Right Side - Motion Computing Motion F5 User Manual

Battery gauge
Microphones
Web camera
(optional)
Docking connector

Right side

Power adapter
port, USB port (F5),
and cover
Power adapter
port, USB port (F5
only) and cover
RFID (optional)
antenna area
Camera (optional)
button
Windows Security
button
Fingerprint reader
Power button
Bar code scanner
(optional)
Chapter 1 Getting Started
Show battery status (page 11).
Record sounds and use for speech recognition (page 17).
Interact over the web (page 15).
Interface for the Docking Station.
Windows Security
button
RFID antenna Camera
area button
Connect the power adapter (page 20).
F5 only: Connect accessories requiring a USB port.
Scan area for reading RFID tags (page 17).
Use to trigger the built-in documentation camera
(page 15).
Use to log on to or lock the system. Equivalent to
Ctrl+Alt+Del on a keyboard (page 14).
Scan your fingerprints for added security. You can also
use the fingerprint reader as a navigation device
(page 14).
Turns the system on and off.
Reads codes from bar code labels (page 16).
Power
button
Fingerprint
reader
Bar code scanner
3
