Technical Specifications - Intelix DIGI-HDUSB Installation Manual

Host Input/Output Connections
USB Input
Video Input
Link Output
5V DC Power
Client Input/Output Connections
USB Outputs
Video Output
Link Input
5V DC Power
USB Performance
Maximum Distance
USB Device Support
USB Hub Support
USB Host Support
Video Performance
Video Resolution & Depth
Color
Latency
Chassis and Environmental
Enclosure Material
Enclosure Dimensions (H x W x D)
Shipping Weight
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power and Regulatory
Power Supply Input
Power Supply Output
Power Consumption
Power Available to USB device at REX
ESD Protection
Product Regulatory
Power Supply Regulatory
Other
Warranty
Diagnostic Indicators (Host Side)
Diagnostic Indicators (Client Side)
Included Accessories
Distances and picture quality may be affected by cable grade, cable quality, source and destination equipment, RF and electrical
interference, and cable patches.

Technical Specifications

One (1) USB Type B Receptacle
One (1) HDMI In
One (1) 8P8C Connector (RJ45 style)
One (1) Barrel (5.5 mm OD; 1.7 mm ID)
Three (1) USB Type A Receptacles
One (1) HDMI Out
One (1) 8P8C Connector (RJ45 style)
One (1) Barrel (5.5 mm OD; 1.7mm ID)
100 m (328 ft) over solid core Category 5e or greater cable
High-speed devices (USB 2.0) - up to 30 Mbps
Full-speed devices (USB 2.0 & 1.1) - up to 12 Mbps
Low-speed devices (USB 2.0 & 1.1) - up to 1.5 Mbps
Any single chain can include up to 4 USB hubs.
EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)
High Definition 1080p, 1920 x 1200, and 4K; Depth: 2D and 3D
36-bit, Deep Color, and x.v. Color
Less than 1ms
Black Anodized Aluminum
112 mm x 175 mm x 30 mm (4.4 in x 6.9 in x 1.18 in)
1.95kg (4.30 lbs)
0°C to +40°C (+32° to +104° F)
20% to 80%, Non-condensing
-20° to +70° C (-4° to +158° F)
10% to 90%, Non-condensing
100V-240VAC / 50-60 Hz / 0.6A
5VDC / 3.0A
15 watts (max)
500mA each port
±15 kV
FCC, CE, IC, RoHS
UL, CUL, CE, PSE, GS, RoHS2
2 years
Power, Link, USB, Video
Power, Link, USB, Video
(2) Power Supplies, USB Cable, HDMI cable, Installation Guide
8001 Terrace Ave, Ste 201
Middleton, WI 53562
608-831-0880
supportlibav@libav.com
rev 150602
