ii. Basic Layout
GPS Lock
Lanyard Point
Insert SD Card
Location Icon
Trail Taken
Large Side/Front
Multifunction Keys
Side/front press
keys enable one-
handed operation.
Buttons are variable
(depending on the
screen shown)
Screen 3.4 in / 8.7cm
and can be set to
Width 3 in / 7.5cm
activate with 1-click
Height 5.1 in / 13cm
or 2-click operation
Depth 1.4 in / 3.5cm
(section 7.16).
Weight 6.2 oz / 175g
© Satmap Systems Ltd
SiRF III GPS
4
Toggle Icon
Lanyard Point
Battery
Indicator
Replaceable
Screen Cover
Backlight
Boost
On/Off
Stop/
Record Icon
Planning Icon
3.5 in / 8.7cm
Sunlight
Readable
Transflective
Screen
Weatherproof,
Toughened
Impact Casing
9 Function
Joystick
Mini USB
Lock/
Unlock
Removable
Battery Back
Can be
replaced with
a Battery Back
for mounting
on a bike or
in a car, or
with a Slimline
Battery Back
for a lighter unit
with a lower
profile.
