3.03 Specifications & Design
Features
The following apply to the Master Power Supply only:
1. Controls
ON/OFF Switch, Output Current Control, RUN/
SET/PURGE Switch, Secondary Gas Regulator,
Plasma Gas Regulator, Secondary Mode Switch, Sec-
ondary Water Flowmeter/Regulator, Optional Arc
Hour/Counter Meters
2. Control Indicators
LED Indicators:
AC , TEMP, GAS, DC, PILOT, COOLANT PRES, and
COOLANT COND
Gauges:
Secondary, Plasma, and Coolant Pressure Gauges
3. Input Power
Vo lt a g e F re q u e n cy
2 0 0 5 0 o r 6 0 H z
2 2 0 5 0 o r 6 0 H z
2 3 0 5 0 o r 6 0 H z
3 8 0 5 0 o r 6 0 H z
4 1 5 5 0 o r 6 0 H z
4 6 0 5 0 o r 6 0 H z
5 0 0 5 0 o r 6 0 H z
5 7 5 5 0 o r 6 0 H z
NOTE
Refer to Appendix I for recommended input wir-
ing size, current ratings, and circuit protection re-
quirements.
Amps depends on input voltage (Refer to Appendix
I).
4. Output Power
Master Power Supply:
Continuously adjustable by potentiometer from 50
to 150 amps
With Slave Power Supply:
Continuously adjustable by potentiometer from
100 to 300 amps
INTRODUCTION & DESCRIPTION
Ph a se Am p e ra g e
3 9 8
3 8 9
3 8 5
3 5 1
3 4 7
3 4 2
3 4 0
3 3 4
12
5. Duty Cycle
100%
6. Pilot Modes
Auto-Restart, Pre-Flow Delay, "Recycle Required"
7. CNC Signals
Enable, Start/Stop, OK-To-Move, Pilot Sensing Relay
(PSR), Full CNC Available with Remote
8. Coolant Pressure
Internal Service-adjustable
130 psi (8.8 BAR) at zero flow
120 - 125 psi (8.2 - 8.5 BAR) at 0.6 gpm (2.6 lpm)
9. Coolant Flow Rate
0.5 gpm (2.2 lpm) with 150 feet of total torch and torch
leads at 70°F (21°C)
NOTE
The flow rate varies with lead length, torch con-
figuration, ambient temperature, amperage level,
etc.
10. Cooling Capacity
4,000 to 10,000 BTU
NOTE
Maximum value based on "free flow" condition.
11. Coolant Reservoir Capacity
2 gallons
Capable of handling a total of 150 feet of torch lead
length
12. Secondary Water
Tap water can be used as a secondary gas and must
be capable of delivering the following minimums:
• Water pressure of 50 psi (3.5 BAR)
• Flow of 8 gph (35.2 lph)
NOTES
Tap water should only be used as a secondary gas
on machine torches.
The tap water source does not need to be deionized,
but in water systems with extremely high mineral
content a water softener is recommended.
