4.1 Screen 1: GPS MAP (...Cont)

4.1.2 Toggleable Maps

Map toggling is a feature available on all Active
12's. Toggle-enabled MapCards allow you to switch
between different map layers at a particular point
on the same zoom level. For example, you can
flip between the two scales (1:50k and 1:25k) and
the Base Map. It is also possible to toggle between
different map types and map providers.
If a toggle-enabled MapCard is loaded, a mini toggle
symbol appears next to the Stop/Record
the GPS screen in the status bar, indicating the map
inserted can be toggled. This enables the toggle
maps button on the left
.
Please Note: Not all maps are toggleable. Look for
the toggle icon or logo on all of our toggle-enabled
products. The toggle function can also be added
to existing map cards (see satmap.com for further
details on this service).
Toggle icon
Toggle logo
Toggle Symbol
(shown on screen)
Software v3.0.9915
Getting Started:
Insert your SD card. This will load your
screen.
Use the joystick to flip between maps, and select
View Map to access the desired
To access the Map Packs
centre press the joystick (or page forward on the
Primary Screens to POSITION INFO) and select
icon on
Map Packs using the lower left-hand side button.
Toggle between maps by pressing the upper
left-hand side button
seamlessly between different maps without having
to zoom in or out.
Please note: Most detailed maps have a "ceiling",
and will disappear from the screen when zoomed
out above this ceiling. This is intentional, as the map
detail would be too small to observe clearly. If no
other maps are available for toggling, the Toggle
icon will disappear.
Toggle maps button appears
suitable map card is loaded and map areas
and zoom levels overlap.
Toggle maps button appears
toggle function is not available.
Map Packs
GPS MAP screen.
screen at any point,
Toggle maps
(Toggle maps) and switch
bold when
gray when
13
Toggle
icon
OS 1:25 000
scale mapping
OS 1:50 000 scale
mapping
