SPECIFICATIONS

Printing
Print technology
Build volume
Layer resolution
Position precision
Filament diameter
Nozzle diameter
Print speed
Travel speed
Software
Supplied software
File types
Supported OS
Electrical
AC Input
Connectivity
Physical dimensions
Desktop space
Shipping dimensions
Weight
Shipping weight
Temperature
Ambient operation temperature
Storage temperature
Nozzle operation temperature
Heated bed operation temperature
Sound
Average operational noise
CAUTION: The Ultimaker 2 Extended generates high temperatures and has hot moving parts that can cause injury.
Never reach inside of the Ultimaker 2 Extended while it is in operation. Always control the Ultimaker 2 Extended
with the button on the front or with the power switch on the back. Allow the Ultimaker 2 Extended to cool down for 5
minutes before reaching inside.
CAUTION: When opening the Ultimaker 2 Extended for service, ensure that the power supply is turned off and the
power cable is disconnected from the wall socket.
CAUTION: Only use the power supply provided with your Ultimaker 2 Extended.
Fused Filament Fabrication
223 mm / 223 mm / 305 mm
Fast: 200 micron (0.2 mm)
Normal: 100 micron (0.1 mm)
High: 60 micron (0.06 mm)
Ulti: 40 micron (0.04 mm)
12.5 micron / 12.5 micron / 5 micron
2.85 mm (generally known as 3 mm filament)
0.4 mm
30 mm/s - 300 mm/s
30 mm/s - 350 mm/s
Cura - Official Ultimaker Software
STL / OBJ / DAE / AMF
Windows / Mac / Linux
100 - 240 V
Approx. 1.4 AMPS
50 - 60 Hz
221 Watt max.
Stand-alone SD card printing / WiFi printing ready
357 mm / 342 mm / 488 mm
400 mm / 400 mm / 650 mm
12.0 kg
21.0 kg
15 - 32 °C
0 - 32 °C
180 - 260 °C
50 - 100 °C
49 dBA
