AeroWorks 50cc P-51D Mustang ARF-QB Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

50cc P-51D Mustang ARF-QB
(Quick Build)
ASSEMBLY MANUAL
AEROWORKS™
4903 Nome Street, Denver, CO. 80239 - Phone 303-371-4222 - Fax 303-371-4320
E-mail - info@aero-works.net
2009 - Copy write Protected – All Rights Reserved by Aeroworks Inc.
1

Advertisement

Table of Contents
loading

Related Manuals for AeroWorks 50cc P-51D Mustang ARF-QB

Summary of Contents for AeroWorks 50cc P-51D Mustang ARF-QB

  • Page 1 50cc P-51D Mustang ARF-QB (Quick Build) ASSEMBLY MANUAL AEROWORKS™ 4903 Nome Street, Denver, CO. 80239 - Phone 303-371-4222 - Fax 303-371-4320 E-mail - info@aero-works.net 2009 - Copy write Protected – All Rights Reserved by Aeroworks Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page Aeroworks Contact Information ………………………………………………………………. 3 Introduction ……………………………………………………………………………………... 4 Kit Contents……………………………………………………………………………………… 5 Items Needed To Complete ……………………………………………………………………... 8 Tightening and Re-shrinking The Covering ………………………………………………….. 9 Check Seams and Overlaps for Good Seal ……………………………………………………. 11 Wing Assembly………………………………………………………………….……………….. 12 Stab and Elevator Assembly……………………………………………………………………..
  • Page 3 Further, Aeroworks reserves the right to change or modify this limited warranty without notice. In that Aeroworks has no control over the final assembly or materials used for final as- sembly, No liability shall be assumed nor accepted for any damage resulting from the use by the user of the final user-assembled product.

  • Page 4: Introduction

    LIMITED WARRANTY READ It is important to notify Aeroworks of any damage or problems with the model within 30 days of receiving your airplane to be covered under warranty. If you wish to return this air- craft for any reason a 15% restock fee will be charged to the customer. In addition the cus- tomer is responsible for all return shipping cost and all prior shipping cost will not be re- funded.

  • Page 5: Kit Contents

    KIT CONTENTS Sliding Canopy system—painted and installed 50cc P-51D Mustang (1) Cockpit and panel – painted and installed Materials List Left Wing with Aileron, Flap – covered: Pre-drilled BASIC AIRCRAFT PARTS: for the mounting of the control horns (6) 6-32 blind nuts installed for the main retracts mounting Fuselage with pre-installed vertical fin –...
  • Page 6 (1) Template for marking location of bottom air Right Wing with Aileron, Flap – covered: Pre-drilled scoop for the mounting of the control horns (1) Bottom Front Fuse Fillet - painted 6-32 blind nuts installed for the main retracts mounting (2) 4-40 blind nuts installed for the pedestal of (2) Mounting Pedestal for bomb and tank –...
  • Page 7 #10: (24) 6.35mm aluminum engine stand offs. #11: (2) Aluminum stabilizer tubes – 383mm; 176mm anodized black (4) 4-40x16mm hex style head bolts for stab mount- (4) #6 bonded washers for stab mounting (4) 3mm split ring lock washers for stab mounting #12: (1) 300x300mm Midnight Blue Covering (1) 300x300mm Silver Covering...

  • Page 8: Items Needed To Complete

    ITEMS NEEDED TO COMPLETE Hardware • Allen wrenches US and Metric. • Dremel cutting disc and sanding drum tool • Electric drill and selection of bits • Razor saw • Flat head screwdriver • Hobby heat gun • Hobby iron and covering sock •...

  • Page 9: Tightening And Re-Shrinking The Covering

    TIGHTENING AND RE-SHRINKING THE COVERING 1. Remove the rear canopy before applying heat to 3. Using your covering iron with a soft sock, gently the covering. Excessive heat from covering irons apply pressure and rub in the covering. If any or heat guns can cause the canopy to melt or bubbles occur, your iron may be to hot.
  • Page 10 5. Use your heat gun and iron with extreme cau- tion. Take care not to apply too much heat to one area for long periods of time. This may cause the trim colors to over shrink and pull away leaving unsightly gaps on the color lines. The trim stripes are especially vulnerable to over shrinking.
  • Page 11 It is the responsibility of the purchaser / operator to check the covering seams and overlaps for security and a good seal. Aeroworks is not responsible for failure of covering seams or overlaps during flight. Note: If covering continues to lift apply a small amount of thin CA underneath the covering.

  • Page 12: Wing Assembly

    (4) servo mounting blocks, (2) Wood screws to secure servo mounting blocks (1) 6” Servo extension,(1) 24” Servo extension (2) 1 1/4” Servo arms and (2) Aeroworks safety clips as shown below. Note: The ailerons and flaps have been pre-hinged and glued to the wing panels and are ready for flight.
  • Page 13 Place the servo on a flat surface as shown, this Install servo with servo mounting screws. Re- will ensure correct placement of the servo peat servo installation process for all aileron onto the blocks. Use a C-clamp to hold the and flap servos.
  • Page 14 6” extension will be used Note: Use two pieces of thin plywood to protect the for the flap servo. Use an Aeroworks Safety servo mounting plate and servo from being Clip to ensure the plugs will not come apart damaged by the C-clamp.
  • Page 15 16. Pull the flap servo extension out the root end of 14. Remove the balsa stick with the pull string from the wing using the same steps described for the the servo well and tie the pull string to the servo aileron extension.
  • Page 16 18. Re-install the four screws holding the aileron 2. Assemble the pushrod and control horn servo mounting plate to the wing as shown. Re- assembly as shown. The ball link goes peat process for remaining aileron and flap ser- between the left and right sides of the control horn vos.
  • Page 17 6. Correct installation of ball link, flat washer and 4. Use thick CA on each screw prior to brass spacer to servo arm shown below. installing to lock screws in place Note: CA glues have a fast drying time. Remember to work quickly 4-40 Bolt Flat Washer...
  • Page 18 10. Correct flap pushrod installation shown below, the servo arm should be approximately 45 de- 8. Plug the servo into the receiver and turn radio grees to the wing as shown. on. Ensure the servo trim and sub trim is cen- tered.
  • Page 19 13. Attach the airlines to their respective connectors Wing Panel Assembly and pump the system with air ( 100PSI MAX) . Gather the wing joining supplies shown below: This will be your last time to check for air leaks • 30 or 45 Minute Epoxy-Not Supplied in the retract system before the wings are joined.
  • Page 20 2. Dry fit the wing as shown below, light sanding 4. Spread an even amount of 30 Minute Epoxy on of the wing joiner may be required for a perfect the wing root as shown. fit. Note: Pull air lines and servo extension clear and secure with tape to prevent accidental gluing.
  • Page 21 6. Slide the wing joiner into the slot of the left 8. Slide the right wing panel onto the wing joiner wing panel as shown below. and press firmly against left wing panel. 7. Evenly spread epoxy over the right half of the 9.
  • Page 22 10. Slide the included wing tightening dowels into 12. Use Rubbing alcohol to wipe away any excess the holes drilled for the wing mounting bolts as epoxy that has gotten onto the wings surface shown below. Attach a Zip-Tie around the dow- during assembly Let the wing set until the glue els as shown, do not fully tighten until the next is fully cured.

  • Page 23: Stab And Elevator Assembly

    (2) 1 1/4” Servo arms • (2) 36” Servo Extensions • (2) Aeroworks Safety Clips Note: 36” servo extension will be used to connect servos to receiver during a later step. 3. The servo should fit in the servo opening as shown below, if necessary sand the opening slightly if the servo is a tight fit.
  • Page 24 4. Use a pin drill to drill the four servo mounting 6. Following same steps as used in the wing assem- holes as shown below. bly assemble pushrods to horns. Align the con- trol horns over the factory drilled holes. We rec- Note: We recommend the Great Planes Dead Center ommend installing ball link to center hole of tool Part # GPM8130...
  • Page 25 8. Align the left and right sides of the control horns to the mounting holes and secure using six wood screws as shown. 9. Correct elevator pushrod installation shown be- low, the servo arm should be 90 degrees to the stab as shown.

  • Page 26: Rudder And Rudder Servo Installation

    RUDDER AND RUDDER SERVO INSTALLATION 3. Mix epoxy in mixing cup and use a tapered stick Rudder Installation to apply the epoxy inside the pre-drilled holes in the trailing edge of the fin. Apply epoxy to one Gather the rudder, hinges, epoxy, Vaseline, side of each hinge and insert the hinge com- stir sticks, mixing cup and alcohol as shown.

  • Page 27: Tail Wheel Steering

    TAILWHEEL STEERING Mix epoxy in mixing cup and use a tapered Horns, Servo and Pull-Pull Cable stick to apply the epoxy inside the pre-drilled Installation holes in the leading edge of the rudder. Apply epoxy onto each hinge. Gather the rudder control linkage parts shown below.
  • Page 28 • Servo mounting screws • Aeroworks Safety Clips 3. The Pull Pull Cables for the tail wheel steering 5. Install the rudder servo, the output shaft should have been installed at the factory and taped to face the front of the fuse as shown.
  • Page 29 6. Install the 4-40 ball link onto the threaded cou- 8. Thread the brass swag tube onto the steering pull pler as shown below. pull cable. 7. Tip: Use a hobby knife to remove the burrs from 9. Thread the threaded coupler onto the steering the brass swaging tube as shown below.
  • Page 30 12. Pull cable tight and thread cable back through 10. Temporally install the ball link onto the rudder the brass swage tube as shown. servo arm as shown and adjust cable length to remove excess slop. 11. Ensure that the tail wheel is straight when the 13.
  • Page 31 14. Crimp the brass tube with a crimping tool or pli- 16. A drop of thin CA may be applied to the swage ers. tube to help secure the cable. 15. Cut off excess cable as shown. 17. Repeat the steps for the other tail wheel steering pull pull cable.
  • Page 32 RUDDER PULL-PULL INSTALATION 18. Install the servo arm onto the rudder servo as 1. Gather the rudder control linkage parts shown shown below. Tail wheel steering is now com- below. • plete. (2) Pull pull cables • (2) Threaded couplers •...
  • Page 33 5. Gather the rudder control horn parts shown be- 3. Feed the cables through the rear guide tube as low. shown. The guide tube has been removed near • (2) left control horns the tail wheel to allow for proper operation of •...
  • Page 34 7. Align the control horns over the factory drilled 9. Align the left and right sides of the control horns holes. to the mounting holes and secure using six wood screws as shown. 8. Use thick CA on each screw prior to 10.
  • Page 35 11. Tape the rudder to the top edge of the vertical fin 13. Install rudder pull pull cables to the control in the neutral position as shown. This ensures horns using the same method used for the tail the rudder is straight when the cables are at- wheel.

  • Page 36: Engine Installation

    ENGINE INSTALLATION 3. Locate the laser cut engine mounting template Engine Installation for the DA-50. 1. Align cowl to fuse and bolt in place attach mask- ing tape to bottom of fuse Mark the location of Note: If other engines are used a universal tem- the panel lines from the cowl onto the fuse.
  • Page 37 5. Mark the engine mounting hole locations for Align template to firewall and tape template your engine. securely in place. 8. Use a 1/4 drill bit to drill the engine mounting holes in firewall. After drilling is finished, re- move template from firewall. 6.
  • Page 38 9. Using mounting bolts and flat fender washers Throttle/Choke Servo Installation mount engine to firewall. Tighten the bolts evenly to prevent crushing of the firewall. 1. Gather the throttle servo, choke servo and push- rod parts: • (2) 4-40 metal rod threaded at one end •...
  • Page 39 3. Drill a hole through the firewall to allow the 5. Remove the engine in order to enlarge the throt- throttle linkage to pass through and connect to tle and choke pushrod holes as shown. the carburetor. 4. Drill a second hole through the firewall to allow 6.
  • Page 40 3. Assemble the choke servo arm as shown below. Choke Servo Installation The ball link should be on the bottom of the servo arm. Install a 4-40 ball link onto the 4-40 pushrod as shown below. 2. Slide the pushrod through the firewall and attach to the choke lever on the carb as shown below.
  • Page 41 4. Install the choke servo onto the servo mounting 6. Spread an even amount of 5 Minute epoxy on tray using servo mounting screws as shown be- the servo mount where it will be glued to the low. fuse. 5. With the servo arm on servo check alignment of 7.
  • Page 42 8. With the servo arm centered and the choke arm 10. Gather the soldering tools as shown below. centered, measure and mark the end of the choke pushrod wire that will be inserted into the Note: For best results we recommend a high threaded coupler as shown.
  • Page 43 12. Attach the choke pushrod with the 4/40 ball 2. Attach the throttle pushrod with the 4/40 ball links and secure. Power up the receiver and links to the throttle arm on the carb as shown choke servo and adjust pushrod for proper op- below.
  • Page 44 4. Glue the throttle servo mount riser to the fuse 6. Install the servo mount as shown aligning servo side as shown below. to throttle pushrod, allow the glue to fully cure before moving on to the next step. 5. Spread an even amount of 5 Minute epoxy on 7.
  • Page 45 IGNITION INSTALATION 1. Gather the ignition module, ignition battery, 4. Route the nylon ties through the holes drilled in regulator, switch, and mounting hardware as the previous step as shown below. shown. 2. Position the ignition module outside the engine 5.
  • Page 46 Note: We used a “Pin and Flag Switch” to aid in the scale appearance of the airplane. These items can be purchased directly from Aeroworks. 7. Install the ignition battery using the foam pad 9. Install the ignition regulator as shown below.

  • Page 47: Ignition Installation

    10. Drill a hole for the ignition switch as shown be- 12. Ignition installation is now complete. low. 11. Install the ignition switch as shown below. Fol- low the switch manufacturers directions for spe- cific switch mounting instructions.

  • Page 48: Fuel Tank Assembly And Installation

    750cc (26oz) fuel tank has been provided. Note: Fuel line is not provided but can be purchased from Aeroworks 2. Locate the (2) supplied brass fuel barbs. Solder a 4. Solder a brass fuel barb to the other end of the brass fuel barb to the fuel line pick up tube.
  • Page 49 5. Final assembly of rubber fuel stopper with fuel 7. Install the fuel tubing and clunk. Secure the fuel pick up tube shown below. tubing with nylon ties to the pick-up tube and clunk. 6. Install air vent tube into rubber stopper and bend 8.

  • Page 50: Fuel Tank Installation

    Note: It is recommended you always use a fuel filter in the fuel line to the carburetor. Note: The fuel line, fuel “T”, fuel filter are not supplied, but are available through Aeroworks.
  • Page 51 6. Install foam rubber pad for fuel tank to rest on. 4. Use small nylon ties to secure fuel line. Foam rubber will help prevent fuel from foam- ing or getting air bubbles from engine vibration Note: Gasoline will cause the fuel line to swell over time.
  • Page 52 8. Attach the fuel line to the carburetor as shown. 10. Drill a hole in the bottom of the fuse to allow the Use a small nylon tie to secure the hose to the vent line to exit as shown below. carburetor.
  • Page 53 12. Gather the fuel filler dot (supplied) and drill bits 14. Glue the fuel filler dot mount in place using as shown below. thick CA as shown below. Note: We recommend you start with a smaller size drill bit then increase the bit size to the correct size to fit your filler dot.

  • Page 54: Air Fill Valve Installation

    Air Fill Valve Installation 1. Gather the air fill valve (supplied) as shown be- 3. Locate the yellow air fill valve line as shown low. below. 2. Use a 1/4” drill bit to drill the mounting hole for 4. Use a heat gun to soften the air line as shown. the air fill valve as shown below.
  • Page 55 5. Attach the hose the fill valve as shown below. Use the mounting nut to securely fasten the air valve to the fuse side as shown below. 6. Mount fill valve from the backside as shown below.

  • Page 56: Air Scoop Installation

    Air Scoop Installation 1. Gather the air scoop, wing mounting bolts, wing 3. Use a hobby knife to remove covering for wing bolt guide tubes, wing reinforcement discs and reinforcement discs as shown below. bottom fuse fillet as shown below. Note: Nylon bolts shown in manual have been re- placed with metal bolts and washers for extra strength.
  • Page 57 5. Apply 5 minute epoxy to wing reinforcement Locate the rear air scoop and mounting tem- discs as shown below. plate as shown below. 6. Use wing mounting bolts to securely hold wing 8. Align rear scoop to fuselage and lightly mark reinforcement discs in place as shown below.
  • Page 58 9. Remove air scoop as shown below. 11. Finished marking pattern shown below. Note: Scoop alignment marks drawn on bottom of the wing. 10. Using alignment marks tape air scoop mounting 12. Use a hobby knife to cut the covering away from template to the bottom of the wing as shown.
  • Page 59 13. Use sand paper to roughen the gluing surface of 15. Carefully position the air scoop onto the wing the air scoop as shown. as shown making sure the air scoop is posi- tioned correctly before the glue fully cures. 14.
  • Page 60 17. Remove wing and gather the wing bolt guide 19. Mark guide tubes flush with top of air scoop. tubes and slide them into the precut holes as Remove guide tubes and use a saw or a rotary shown below. cutting tool to remove excess guide tube.
  • Page 61 21. Reinstall guide tubes and use a sanding bar to 23. From the inside use thick CA to glue the guide sand the guide tubes flush with the air scoop as tubes in place as shown below. shown. 22. Remove the masking tape from the air scoop. 24.
  • Page 62 25. Align fillet with fuse and mark the location of 27. Sand the mounting area of the fuse fillet as the bottom fuse fillet onto the wing. shown below. 26. Use a T-Pin to poke holes in the covering along 28.
  • Page 63 29. Install the wing on the fuse, make sure the suran 31. Place the fuse fillet back onto the wing and al- wrap covers the entire front portion of the wing low the glue to dry. mount. 30. Apply thick CA on the inside of the line marked 32.

  • Page 64: Radio Installation

    RADIO INSTALLATION 1. Gather the receiver, battery, switch, and regula- 3. Reinstall the retract control plate using the 4 tor as shown below. wood screws as shown below. 2. Install the receiver battery, receiver, and regula- 4. Be sure to allow easy access to the air line quick tor using the supplied nylon ties and foam pad as disconnects as shown.
  • Page 65 5. Final radio installation shown below. 6. A 2.4GHz resister has been included. This unit will be installed between the landing gear se- quencer and the receiver. It is very important that this unit is installed, if it is not installed it may cause RF interference with some 2.4 Radio systems.

  • Page 66: Cowl Installation

    COWL INSTALLATION 1. Gather the following material for making a cowl 3. Cut the template material to 5” wide as shown cutout template. below. This will allow the template to correctly fit on the cowl. Hobby Knife, Ruler, Tape, Felt tip pen or marker Template material has been supplied.
  • Page 67 5. Tape template to fuse bottom transfer alignment 7. Using a hobby knife cut out template for cylin- marks onto template. Use masking tape to se- der head. curely hold the template to the fuse. 8. Reattach the template to fuse and check to see if 6.
  • Page 68 Attach the muffler to the motor at this time. 12. Dry fit template and check to see if the template Leave the template attached to the fuse. lines up correctly. It may be necessary to make small adjustments to the cut out at this time. 10.
  • Page 69 Always check the operating temperature of your engine to prevent any damage from occurring. Aeroworks is not responsible for damages incurred from improper engine cooling. 15. Mark cut lines with removable marker.
  • Page 70 Finished cowl installation shown below.

  • Page 71: Spinner And Prop Installation

    Spinner and Prop Installation 1. Gather the following items as shown below. 3. Remove the spinner back plate from the nose • Spinner (supplied) cone as shown. Make certain holes are aligned • correctly. Prop (not supplied) • Drill jig guide (not supplied) •...
  • Page 72 5. Use a bolt, and plywood spacer to securely fas- 7. Use a drill press to drill the holes through back ten the drill guide to the back plate as shown. plate for the prop bolts as shown. Take your time on this step, it is very important that the holes are drilled correctly.
  • Page 73 9. Align the prop between the two marks made in a 11. Slide the nose cone over the prop and onto the previous step. This will ensure that the prop back plate as shown. lines up correctly with the spinner. 10.
  • Page 74 13. Check and make sure that the prop does not 15. Using a drill press drill through the drill jig come in contact with the spinner. If it does use a guide and back plate and into the prop. This will dremel tool to remove the material around the keep the prop aligned with the back plate.
  • Page 75 17. Install the prop and spinner using the prop mounting bolts included with your engine. 18. Spinner and prop installation are now complete.

  • Page 76: Decal Installation

    DECAL INSTALLATION Decals Available through Aeroworks 1. Placement of OPTIONAL decal package 2. Placement of OPTIONAL decal package shown, included decals will differ. shown, included decals will differ.

  • Page 77: Preflight Preparation

    2. Connect aileron extensions, flap extensions, and air lines to their respective positions in the fuse and wing. Use an Aeroworks Safety Clip to en- sure the plugs will not come apart from vibration 4. Tighten the wing mount bolt as shown. Over or light tension.
  • Page 78 Secure elevator extension at this time, us and Aeroworks safety clip to keep the connector from loosening in flight. 6. Slide the rubber backed washers on the stab 8.

  • Page 79: Drop Tanks And Drop Bombs Installation

    Drop Tanks and Drop Bombs Installation 1. Gather the drop tanks or drop bombs, mounting 3. Tighten mounting bolts to the blind nuts prein- bolts, mounting pylons, and pylon mounting stalled in the wing as shown. It may be necessary bolts.

  • Page 80: Center Of Gravity

    Move the battery or add small at the Wing Tip stick on weights to the nose or tail as necessary. 2. Balance the 50cc P-51D Mustang ARF-QB without fuel in the tank with the batteries in- stalled and ready to fly with gear retracted. The...

  • Page 81: Control Throws

    CONTROL THROWS 1. The amount of control throw should be adjusted 4. Location for throw meter to measure Flap throw using mechanical means as much as possible and in degrees. then electronically with the radio. The control throws are shown in degrees and inches of de- flection measured at the widest point of the con- trol surface for both low and high rates.
  • Page 82 6. Measure the rudder deflection in inches from bottom of the rudder...

  • Page 83: Control Throw Deflection Table

    Batteries: Transmitter, ignition and receiver bat- Control Throw Deflection Table teries are fully charged. Fasteners: Check all engine bolts, wing bolts, Low Rate High Rate hatch bolts, servo screws, control horn bolts, wheel collars, and clevis keepers are tight and Aileron 1/2”...
  • Page 84 Flight Envelope The 50cc P-51D Mustang ARF-QB is capable of many scale maneuvers. After you gain some confi- dence and experience flying the airplane you can cut loose and perform any maneuver you can think of. Here is a list of some of the more popular scale ma- neuvers you can try: •...
  • Page 85 50 cc P-51D Mustang ARF-QB NOTES ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ __________________________________________________________________________...
