ULTIMAKER 2 EXTENDED AT A GLANCE

1 Display
2 SD card slot
3 Push and rotate button
4 Build plate
5 Build plate clamps
6 Build plate screws
7 Print head
8 Bowden tube
9 Print head cable
10 Material feeder
11 Spool holder
12 Power socket
13 USB socket
14 Power switch
11 12 13 14
9
8
7
4
6
2 1 3
8
9
10
5
11
