ii. Basic Layout
GPS Lock Icon
Backlight Boost Button
Backlight Level Icon
Screen : 8.7cm
Width : 7.1cm
Height : 14.7cm
Depth : 3.5cm
Weight : 310g
Location Icon
Planning Icon
Trail Taken
Large Side/Front
Multifunction Keys
Side/front press keys
enable one-handed
operation. Buttons are
variable (depending
on the screen shown)
and can be set to
activate with 1-click or
2-click operation .
Software v3.0.11065
uBlox Max GPS
Insert SD Card
Bluetooth Icon
Stats Recording
Toggle Map Icon
Battery Indicator
On/Off
3.5 in / 8.7cm
Bright, Hi-Res
HVGA (320x480)
Screen
Weatherproof,
Toughened
Impact Casing
9 Function
Rocker pad
microUSB
4
Lanyard Point
