ASMB-786 LGA 1151 Intel® Xeon® E / 8th Gen Core™
ATX Server Board with 4 x DDR4, 7 x PCIe, 6 x USB 3.1,
8 x SATA3, Quad/Dual LANs, IPMI
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 Startup manual
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 1 COM cable
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note:
Acrobat Reader is required to view any PDF
file.Acrobat Reader can be downloaded at:
http://www.adobe.com/downloads/ (Acrobat is a
trademark of Adobe)
For more information on this and other Advantech prod-
ucts, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for ASMB-786 at:
https://advt.ch/searca78a8
Register your products on our website and get 2 months
extra warranty for FREE at:
http://www.register.advantech.com
This manual is for the ASMB-786 series Rev. A1..
Part No. 2001S78610
Print in China
Specifications
Standard Functions
• CPU: Intel LGA1151 Xeon E-21xx / 8th Gen Core i3/i5/i7
series processors
• BIOS: AMI 256 Mb SPI BIOS
• Chipset: Intel C246
• System Memory: Dual Channel DDR4 ECC/Non-ECC
2666/2400/2133 MHz unbuffered DIMM, Max. 64 GB
Note:
• SATA3 Interface: 8 SATA3 6Gb/s ports to support Intel
Rapid Storage Technology Enterprise with software RAID
0, 1, 10 & 5. (for Windows only)
• Serial Ports: Two serial ports onboard, only supports RS-
232 (one can be in rear IO via COM cable connection)
• Keyboard/Mouse Connector: Supports standard PS/2
keyboard and mouse via KMBS1 pin header
• Watchdog Timer: 255 level timer intervals (sec/min)
• USB 3.1: Supports up to six USB 3.1 ports, four Gen2
ports in rear I/O and two Gen1 ports from on-board pin
header
• USB 2.0: Supports up to seven USB 2.0 ports (1* Type-A)
Display Interface
• Chipset: CPU integrated Intel HD graphics controller
• Display Memory: 1 GB maximum shared memory with
2 GB and above system memory installed (BIOS default
is 256 MB)
• Resolution:
- Supports VGA up to 1920 x 1200 resolution @ 60 Hz
refresh rate
- Supports DVI up to 1920 x 1200 resolution@ 60 Hz
refresh rate
- Supports HDMI 2.0 up to 2K/4K resolution @ 60Hz
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1:Intel
I210AT (LAN2 is BMC shared NIC; LAN3/4 is for G4 SKU
only)
Mechanical and Environmental
• Dimensions (L x W): 244 x 304 mm (9.6" x 12")
• Power Supply Voltage: +3.3 V, +5 V, ±12 V, 5 Vsb
• Power Consumption: Max. load: +3.3 V @ 3.44 A, +5 V
@ 2.61 A, +12 V @ 1.04 A, +12 V (8P) @ 6.3 A, +5 Vsb
@ 0.09 A, -12 V @ -0.02 A
• Operating Temperature: 0 ~ 60° C (depends on CPU
1st Edition
speed and cooler solution)
August 2018
Due to the inherent limitations of PC architecture,
the system may not fully detect 64 GB RAM
when 64 GB RAM is installed.
I219LM; LAN2 ~ LAN4: Intel®
®
ASMB-786 Startup Manual 1
