HPHA36C5H TROWEL— OPERATION AND SAFETY DECALS

OPERATION AND SAFETY DECALS

The HPHA36C5H walk-behind trowel is equipped with a number of operation, safety and maintenance decals. Should any of these
decals become unreadable, replacements can be obtained from your dealer.
DO NOT LIFT MACHINERY BY GUARD
RING. MAY CAUSE DAMAGE TO
GUARD RING SHOCK MOUNTS
USE LIFT HANDLES ONLY
PRELOAD TRIM INDICATOR
J
FINISH
PAGE 12 — HPHA36C5H WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #3 (07/06/10 )
CAUTION
P/N 1261
P/N 20816
P/N 1736
B
FINISH
COMBO COMBO
P/N 1735
Symbol indicates that it is mandatory to wear
safety glasses, safety helmet and ear protection.
P/N 11247
(Part of decal kit 12620)
Symbol indicates that it is mandatory to wear
gloves.
P/N 11247
(Part of decal kit 12620)
Radiating heat symbol. Symbol indicates equipment
is hot.
P/N 11246
(Part of decal kit 12620)
Symbol for examining or checking of the machine.
Mostly used for maintenance. Check lubrication
oil in gearbox.
P/N 11246
(Part of decal kit 12620)
Figure 1. HPHA36C5H Trowel Decals
WARNING!
INJURY COULD RESULT IF FINISHER IS LIFTED
WITHOUT PITCH HANDLE FIRMLY ENGAGE
WARNING!
DO NOT OPERATE HANDLE UNTIL IT IS
SECURELY FASTENED TO POWER TROWEL
& INSTRUCTIONS HAVE BEEN READ
P/N 20815
P/N 20814
NAMEPLATE
P/N 20526
P/N 20527
P/N 20820
CONTACT MULTIQUIP
SERVICE DEPT.
Symbol indicates that it is mandatory to
wear safety shoes, with extra protection
(steel toed).
P/N 11247
(Part of decal kit 12620)
This is the symbol for belt drive.
P/N 11246
(Part of decal kit 12620)
This is the symbol for gear drive.
P/N 11246
(Part of decal kit 12620)
