4.5

Screen 5: MAIN MENU

To access MAIN MENU screen
(GPS MAP → POSITION INFO → TRIP LOG →
MAIN MENU)
The MAIN MENU screen gives access to some of
the Active 12's main functions and settings.
MAIN MENU
The upper half of the screen shows
the title of the Active Map, ie. the loaded
on the MapCard. The lower half of the
screen shows the name of the Active
one at once Route can be Active.
Buttons:
OOI Menu.
Go to OOI Menu. These are Objects of
Interest, and include Points of Interest (POIs), Areas
(AOIs) and Lines (LOIs).
GoTo and Marker.
Set GoTo point/Marker
by coordinates (or postcode: GB only). A
point is a single leg route with a single waypoint.
A Marker allows the measurement of distance and
bearing between any two points.
Spot Button (map screens).
Return to
MAP/ PLANNING map screens
Routes Menu.
Go to ROUTES MENU.
View, Activate, Edit and Delete routes functionaliy.
Settings.
Go to SETTINGS MENU
Primary Screens (Page Forward).
scroll through the primary screens. This can also
be achieved by using the Left-Right action on the
joystick.
Software v3.0.9915
MapPack
MAIN MENU
Route. Only
either
GoTo
GPS
Create,
Press to
Screens
22
MAIN MENU
Map
© Satmap Systems Ltd 2015
Primary
Screens
