AeroWorks 50cc Pitts Python ARF-QB Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

(Quick Build)
ASSEMBLY MANUAL
AEROWORKS™
401 Laredo Unit "D", Aurora, CO. 80011 - Phone 303-366-4205 - Fax 303-366-4203
E-mail - info@aero-works.net
2007 - Copy write Protected – All Rights Reserved by Aeroworks Inc.
1

Advertisement

Table of Contents
loading

Related Manuals for AeroWorks 50cc Pitts Python ARF-QB

Summary of Contents for AeroWorks 50cc Pitts Python ARF-QB

  • Page 1 50cc Pitts Python ARF-QB (Quick Build) ASSEMBLY MANUAL AEROWORKS™ 401 Laredo Unit “D”, Aurora, CO. 80011 - Phone 303-366-4205 - Fax 303-366-4203 E-mail - info@aero-works.net 2007 - Copy write Protected – All Rights Reserved by Aeroworks Inc.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page Aeroworks Contact Information ………………………………………………………………. 3 Introduction ……………………………………………………………………………………... 4 Kit Contents……………………………………………………………………………………… 5 Items Needed To Complete ……………………………………………………………………... 8 Tightening and Re-shrinking The Covering ………………………………………………….. 9 Check Seams and Overlaps for Good Seal ……………………………………………………. 10 Wing Assembly………………………………………………………………….……………….. 11 Stab and Fin Assembly…………………………………………………………………………..
  • Page 3 Further, Aeroworks reserves the right to change or modify this limited warranty without notice. In that Aeroworks has no control over the final assembly or materials used for final as- sembly, No liability shall be assumed nor accepted for any damage resulting from the use by the user of the final user-assembled product.

  • Page 4: Introduction

    INTRODUCTION Your new 50cc Pitts Python ARF-QB is a highly aerobatic airplane. It is capable of both pre- cision and 3-D maneuvers. The aircraft builds easily, quickly, and precisely due to its state of the art CAD design, LASER cut technology, and high quality included hardware. We hope you enjoy building and flying your 50cc Pitts Python ARF-QB.

  • Page 5: Kit Contents

    KIT CONTENTS 50cc Pitts Python ARF-QB Top Wing with Aileron – pre-glued at factory, covered: Materials List (8) 6-32 blind nuts installed for the Outer and Inner struts mounting. Basic Aircraft Parts (14) pin point hinges glued Fuselage – covered, firewall installed and fuel-proofed: (2)Aileron servo string installed (2) 1/4”...
  • Page 6 Vertical Fin with Rudder with (7) pin point hinges (not outer cabane glued) – covered (2) Pilot holes pre drilled for control horns mounting (2) 1/4 - 20 x 2” Nylon Bolts for the bottom wing mounting SUB ASSEMBLIES (4) 4-40 3” two end threaded pushrod with nuts and (1) Fiberglass Cowling—painted with (4) screw holes clevises for ailerons (4) 4-40x14mm hex style bolts for mounting of the...
  • Page 7 #10: (24) 6.35mm aluminum engine stand offs. #11: Tail Section flying wires - Pre-made (4) 0.6x350mm plastic coated steel cable (4) 0.6x260mm plastic coated steel cable (8) Right hand threads Rods – R1&R3 (8) Left hand thread Rods – L2&L4 (6) M3x20mm Phillip head bolts (6) M3 Hex nuts (4) T2.6x10mm PWA screws...

  • Page 8: Items Needed To Complete

    ITEMS NEEDED TO COMPLETE Hardware • Allen wrenches US and Metric. • Dremel cutting disc and sanding drum tool • Electric drill and selection of bits • Razor saw • Flat head screwdriver • Hobby heat gun • Hobby iron and covering sock •...

  • Page 9: Tightening And Re-Shrinking The Covering

    TIGHTENING AND RE-SHRINKING THE COVERING 1. Open your kit slowly and take care not to dam- 3. If bubbles persist, use a small pin to punch holes age any parts of the kit. Remove all parts from in the bubble to relieve trapped air and reheat. their plastic protective covers for inspection.
  • Page 10 IMPORTANT: It is the users responsibility to check the covering seams and overlaps for security and a good seal. Aeroworks is not re- sponsible for failure of covering seams or overlaps during flight. This is a never ending process that must be done after each flying secession.

  • Page 11: Wing Assembly

    WING ASSEMBLY Attach the 6” extension to the servo lead and Aileron Servo Installation secure with safety wire, string, tape, or other 1. Gather the aileron servos, pushrods, control method. Ensure the plugs will not come apart horns, mounting screws and 4-40 ball links as from vibration or light tension.
  • Page 12 Secure with tape so that the string pulls from Install servo in servo well with the output arm toward the leading edge of the wing. Drill . Taper the tape to the front end of the plug holes for servo mounting screws. avoid hang-ups inside the wing.
  • Page 13 Aileron Control Linkage Installation 3. Place the control horns over the predrilled mounting holes. 1. Gather the aileron control linkage parts as shown below. 1 pushrod 2 4-40 ball link assemblies 1 brass spacer 1 left and 1 right side control horn 6 wood screws 2.
  • Page 14 5. Securely fasten the control horn to the aileron 6. Tape the trailing edge of the aileron to the trail- with six wood screws as shown. ing edge of the wing in the neutral position. Plug the servo into the receiver and turn radio on.

  • Page 15: Stabilizer Installation

    STABILIZER - FIN ASSEMBLY Center stab in fuselage Stabilizer Installation 1. Gather the Stab, Elevators and Hinges. 2. Mount bottom wing to fuselage. Slide the stab 4. Align stab to bottom wing. Ensure all dimen- through the pre cut stab slot at the rear of the sions are equal for both left and right sides.
  • Page 16 5. Make alignment marks on stab for easy re- 7. Double check all measurements are equal and alignment during the gluing process. stab is properly positioned before glue dries. 6. Glue stab into fuselage. Be certain to put glue 8. Double check all measurements are equal and onto both the top and bottom sides of the stab.

  • Page 17: Fin Installation

    Fin Installation 3. Using a hobby knife cut away covering to ex- pose the wood at the top of the fuse for the fin to 1. Gather the Fin, Rudder and Hinges. securely glue too. 2. Mark cut lines on the covering were the bottom 4.
  • Page 18 5. Put epoxy into rear section of fuse were the tail 7. Fin glued to fuse shown below. post of fin will be located. 6. Slide fin into position. Tape or hold in place un- 8. Cut two small strips from the supplied white til glue is completely cured.
  • Page 19 9. Fin attached to fuse with seams covered shown 2. Assemble two control horn assemblies for the below. elevators as shown. The ball link goes between the left and right sides of the control horn sides and is secured with a nylon lock nut. Start with the center hole in the control horn.
  • Page 20 4. Use a drop of thick CA glue on each mounting 6. Gather rudder servo with double output arm and screw as shown. rudder pull - pull hardware as shown below. 2 Rudder cables 4 brass swaging tubes 4 Threaded metal RC links (Not Used) 4 Threaded couplers 4 4-40 ball links with mounting hardware 2 Brass Spacers...
  • Page 21 8. Place the control horn over the pre-drilled Elevator and Rudder Hinging mounting holes as shown. Install control horns with mounting bolts and nuts. 1. Prep all hinges for installation by applying Vase- line petroleum jelly or light oil to the hinge joint. This ensures no epoxy gets into the hinge during assembly.
  • Page 22 3. Mix epoxy in mixing cup and use a tapered stick 5. Mix epoxy in mixing cup and use a tapered stick to apply the epoxy inside the pre-drilled holes in to apply the epoxy inside the pre-drilled holes in the leading edge of the elevators.
  • Page 23 3. Mount elevator servo with output shaft facing Elevator Servos and linkage forward. Installation 1. Attach the 24” extension to the servo lead and secure with safety wire, string, tape, or other method. Ensure the plugs will not come apart from vibration or light tension.
  • Page 24 5. Correct installation of ball link and brass spacer Rudder Servo and Pull-Pull Cable to servo arm shown below. Installation 1. Mark and use a 1/16 bit to drill the rudder servo mounting holes. Improperly installed servo linkages can cause ser- vos to strip and elevators to flutter.
  • Page 25 3. Gather the rudder control linkage parts shown 5. Pull the rudder cables from rear of fuse to the rudder servo tray. 2 Rudder cables 4 4-40 ball link assemblies Note: Do not cross cables inside of fuselage. 2 Brass spacers 2 Threaded metal RC links (Not Used) 4 Threaded couplers 4 Brass swaging tubes...
  • Page 26 7. Loop the cable back through the brass swage 9. Crimp the brass tube with a crimping tool or pli- tube as shown. ers. 8. Pull second loop tight against brass swage tube 10. A drop of thin CA may be applied to the swage as shown.
  • Page 27 11. Attach the ball links and brass spacers to the 13. Tape the rudder balance tab to the top leading rudder servo arm and then attach the servo arm edge of the vertical fin in the neutral position as to the rudder servo as shown. shown.
  • Page 28 15. Loop the cable back through the brass swage 17. A drop of thin CA may be applied to the swage tube as shown and pull tight. tube to help secure the cable. 16. Crimp the brass tube with a crimping tool or pli- 18.
  • Page 29 19. Finished rudder cable installation shown below Tail Wire Installation 1. Gather the Pre-Made tail section flying wires and mounting hardware. Note: Long wires fit to the top and short wires fit to the bottom section of tail. 20. Finished rudder cable installation shown below 2.
  • Page 30 3. Install mounting bolts through brass coupler and 5. Top flying wire installation shown below. pre drilled holes in fin and stab. 4. Secure mounting bolts with lock nuts. 6. Attach bottom flying wires to bottom of fuse with mounting screws. Use drop of thick CA glue to secure.
  • Page 31 7. Secure flying wires to fuse bottom. 9. Adjust flying wire tension until wires are taught but not to tight. Overly tight wires will break easier during flight. Note: The brass turn buckles have left and right handed threads to make adjustments easier. Take care not to force the threads the wrong direction and damage or break the turn buckles 8.

  • Page 32: Main Landing Gear And Wheel Pant Assembly

    MAIN LANDING GEAR AND WHEEL PANT ASSEMBLY 1. Gather the landing gear parts as shown below. 3. Fuse shown with hatch cover removed (1) landing gear strut, (2) wheels, (2) axle as- semblies, (2) wheel pants and landing gear mounting hardware. 2.
  • Page 33 5. Assemble the 8-32 landing gear bolts with flat 7. Gather the wheel parts as shown below. washer. Use a drop of blue Loctite on landing (2) wheels, (2) axle assemblies, (4) wheel collars gear bolts before attaching the landing gear. 6.
  • Page 34 9. Align flat sides of axle with edge of landing 11. Install the wheel and outer wheel collar. Use gear. Tighten axle to landing gear. blue Loctite on the wheel collar set screw before final tightening. Note: Test fit wheel pant alignment to main gear prior to tightening axle 10.

  • Page 35: Tail Wheel Installation

    13. Tighten wheel pant with two mounting bolts. Tail Wheel Installation 1. Gather the tail wheel parts shown below. Tail wheel strut and leaf spring, 3 tail wheel mounting screws, steering tiller, 2 tiller mount- ing screws, and 2 steering springs. 14.
  • Page 36 3. Mount the tail wheel steering tiller using two 5. Place the tail wheel leaf spring on top of the tail wood screws. Apply a drop of thick CA to the wheel strut. Position the tail wheel and spring mounting screws before inserting into the tiller on the bottom of the fuse over the pre-drilled mounting holes.
  • Page 37 9. Use pliers to twist spring ends closed around the Mount the tail wheel strut and leaf spring using rudder steering tiller. three wood screws. 10. Cut off excess spring wire as shown. 8. Attach the steering spring to the rudder tiller and tail wheel tiller.
  • Page 38 11. Center tail wheel and bend spring through tail 13. Tail wheel final assembly is complete. wheel tiller. Use pliers to twist spring ends closed around the tail wheel tiller. Note: Ensure rudder is in the centered or neutral position. 12.
  • Page 39 INNER CABANE AND OUTTER STRUT INSTALLATION 1. Gather the Inner cabane and mounting hardware 3. Insert the rear cabane into the pre made rear slot as shown. of the fuselage. Note: To ensure a quick and correct installation of (4) Aluminum Inner Cabanes the inner cabane’s they have been (12) 6-32 x 15mm Hex head bolts pre marked from the factory.
  • Page 40 5. Install front cabane into pre made front slot of 7. Repeat cabane installation steps for other side the fuselage. inner cabane. 6. Left Front and Rear inner cabane inserted into 8. Secure rear inner cabanes with 4-40 x 15mm fuse shown below bolts and flat washer.
  • Page 41 9. Tighten cabane mounting bolts 11. Secure front cabanes using 4-40 x 15mm bolts, flat washers and blue Loctite 10. Pull aileron extension through pre made hole in 12. Gather the outer struts and mounting hardware. radio floor of fuse. (8) Steel “L”...
  • Page 42 13. Place L shaped mounting brackets into mounting 15. Securely tighten L bracket into place slots in bottom wing. 14. Install using 4-40 x 10mm bolt, #6 flat washer 16. Place L shaped mounting brackets into mounting and Blue Loctite to secure slots in top wing.
  • Page 43 17. Install using 4-40 x 10mm bolt, #6 flat washer 19. Attach bottom wing using provided nylon 1/4-20 and Blue Loctite to secure x 2” mounting bolts. 18. Securely tighten L bracket into place 20. Attach top wing to Inner cabane using 4-40 x 15mm bolts and #6 Bonded washers.
  • Page 44 21. Outer struts have been marked at the bottom to 23. Attach outer cabane with 4-40 x 15mm bolts and ensure quick and accurate installation. #6 flat washers. Note: Markings may differ from picture 22. Align outer strut with aluminum L brackets and 24.

  • Page 45: Cowl Preparation

    COWL PREPARATION Important step DO NOT skip The following cowl preparation steps will assist 3. Centered on the tape draw an alignment mark you during a later step to make the cowl installa- onto both the cowl and fuselage tape. tion quicker and more accurate Note: This step will help you to align the paper 1.

  • Page 46: Engine Installation

    ENGINE, MUFFLER, THROTTLE AND CHOKE SERVO INSTALLATION 3. Locate the laser cut engine mounting template Engine Installation for either the DA-50 or 3W-55. If other engines are used the templates may be modified for any 1. The 50cc Pitts Python will accept a wide range mounting pattern of engine types.
  • Page 47 5. Mark the location of the engine mounting holes 7. Align mounting template with firewall and tape on template. in place. 6. Use a 1/4 drill bit to drill the engine mounting 8. Use a 1/4 drill bit to drill the engine mounting holes.
  • Page 48 9. Firewall drilled ready for engine installation 11. Use blue Loctite to secure all mounting hard- ware. Note: Using a flat fender washer behind firewall will help dispense the bolt pressure and help prevent the wood from crushing. 10. Remove engine box top hatch cover 12.
  • Page 49 3. It is recommended to remove the top engine Throttle Servo and Choke Installation mounting hardware from the same side as your Gather the left and right plywood throttle and throttle arm. This will make attaching the ball choke servo mounting trays, the throttle and link to your throttle arm much easier.
  • Page 50 5. Attach ball link to throttle arm of carburetor 7. Assemble servo arm to servo at 90 degrees to servo. Drop servo into provided servo mounting slot in fuse with servo out put shaft to the rear. Align throttle servo with throttle pushrod and mark servo mounting location 6.
  • Page 51 9. Drill throttle servo mounting holes into throttle 11. Remove pushrod from throttle arm on carburetor servo mounting tray. and cut throttle pushrod to length. 10. Install throttle servo to mounting tray. 12. Gather the soldering tools as shown below. Note: For best results we recommend a high quality Silver Solder like “Sta-Brite”...
  • Page 52 13. Solder the threaded brass coupler to the end of 15. Attach the throttle pushrod with the 4/40 ball the throttle pushrod. links and secure. Power up the receiver and throttle servo and adjust pushrod for proper op- eration. Ensure the servo or rod does not bind or jam at closed or full open positions.
  • Page 53 17. If a manual choke will be installed gather the 19. Another view of the manual choke installation choke pushrod, ball link, wheel collar and nylon ties as shown. Wheel collar and ties are not sup- plied. Note: If a manual choke is used it will be necessary to cut a relief or exit hole in the radial engine baffling.

  • Page 54: Ignition Module Installation

    21. DA-50 with Pitts style muffler mounted. 2. Insert provided Velcro strap through the pre cut slots at the engine box bottom Note: 2 1/2” aluminum stand offs used with no other stand offs required. 3. Mount the engine ignition module using the Vel- Ignition Module Installation cro strap and foam rubber as shown.

  • Page 55: Fuel Tank Assembly

    4. Route the ignition wire to the engine as shown Fuel Tank Assembly and secure connectors with safety clip, tape or other method. 1. Gather the fuel tank parts as shown below. There are two tanks provided, 750cc (26oz) for your fuel system and 450cc (16oz) for your smoke system if used.
  • Page 56 3. Locate the (4) supplied brass fuel barbs. Two for 5. Solder a brass fuel barb to the other end of the the fuel tank and Two for the smoke tank. Solder fuel pick up line. a brass fuel barb to the fuel line pick up tube. This will keep the weight of the fuel clunk from pulling the fuel line off the brass tube.
  • Page 57 7. Install air vent tube into rubber stopper and bend 9. Insert the rubber stopper assembly into the tank upward. Air vent tube should rest as close to the with the vent tube at the top of the tank. top of fuel tank as possible. Without touching the top of the tank.
  • Page 58 Note: The fuel “T”, fuel filter and filler dot are not reach the engine carburetor and the filler dot. supplied, but are available through Aeroworks. Note: It is recommended you always use a fuel filter in the fuel line to the carburetor.

  • Page 59: Fuel Tank Installation

    15. Install the vent line to the vent tube in the tank. 2. Thread nylon ties under tank mounting plate and center in position. Install foam rubber pad for Note: We recommend running your vent line to the fuel tank to rest on. Foam rubber will help pre- rear of the fuel tank like shown below.
  • Page 60 4. Another view of the tank installed shown below 6. Route fuel line through firewall and connect to the engine carburetor as shown Use nylon tie to secure Filler Dot and Vent Exit Line 5. Route the vent line on top of the fuel tank and Installation secure with small nylon ties as shown.
  • Page 61 2. Mark and Drill hole to accommodate fuel filler 4. Locate the supplied Rubber grommets as shown dot. below. Note: We have supplied rubber grommets for you to route the fuel line through to give a finished professional look. 5. Determine the vent line hole location at the bot- tom fuse hatch cover.
  • Page 62 6. Drill hole in bottom hatch cover to accommo- 8. Install fuse bottom hatch. date rubber gourmet 7. Feed vent line tubing through the rubber grom- met in the hatch cover.

  • Page 63: Radio Installation

    RADIO INSTALLATION 1. Gather the receiver, receiver battery, ignition 3. Use a modeling knife to cut out the switch hole. battery, regulators, switches, Velcro straps and foam rubber as shown. 2. We chose to mount the ignition switch on the 4.
  • Page 64 5. Mount switches in accordance with the switch 7. Insert Velcro straps into mounting slots of radio manufacturers instructions and hardware. Re- floor as shown below. peat switch mounting installation for mounting of the receiver switch. We recommend mounting the receiver switch on the opposite side of the fuselage 6.
  • Page 65 9. Secure ignition battery using Velcro straps. 11. Attach Y– Harness to the servo extension for the top wing 10. Mount receiver battery and receiver regulator 12. Secure Y– Harness with tape or safety clip to using the same steps and techniques as for the prevent from disconnection from vibration ignition.
  • Page 66 13. Install Receiver using Velcro strap and foam 15. Place tape on the antenna and tube, this will rubber keep the antenna from backing out of the tube from vibration. 14. Install the receiver antenna in the pre-mounted antenna tube. Note: Placing baby powder on the antenna will aid in sliding it through the tube.

  • Page 67: Cowl Installation

    COWL INSTALLATION 1. Gather the following material for making a cowl 3. Center line drawn on template shown below. cutout template. Hobby Knife, Ruler, Tape, Felt tip pen or marker Template material has been supplied. 2. Mark a center line down one side of the template 4.
  • Page 68 5. Template shown with both lines drawn ready to 7. Align center line on template with center mark install to fuselage. on tape you installed before the engine installa- tion steps. 6. Remove muffler to make easier installation of 8. Align 3/8” mark across template with the front the cowl template.
  • Page 69 9. Be sure to get the 3/8” reference line you previ- 11. Remove the template. Using a hobby knife cut ously drew lined up with the front edge of the around the lines you just created to make a hole fuselage as shown for the cylinder head.
  • Page 70 13. Measure back 1 1/4” from the Rear Edge of the 15. Measure and mark 3 1/4” from the center line of template. template as shown 14. On 1 1/4” marks, draw a reference line across 16. Measure and mark 2 1/2” from the center line of the Rear of the template template as shown...
  • Page 71 17. Measure and mark 3” back from the 1 1/4” rev- 19. Draw joining lines from the cylinder head cut erence line. out to the front of the hot air exit box as shown 18. Draw a hot air exit and muffler relief hole in the 20.
  • Page 72 Always check the operating temperature of your engine to prevent any damage from occurring. Aeroworks is not responsible for damages incurred from improper engine cooling.
  • Page 73 Always check the operating temperature of your engine to prevent any damage from occurring. Aeroworks is not responsible for damages incurred from improper engine cooling. 2. Gather the included Dummy Radial alignment...
  • Page 74 3. Insert and lift into position the dummy radial 5. Place bolt and washer through front jig plate and engine and alignment jig back plate. screw into blind nut in jig back plate. Hand tighten only it is not necessary to over tighten the jig plates.
  • Page 75 7. Insure Dummy radial is centered in cowling and 9. Run a bead of Thick CA glue around the edge of the position of the dummy cylinders are located the dummy radial engine. correctly. The air inlet cut out should be directly over the engine cylinder.
  • Page 76 Note: Always check the operating temperature of your engine to prevent any damage from occurring. Aeroworks is not responsible for damages incurred from improper engine cooling.

  • Page 77: Decal Installation

    DECAL INSTALLATION Decals Available through Aeroworks 1. Factory placement of decals shown. 2. Factory placement of decals shown.
  • Page 78 1. Decals supplied with the kit may vary from the 3. Remove backing from Clear transfer tape. photos below. Installation step are the same Gather supplied decals, transfer tape, ruler, scis- sors, hobby knife, plastic squeegee or credit card, Windex or Application fluid like Rapid Tac.
  • Page 79 5. Press transfer tape to top of decal. 7. Spray model surface with application fluid, Windex or soapy water solution. 6. Peel backing from decal. 8. Spray back side of decal with application fluid, Windex or soapy water solution.
  • Page 80 9. Position decal in proper location. Application 11. Pull transfer tape from top of decal. Take care fluid will allow decal to be moved slightly. not to pull away or damage decal. 10. Using a plastic squeegee or credit card. Spread 12.
  • Page 81 13. Repeat installation process of bottom decal for 15. Pull transfer tape from top of decal. Take care top decal installation. Use application fluid for not to pull away or damage decal. easier installation 14. Place top decal over bottom decal. Position 16.
  • Page 82 DASH AND PILOT INSTALLATION Available Through Aeroworks 1. If installing pilot or dash remove canopy mount- 3. Reattach canopy using mounting screws. ing screws. Note: Dash panel and pilot available from Aeroworks 2. Glue or screw in dash panel and pilot figure ac-...

  • Page 83: Preflight Preparation

    PRE-FLIGHT PREPARATION 1. Mount the cowl using the cowl mounting bolts 3. Secure extension with safety clip or tape. and rubber backed washers. The rubber backed washers are to prevent the fiberglass cowl from cracking and to prevent mounting bolts from loosing from normal engine vibration.
  • Page 84 5. Attach top wing to inner cabanes with 6-32 x 7. Ensure lock nuts are tight and will not come 15mm bolts and #6 bonded washers. Bonded lose from engine vibration. washer will prevent bolts from coming loose during normal engine vibration and flying. 6.
  • Page 85 9. Glue a small piece of Velcro to the inside of the 11. This will give you a simple and virtually invisi- rear inner cabane and to the side of the safety ble method for connecting the top wing aileron clip.

  • Page 86: Center Of Gravity

    CENTER OF GRAVITY 2. Balance the 50cc Pitts Python ARF-QB without Center of Gravity fuel in the tank with the batteries installed and ready to fly. The engine, radio, servos, and bat- 2 1/4” Back tery you use will determine the final weight and Measured off the Top Wing locations of equipment.

  • Page 87: Control Throws

    CONTROL THROWS 1. The amount of control throw should be adjusted 4. Measure the rudder deflection in inches from the using mechanical means as much as possible and rudder boost tab then electronically with the radio. The control throws are shown in degrees and inches of de- Note: No inch measurements given for rudder.
  • Page 88 9. Slide the throw meter under the rudder boost tab Location for throw meter to measure Elevator throw in degrees. 10. Center the throw meter on the rudder using the 8. Gather the Rudder Throw Meter ( Supplied) and centering marks on the meter to aid with align- scotch tape.
  • Page 89 13. Degrees are measured at the tip of the boost tab 11. Bend the precut positioning tabs down around as shown below. the fin. 12. Secure the tabs to the fin using scotch tape. As shown below...

  • Page 90: Control Throw Deflection Table

    Control Throw Deflection Table Preflight Checks Low Rate High Rate Center of Gravity: Check CG is set properly. Aileron 1 1/2” or 25˚ up 2” or 30˚ up 1 1/2” or 25˚ down 2” or 30˚ down Engine: The engine should run smoothly at all throttle settings with smooth transition from idle to full throttle without stalling or hesita- Rudder...
  • Page 91 Aerobatics The 50cc Pitts Python ARF-QB is capable of any aerobatic maneuver. After you gain some confi- dence and little experience flying the airplane you can cut loose and perform any maneuver you can think of. Here is a list of some of the more popular aerobatic and 3D maneuvers you can try: •...
  • Page 92 50 cc Pitts Python ARF-QB NOTES ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ ___________________________________________________________________________ __________________________________________________________________________...
