system, the DIP switch in the IHD- 410PT and IHD-410PR facilitates distinguishing the pair of the transmitter and receiver units in the same channel. It further enables the broadcasting system to perform multiple video extend systems simultaneously through matching of the IHD-410PT and IHD-410PR.
-
Page 11: Features
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 1.3 Features HDMI Network 4K ultra high-quality video transmitter Supports IR extension for controlling video source Supports RS-232 bi-directional remote extension Assigns video sources to any monitor of the video wall system ... -
Page 12: Product Specifications
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 1.4 Product Specifications Model IHD-410PT IHD-410PR Hardware Specifications Network Interface RJ45 port (10/100/1000BASE-T Ethernet) x 1 Serial Interface DB-9 female connector for RS232 x 1 ACT LED x 1... - Page 13 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Model IHD-410PT IHD-410PR 480i @ 60/50 Hz HDMI Video Out Rotation 0 degrees/180 degrees/270 degrees Compression Visual lossless compression Audio HDMI: 2-ch uncompressed audio General Management Interfaces Web management System Expandability (max.)
-
Page 14: Hardware Interface
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 1.5 Hardware Interface 1.5.1 Diagrams: Transmitter:... -
Page 15: Interfaces
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Receiver: 1.5.2 Interfaces: Transmitter (IHD-410PT) Receiver (IHD-410PR) Interfaces Definition: Position Description Function Connect to a LAN Switch. IGMP snooping and jumbo frame supported Gigabit IEEE 802.3af/at PoE+ Ethernet switch is recommended. - Page 16 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Position Description Function switch, the LED will be always on. Transmitter: HDMI Type-A female connector for connecting to the HDMI HDMI source. Receiver: HDMI Type-A female connector for video output.
-
Page 17: Device Connection Topology
Video Wall To bring the image and picture in larger size over video wall, the IHD-410PT and IHD-410PR are the ideal solution to distributing one specified image, picture, or video to multiple screens which are... - Page 18 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Ideal Solution for Wide Variety of Commercial Installation Environments The IHD-410 series supports 100m over single Cat5e/6 cable at point to point, as well as point to many and many to many over Gigabit Ethernet switch.
-
Page 19: Chapter 2. Hardware Installation
2.2 Installation Instructions 1. Connect the video source to the Transmitter (IHD-410PT) unit’s HDMI In interface. 2. Connect the monitor to the Receiver (IHD-410PR) unit’s HDMI Out interface. 3. Set an identical ID number on DIP switch for all units of the same group. -
Page 20: Chapter 3. Preparation
4. Apply the proper power to the Transmitter, Receiver, switch and monitor. 5. The monitor will show the information shown below. Description Function Show the date of firmware. Local IP Show the IHD-410PR’s IP address. Remote IP Show the connected IHD-410PT’s IP address. Show the IHD-410PR’s MAC address. -
Page 21: Find The Ip Address Via Bonjour Browser Software
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 3.2 Find the IP Address via Bonjour Browser Software The Bonjour Browser is a free third-party software. User is able to download it from internet. The supported Bonjour Browser version is shown below. -
Page 22: Setting Tcp/Ip On Your Pc
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Default DIP switch is 0 and the four digits are 0000. Please refer to the form below. For example, if the position is set to 7, then you’ll see ast-gateway 1110. - Page 23 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 2. Right-click on the Local Area Connection and select Properties. 3. Select Internet Protocol (TCP/IP) and click Properties.
- Page 24 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4. Select "Use the following IP address". IP address: You have to set the same network segment between your PC’s IP address and the transmitter/receiver. For example, if the transmitter’s IP is 169.254.0.1, then you should set your PC’s IP address to 169.254.0.xxx where xxx can be any number between 2 and 253.
-
Page 25: Windows 7
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 3.3.2 Windows 7 If you are using Windows 7, please refer to the following: 1. Click on the network icon from the right side of the taskbar and then click on “Open Network and Sharing Center”. - Page 26 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 3. Right-click on the Local Area Connection and select Properties. 4. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties or directly double-click on Internet Protocol Version 4 (TCP/IPv4).
- Page 27 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 5. Select "Use the following IP address". Select "Use the following IP address". IP address: You have to set the same network segment between your PC’s IP and the transmitter/receiver.
-
Page 28: Windows 10
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 3.3.3 Windows 10 If you are using Windows 10, please refer to the following: 1. In the search box on the taskbar, type View network connections, and then select View network... - Page 29 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 2. Right-click on the Local Area Connection and select Properties. 3. Select Internet Protocol Version 4 (TCP/IPv4) and click Properties or directly double-click on Internet Protocol Version 4 (TCP/IPv4).
- Page 30 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4. Select "Use the following IP address". Select "Use the following IP address". IP address: You have to set the same network segment between your PC’s IP and the transmitter / receiver.
-
Page 31: Chapter 4. Web-Based Management
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Chapter 4. Web-based Management Before doing configuration, ensure that all remote displays and all network cables are connected correctly. (Video source is required.) Double-click the device’s name in Bonjour Browser and then get to the Web UI, or you can simply type the device’s IP in the address bar. -
Page 32: System
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.1 System 4.1.1 Version Information Here user can see the current date and the firmware version information. 4.1.2 Update Firmware Here is for user to update firmware. Some functions or issues may have to be improved by updating the firmware. -
Page 33: Utilities
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.1.3 Utilities User can restore the device to factory default setting, reboot device, reset EDID, even console API command is issued here. Usually, the API command is for engineers to use, but not for end users. -
Page 34: Statistics
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.1.4 Statistics Below is the detailed information on ID, IP, unit status, casting mode, etc. -
Page 35: Video Wall
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.2 Video Wall 4.2.1 Basic Setup Click on Video Wall Setup tab for Basic Setup first. - Page 36 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.2.1.1 Bezel and Gap Compensation: OW = Outside Width OH = Outside Height VW = View Width VH = View Height Adjust dimensions (mm) for the monitors of video wall. If you don’t need this, just set all values...
- Page 37 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.2.1.2 Wall Size and Position Layout: Step 1 Vertical Monitor Count x Horizontal Monitor Count: If the video wall is 2 x 2, then set up Vertical Monitor Count and Horizontal Monitor Count as 2.
- Page 38 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR User can according to the number do individual control with the corresponding receiver’s IP. Vertical Monitor Count: The number of monitors on vertical line. Horizontal Monitor Count: The number of monitors on horizontal line.
-
Page 39: Setup Steps (Examples)
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.2.2 Setup Steps (Examples) 4.2.2.1 1 x 2 video extender If you want to set a 1 x 2 “video extender” as shown in the following picture, you may refer to the... - Page 40 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Step 3 Apply To: Select one of the clients by the OSD number for configuring the video wall setting one by one. After all settings are done, you can uncheck OSD item.
-
Page 41: Advanced Setup
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Step 3 Apply To: Select one of the clients by the OSD number for configuring the video wall setting one by one. For video wall application, it is NOT suggested to set up your screen array as N (row) x 1 (column) when horizontal resolution is greater than 1280 pixels. - Page 42 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Step 2: Control Options Description Function Reset to Basic Setup If users make incorrect operations, press “Reset” to restore basic setup. Stretch Type Set up the video output to “Fit In’ or “Stretch Out” mode in the screen.
- Page 43 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Description Function Set up the number of vertical and horizontal monitor based on the video Screen Layout wall layout. Vertical number 1~8 and horizontal number 1~16. Set up the row position of monitor, number from 0 to the total number of Row Position vertical monitor.
-
Page 44: Network
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.3 Network User can set the IP mode of each unit here and also can change the casting mode. 4.3.1 IP Setup Description Function Auto IP By default, each device is auto IP mode; the IP is 169.254.xxx.xxx. - Page 45 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Unicast is a one-to-one connection between the client and the server. Unicast uses IP delivery methods such as Transmission Control Unicast Protocol (TCP) and User Datagram Protocol (UDP), which are session-...
-
Page 46: Function
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.4 Function Here user can make settings for IHD-410 series. 4.4.1 Video over IP Description Function By default, the function is set as enable. Enable Video over IP If users uncheck this item, then it can’t work. -
Page 47: Usb Over Ip
Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Description Function Set up the time of stopping the video when detecting video lost. By default, the time is 10 seconds. Timeout for Detecting Video Lost 4.4.2 USB over IP... - Page 48 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR 4.4.3 Serial over IP Usually, it is recommended that the Serial over IP function is for engineer to use, but not for end users. Please do not change the settings.
- Page 49 Basically, there are so many third-party search tools that can be used, as long as you can find the IP of the unit. If you want to use Bonjour Browser, please e-mail to us (support@planet.com.tw) and we will provide it to you.
- Page 50 You can set port-based VLAN for the Transmitter (IHD-410PT), and then for the receiver (IHD- 410PR). You can just dynamically swap the receiver port to a different VLAN for video source change.
- Page 51 1. The PC installed Bonjour Browser is not in the same LAN as IHD-410PT or IHD-410PR. 2. The IP address of PC might be in a different subnet from IHD-410PT/IHD-410PR. Please set the PC’s IP address in the same subnet as IHD-410PT/IHD-410PR.
- Page 52 Q15: How to use IR extension on IHD-410PT and IHD-410PR? Please refer to the steps below: 1. Connect the IR emitter cable to IHD-410PT, and make IR emitter cable focus to video source device. 2. Connect the IR receiver cable to IHD-410PR.
- Page 53 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Q17: How can I connect one video source to two or more Tx ? It is recommended to use HDMI splitter with two or more ports. Q18: The output monitor which is connecting to IHD-410PR does not display any video or show wrong color video.
- Page 54 Video Wall Ultra 4K HDMI/USB Extender over IP with PoE IHD-410PT / IHD-410PR Q20: Please specify the traffic bandwidth based on one pair of IHD-410PT and IHD-410PR stream. There are too many factors that are able to affect the bandwidth and compression ratio that depends on your video format, resolution, etc.
