ASMB-782 LGA 1155 Intel
Board with 2 PCIe x16 slots (x8 link), 2 PCIe x4, USB
3.0, PCIe Gen III, Quad LANs
Startup Manual

Packing List

Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 ASMB-782 Startup Manual
• 1 Driver CD (user's manual is included)
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note:
Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
http://www.adobe.com/downloads/ (Acrobat is a
trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/applied-computing-
systems/
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/new_de-
fault.aspx
This manual is for the ASMB-782 series Rev. A1
Part No. 2006S78210
Print in China
Xeon
®

Specifications

Standard SBC Functions

• CPU: LGA 1155 Intel
Core™ i3 / Pentium processors
• BIOS: AMI 64 Mb SPI BIOS
• Chipset: Intel
• System memory: Dual Channel DDR3 ECC/Non-ECC
1066/1333/1600 MHz unbuffered DIMM, Max. 32 GB
Note:
• SATA2/SATA3 Interface: 4 SATA2 3 Gb/s ports, 2 SATA3
6Gb/s ports to support Intel Matrix Storage with software
RAID 0, 1, 10 & 5. (for Windows only)
• Serial ports: Two serial ports, only support RS-232
• Parallel port: One parallel port, supports SPP/EPP/ECP
modes.
• Keyboard/mouse connector: Supports standard PS/2
keyboard and mouse
• Watchdog timer: 255 level timer intervals
• USB 3.0: Supports up to four USB 3.0 ports. Two ports
are in rear I/O, and two ports are on-board pin header.
• USB 2.0: Supports up to ten USB 2.0 ports (2* Type-A)

VGA Interface

• Chipset: CPU integrated Intel HD graphics controller
• Display Memory: 1 GB maximum shared memory with 2
GB and above system memory installed
• Resolution:
Supports RGB up to 2048 x 1536 resolution @ 75 Hz
refresh rate
Supports DVI up to 1920 x 1200 resolution@ 60 Hz
refresh rate (DVI cable kit is an optional accessory)

Ethernet interface

• Interface: 10/100/1000 Mbps
• Controller: LAN1:Intel
82574L

Mechanical and Environmental

• Dimensions (L x W): 304.8 x 244 mm (12" x 9.6")
• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 Vsb
• Power consumption: Max. load: +3.3V at 4.69A, +5V
at 1.39A, +12 V at 0.4 A, +12 V(8P) at 3.01A, +5 Vsb at
1.95A, -12 V @ 0.01 A
• Operating temperature: 0 ~ 60° C (depending on CPU)
• Weight: 0.5 kg (weight of board)
1st Edition,
July 2012
E3 V2 ATX Server
®
Xeon
E3 / E3 v2 / 2nd and 3rd
®
®
®
C216
Due to the inherent limitations of PC architecture,
the system may not fully detect 32 GB RAM
when 32 GB RAM is installed.
82579LM; LAN2/3/4: Intel®
®
ASMB-782 Startup Manual 1
