Kramer VP-436N User Manual page 16

im Vertrieb von
6.2.1 The MAIN MENU
i
CONTRAST
BRIGHTNESS
FINETUNE
COLOR
SIZE
SOURCE
OUTPUT
AUDIO
OSD
HDCP ON INPUT
12
www.camboard.de
CAMBOARD Electronics
The range and default values vary according to the input signal.
Mode
Set the contrast
The range and default values vary according to the input signal
Set the brightness
The range and default values vary according to the input signal
See Section 6.2.2
Set the red, green and blue shades (0 to 100, default 48, 48 and 52
respectively)
Select the size of the display: FULL, OVERSCAN, UNDER1, UNDER2,
LETTER BOX and PANSCAN (FULL is the default)
UNDER1 refers to an underscan of 6%
UNDER2 refers to an underscan of 9%
Select the source: (VGA is the default)
Appears as:
CVBS
SVIDEO
YPBPR1
YPBPR2
CVBS means Composite Video Baseband Signal
Select the output resolution from the menu (NATIVE is the default):
Output resolution:
1080i @60Hz
1080p @60Hz
576i
576p
720p @50Hz
1080i @50Hz
1080p @50Hz
1280x800
1680x1050
1920x1200
1440x900
480i @59.94Hz
480p @59.94 Hz
720p @59.94Hz
NATIVE - Select NATIVE to select the output resolution from the EDID of the
connected HDMI monitor
See Section 6.2.3
Set the OSD parameters: H POSITION, V POSITION, TIMER,
BACKGROUND and DISPLAY (see
Select the HDCP option for the HDMI input: either ON (the default) or OFF.
Setting HDCP support to enabled (ON) on the HDMI input allows the
