Motion Computing Motion C5 Quick Reference Manual

®
This Quick Reference Guide provides information for using the
C5 Mobile Clinical Assistant.
NOTE: For additional reference information, see the Quick
Setup included with your C5.

Logging on

After turning on your C5, perform the
following steps:
1. Press the power button.
2. When prompted, press the Windows Security button.
3. Using the pen and the on-screen keyboard, tap in
your password.

Using the pen

Using the C5 pen on the screen is similar to using a mouse to make
selections and open files.
The following table explains the similarities between a C5 pen and
a mouse.
Function Mouse action
Select Point and click
Open a file or Double-click
application
Select and drag Click and drag
Display properties Right-click and
or edit functions hold
(cut, copy, paste)

Using the C5 buttons and LEDs

Function
Directional
control
Programmable A
(to rotate display press
Function and A)
Helpful tip:
Use the Function button to activate the secondary functions of the
Directional Control, Motion Dashboard, and Rotate buttons. For more
information, see the Motion C5 User Guide on your Tablet PC desktop.
Motion Computing and Speak Anywhere are registered trademarks and Motion is a trade-
mark of Motion Computing, Inc. in the United States and other countries. All trademarks or
registered trademarks are properties of their respective owners.
Motion
Quick Reference Guide for Windows XP
Power
button
Windows
Security
button
Pen action
Point and tap the display
Double-tap or double-touch on
the display
Tap or touch and drag on the
display
Hold the pen on the display until
the mouse icon appears, and
then remove the pen tip from the
display
Motion Dashboard
Wi-Fi LED
Battery LED
Bluetooth LED
Programmable B
C5 Mobile Clinical Assistant
TM

Getting started

Familiarize yourself with the following reference materials:
1. Complete the interactive Get Going with Tablet PC tutorial.
(Start > All Programs > Tablet PC > Get Going with Tablet PC)
2. Complete the other useful Tablet PC Tutorials.
(Start > All Programs > Tablet PC > Tablet PC Tutorials)
3. Open and review the Motion Dashboard.
(Start > All Programs > Motion Computing > Motion Dashboard
or see "Using the Tablet PC Buttons" below)
4. Refer to the Motion User Guide if you have any questions.
(Start > All Programs > Motion Computing > Motion User Guide)
Helpful pen tips
• Hold the pen like a regular pen.
• You can rest your hand on the screen.
• Calibrate the digitizer and pen for better pointer alignment
through the Pen & Tablet panel.
• For more information, see the Motion C5 User Guide.
Function button (right-click function)
Pen tip

Helpful bar code scanner tips

• The bar code button is located on the top right-edge of the C5.
• Hold the C5 by the handle to scan. Ensure the scan beam
covers the entire bar code.
• Press the button once to trigger the scanner. Do not hold the
button down when scanning.
• The C5 beeps when the barcode successfully scans.

Optimizing battery life

• Use AC power when available. When the C5 is
connected to AC power, the battery will continue to charge
while using the C5.
• In the Display panel of the Motion Dashboard, adjust the
brightness to the dimmest comfortable brightness level.
• In the Motion Dashboard, set the power button to Stand By
or Hibernate to conserve battery power, to quickly power on
and off, or when not using the C5.
• When not in use, turn off wireless adapters in Motion Dashboard.
• For advanced tips about extending the battery life, go to
www.motioncomputing.com/tips.
Copyright © 2007 Motion Computing, Inc. All rights reserved.
Eraser
(April 2007) P/N 024-02-XXXX Rev. X00
