Rear panel LEDs and buttons

Item
Description
NIC link LED
1
NIC status LED
2

System board components

Status
Solid green = Link exists
Off = No link exists
Solid green = Link to network
Flashing green (1 Hz/cycle per sec) = Network
active
Off = No network activity
Component identification 9
