3. Place the centrifugal safety stop switch (Figure 23) in the
"ON" position.
Figure 23. Centrifugal Safety Stop Switch
4. Place the Choke Lever (Figure 24) in the " CLOSED "
position
Figure 24. Engine Choke Lever
5. Grasp the starter grip (Figure 25) and slowly pull it out. The
resistance becomes the hardest at a certain position, corre-
sponding to the compression point. Pull the starter grip briskly
and smoothly for starting.
Figure 25. Starter Grip
HPHA36C5H WALK-BEHIND TROWEL — OPERATION AND PARTS MANUAL — REV. #3 (07/06/10) — PAGE 25
HPHA36C5H TROWEL — INITIAL START-UP
6. If the engine has started, slowly return the choke lever
(Figure 24) to the OPEN position. If the engine has not started
repeat steps 1 through 5.
7. Before the trowel is placed into operation, run the engine for
several minutes. Check for fuel leaks, and noises that would
associate with a loose guard ring and/or covers.
8. Test the Safety Stop Switch.
a. With the engine at idle, move the safety stop switch lever
to "OFF" (Figure 23). The engine should shut off.
b. CLEAR THE AREA AROUND THE TROWEL. Move
the safety stop switch lever back to the "ON" position,
restart the engine and let idle. Stand behind the handle
and spin the handle to the right, simulating a runaway
situation. (See Figure 26). Centrifugal force should
throw the safety switch outward to the "OFF" position
thus shutting off the engine.
.
Figure 26. Testing the Centrifugal Safety Stop Switch
9. To begin troweling, push the throttle lever (Figure 27) toward
the " RUN " position.
Figure 27. Throttle (Run Position)
