Both the RPSD Lock and the RPSD Key have seven LEDs each on their front panels. The
following sections explain the meaning of each LED and their various states.
RPSD Lock
The first LED on the left is the red Power light. This indicates that the power is on. This LED
should remain lit whenever the RPSD Lock is plugged into an electrical outlet.
When first powered up, the LEDs should all blink on and off in unison three times, then settle
into a Locked condition.
Front Panel LEDs
FIGURE B-1
RPSD Lock LEDs
Front Panel LEDs B-1
