Basic Layout; Ii. Basic Layout - satmap active12 User Manual

ii.

Basic Layout

GPS Lock Icon
Lanyard Point
Insert SD Card
Location Icon
Trail Taken
Large Side/Front
Multifunction Keys
Side/front press
nable one-
keys e
handed operation.
Buttons are variable
(depending on the
screen shown)
Screen 3.4 in / 8.7cm
and can be set to
Width 3 in / 7.5cm
activate with 1-click
Height 5.1 in / 13cm
or 2-click operation .
Depth 1.4 in / 3.5cm
Weight 6.2 oz / 175g
Software v3.0.9915
SiRF III GPS SiRF III GPS
4
Bluetooth Icon
Stats Recording
Toggle Map Icon
Lanyard Point
Battery Indicator
Replaceable
Screen Cover
Backlight Boost
On/Off
Planning Icon
3.5 in / 8.7cm
Bright, Hi-Res
HVGA (320x480)
Screen
Weatherproof,
Toughened
Impact Casing
9 Function
Joystick
Mini USB
Lock/
Unlock
Removable
Battery Back
Can be replaced
with a Battery
Back for
mounting on a
bike or in a car,
or with a Slimline
Battery Back for
a lighter unit with
a lower profile.
