Page 1: User Manual
Kramer Electronics, Ltd. USER MANUAL Models: VP-420, PC/HD Scaler VP-421, PC/HD Scaler... -
Page 2: Table Of Contents
6.2.4 The “OSD” Submenu Technical Specifications Figures Figure 1: VP-420 PC/HD Scaler – Front and Rear View Figure 2: VP-421 PC/HD Scaler – Front and Rear View Figure 3: Connecting the VP-420 PC/HD Scaler Tables Table 1: VP-420 PC/HD Scaler Front Panel Features... -
Page 3: Introduction
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com 3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com... -
Page 4: Quick Start
Getting Started Quick Start This quick start chart summarizes the basic setup and operation steps. KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 5: Overview
RGBHV or component video input and/or output The machine is fed from an external 5V DC source, making it suitable for field operation. Operate your VP-420/VP-421 directly via the front panel push buttons and the on-screen display (OSD). To achieve the best performance:... -
Page 6: Your Pc/Hd Scaler
For a description of the: VP-420 PC/HD Scaler, see section 4.1 VP-421 PC/HD Scaler, see section 4.2 Your VP-420 PC/HD Scaler Figure 1 and Table 1 define the VP-420 PC/HD Scaler: 1 For example, part number 2535-052002 KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 7: Figure 1: Vp-420 Pc/Hd Scaler - Front And Rear View
Your PC/HD Scaler Figure 1: VP-420 PC/HD Scaler – Front and Rear View Table 1: VP-420 PC/HD Scaler Front Panel Features Feature Function PC/HD OUTPUT 15-pin HD Connects to computer graphics or HDTV acceptor connector PC/HD INPUT 15-pin HD connector... -
Page 8: Your Vp-421 Pc/Hd Scaler
Press to view the on-screen display (OSD) menu. Press together with the – button to reset the display to 720p resolution ENTER button In OSD, press to choose the highlighted menu item. Press together with the + button to reset to XGA KRAMER: SIMPLE CREATIVE TECHNOLOGY... -
Page 9: Connecting The Vp-420/Vp-421 Pc/Hd Scaler
When not in OSD, press to freeze the display Connecting the VP-420/VP-421 PC/HD Scaler To connect your VP-420/VP-421, as illustrated in the example in Figure 3 do the following: 1. Connect a computer graphics or HDTV source to the PC/HD INPUT 15-pin HD connector. -
Page 10: Operating The Vp-420/Vp-421
Operating the VP-420/VP-421 Figure 3: Connecting the VP-420 PC/HD Scaler Operating the VP-420/VP-421 The VP-420/VP-421 is operated directly via the front panel buttons, and via the OSD menu (see section 6.2). Using the Front Panel Buttons During normal operation (without the OSD), the front panel buttons... -
Page 11: Using The Osd
Operating the VP-420/VP-421 Using the OSD You can use the OSD to set a wide variety of parameters. When the MENU button is pressed, the main menu opens allowing access to all the device settings (see Table 4). When setting FINETUNE, COLOR, SIZE, OUTPUT (see Table 5), and OSD (see Table 6) a submenu opens with the applicable parameters. -
Page 12: The Main Menu
Operating the VP-420/VP-421 6.2.2 The MAIN MENU Table 4 defines the MAIN MENU parameters and functions. Table 4: The MAIN MENU Parameters and Functions Parameter Function CONTRAST Adjusts the contrast from 0–100. The default is 50 BRIGHTNESS Adjusts the brightness from 0–100. The default is 47 FINETUNE Adjusts the positioning of the display –... -
Page 13: The "Osd" Submenu
0–8 EXIT Select to exit to the Main Menu Technical Specifications Table 7: Technical Specifications of the VP-420/VP-421 PC/HD Scaler INPUTS: 1 PC/HD on a 15-pin HD connector, RGBHV/YPbPr OUTPUT: 1 PC/HD on a 15-pin HD connector, RGBHV/YPbPr 1 DVI on a DVI connector (VP-421 only) - Page 14 KRAMER: SIMPLE CREATIVE TECHNOLOGY...
