Kramer VP-436N User Manual

Presentation switcher/scaler
Hide thumbs Also See for VP-436N:
Table of Contents

Advertisement

Quick Links

Download this manual
im Vertrieb von
www.camboard.de
CAMBOARD Electronics
K R A ME R E LE CT R O N IC S L TD .

USER MANUAL

MODEL:
VP-436N
Presentation Switcher/Scaler
P/N: 2900-300149 Rev 4
Tel. 07131 911201
Fax 07131 911203
ce-info@camboard.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VP-436N and is the answer not in the manual?

Questions and answers

Related Manuals for Kramer VP-436N

Summary of Contents for Kramer VP-436N

  • Page 1: User Manual

    Vertrieb von CAMBOARD Electronics K R A ME R E LE CT R O N IC S L TD . USER MANUAL MODEL: VP-436N Presentation Switcher/Scaler P/N: 2900-300149 Rev 4 www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 2 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 3 im Vertrieb von CAMBOARD Electronics www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 4: Table Of Contents

    RS-232 Protocol Table Figures Figure 1: VP-436N Presentation Switcher/Scaler Front Panel Figure 2: VP-436N Presentation Switcher/Scaler Rear Panel Figure 3: Connecting the VP-436N Presentation Switcher / Scaler Figure 4: Infrared Remote Control Transmitter VP-436N – Contents www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 5: Introduction

    Vertrieb von CAMBOARD Electronics Introduction Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world of unique, creative, and affordable solutions to the vast range of problems that confront video, audio, presentation, and broadcasting professionals on a daily basis. In recent years, we have redesigned and upgraded most of our...

  • Page 6: Getting Started

    Avoid interference from neighboring electrical appliances that may adversely influence signal quality  Position your Kramer VP-436N away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building.

  • Page 7: Safety Instructions

    Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

  • Page 8: Overview

    CAMBOARD Electronics Overview The Kramer VP-436N is a high quality presentation switcher and scaler. It accepts one of seven inputs: a component video on RCA connectors, computer graphics on a 15-pin HD connector, composite video on an RCA connector, s-Video on a 4-pin connector and two HDMI signals.

  • Page 9: Defining The Vp-436N Presentation Switcher/Scaler

     Remotely, from the infrared remote control transmitter The VP-436N is housed in a 19” 1U rack mountable enclosure, with rack “ears” included, and is fed from a 100-240 VAC universal switching power supply. Defining the VP-436N Presentation Switcher/Scaler This section defines the VP-436N.

  • Page 10: Figure 1: Vp-436N Presentation Switcher/Scaler Front Panel

    Vertrieb von CAMBOARD Electronics Figure 1: VP-436N Presentation Switcher/Scaler Front Panel Feature Function POWER Switch Illuminated switch for turning the unit ON or OFF IR Receiver Accepts IR remote commands INPUT Press to select the composite video input Selector...

  • Page 11: Figure 2: Vp-436N Presentation Switcher/Scaler Rear Panel

    Vertrieb von CAMBOARD Electronics Figure 2: VP-436N Presentation Switcher/Scaler Rear Panel Feature Function HDMI Connector Connect to the HDMI source (from 1 to 2) VGA 15-pin HD Connector Connect to the computer graphics source YC 4-pin Connector Connect to the s-Video source...

  • Page 12: Installing In A Rack

    Vertrieb von CAMBOARD Electronics Installing in a Rack This section provides instructions for rack mounting the unit. VP-436N - Installing in a Rack www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 13: Connecting The Vp-436N

    INPUT connector. Alternatively, you can connect the DVI connector on the DVD player to the HDMI connector on the VP-436N via a DVI-HDMI adapter. When using this adapter, you can connect the audio signal via the terminal block connector 2. Connect a computer graphics source to the VGA 15-pin HD VIDEO INPUT connector.

  • Page 14: Figure 3: Connecting The Vp-436N Presentation Switcher / Scaler

    Figure 11. Connect the power cord (not shown in Figure 12. If required, connect a PC via RS-232, see Section 6.3 Figure 3: Connecting the VP-436N Presentation Switcher / Scaler VP-436N - Connecting the VP-436N www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 15: Controlling The Vp-436N

    FINE TUNE menu (see Section 6.2.2). Using the OSD Menu The control buttons let you control the VP-436N via the OSD menu. Press the:  MENU button to enter the menu (the default timeout is set to 10 seconds) ...
  • Page 16 6.2.4) HDCP ON INPUT Select the HDCP option for the HDMI input: either ON (the default) or OFF. Setting HDCP support to enabled (ON) on the HDMI input allows the VP-436N - Controlling the VP-436N www.camboard.de Tel. 07131 911201 ce-info@camboard.de...
  • Page 17 By factory default this option is set to OFF. The COLOR FILTER feature may improve the output image for certain graphic cards where color fringing is seen. VP-436N - Controlling the VP-436N www.camboard.de Tel. 07131 911201 ce-info@camboard.de...

  • Page 18: Connecting To The Vp-436N Via Rs-232

    INFO - the information is shown for a few seconds Connecting to the VP-436N via RS-232 You can connect to the VP-436N via an RS-232 connection using, for example, a PC. Note that a null-modem adapter/connection is not required. To connect to the VP-436N via RS-232: ...

  • Page 19: Controlling Via The Infrared Remote Control Transmitter

    Vertrieb von CAMBOARD Electronics Controlling via the Infrared Remote Control Transmitter You can control the VP-436N from the infrared remote control transmitter: Keys Function SIZE Set the size of the image displayed POWER Turn the VP-436N ON or OFF...

  • Page 20: Technical Specifications

    19" x 7" x 1U (W, D, H) rack mountable WEIGHT: 2.7kg (6lbs) approx. ACCESSORIES: Power cord, null-modem adapter, rack ears, IR remote control Specifications are subject to change without notice at http://www.kramerelectronics.com VP-436N - Technical Specifications www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 21: Input Resolutions

    2k@60 (2048X1080) Default Communication Parameters RS-232 VP-436N Proprietary Protocol Baud Rate: 9600 Data Bits: Stop Bits: Parity: None Command Format: Example (Select input source: Y 3 0 6[CR] HDMI1): VP-436N - Technical Specifications www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 22: Rs-232 Communication Protocol

    When sending a command, a blank character may precede [CR] if desired Example: Example 1: set brightness value as 32 Send: Y11632[CR] Reply: Z11632[CR][LF] Example 2: get current output resolution. (2 = SVGA) Send: Y421[CR] Reply: Z4212[CR][LF] VP-436N - RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...

  • Page 23: Rs-232 Protocol Table

    MUTE button on remote control Auto adjust FW V6.12 1: Set 0~100 Color: Red 2: Get 1: Set 0~100 Color: Green 2: Get 1: Set 0~100 Color: Blue 2: Get VP-436N - RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 24 OUTPUT HDCP Option 0 : Follow input (FW : 6.29 ) 2: Get 1 : Follow output 3: Set 1: AV Select Input Source 4: Get 2: YC VP-436N - RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 25 3: Set Factory Reset 0: Unknown 1: VGA 2: SVGA 3: XGA 4: Get 0 ~ 24 INPUT Resolution 4: SXGA 5: UXGA 6: 480i 7: 480p VP-436N - RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 26 Key lock 7: Get 1: On 6 : set 0 : Clear Auto Tune Auto Tune (under fine tune) 7 : get 1 : Set Auto Tune VP-436N - RS-232 Communication Protocol www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 27 Vertrieb von CAMBOARD Electronics VP-436N www.camboard.de Tel. 07131 911201 ce-info@camboard.de Fax 07131 911203...
  • Page 28 Vertrieb von CAMBOARD Electronics For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com...
