Scope of delivery

example of scope of delivery:
1 compact unit
2 Screen
3 vibration decouplers (only
for size 1 units)
4 expansion vessel for heat circuit
5 Safety components for heat
circuit and heat source
6 package with heat pump and heating
regulator, outdoor temperature
sensor, seals, sylomer strips, cap
valve and wall mount for heating
circuit expansion vessel, room
thermostat for cooling function
(only for models with designator
K), compensators (only for size 2
units; in additional cardboard box)
proceed as follows:
Inspect delivery for outwardly visible signs of
damage...
check to make sure that delivery is complete.
Any defects or incorrect deliveries must be claimed
immediately.
notiCe:
note the model.
overview "Technical data/scope of delivery" or
rating plate on unit.
We reserve the right to modify technical specifications without prior notice.
UK830300/170717 © Alpha-InnoTec GmbH

installation and assembly

observe the following when performing all work:
notiCe:
always comply with applicable accident pre-
vention regulations, with applicable statu-
tory regulations, ordinances and directives.
Warning!
the heat pump or heat pump system may
be installed and assembled only by a qualified
technician!
notiCe:
observe the sound levels of the respective
model.
overview "Technical data/scope of delivery",
"Sound" section.
INSTALLATION AREA
Caution.
install the heat pump only indoors.
The installation area must be frost-free and dry. It must meet
the requirements of dIN eN 378. It must also fulfill applica-
ble local regulations.
TRANSpORT TO INSTALLATION LOCATION
To avoid damage during transport, you should transport the
unit to the final installation location in its original packag-
ing (with angle bracket on the wooden pallet), using a lifting
truck.
If it is not possible to transport the unit to the final installa-
tion location using a lifting truck, you can also transport the
heat pump using a hand truck.
Danger!
Several people are required to transport the
unit. Do not underestimate the weight of the
heat pump.
overview "Technical data/scope of delivery", "Gen-
eral unit data" section.
