Evaluation Board User Guide
UG-338
EVALUATION BOARD ARTWORK AND COMPONENTS
Figure 2. Assembly Drawing (Top Side) of the EVAL-ADV7619-7511
HDMI
INPUT A
HDMI
ADV7619
ADV7511
OUTPUT
HDMI
INPUT B
0.1
JUMPERS
2
I
C COMPATIBLE CONTROL BUS
SDRAM
ADSP-BF524
CPU
FLASH
Figure 3. Block Diagram of the EVAL-ADV7619-7511
