IMAGE CORRECTION
VARIATION CORRECTION — COLOR BALANCE
Variation Amount Control slider
Limit indication checkbox
In the Color Balance correction, the 6 images that have been corrected by one-step in each red
(R), magenta (M), blue (B), cyan (C), green (G) or yellow (Y) direction for the center image are
displayed. When the image in the direction to be corrected is clicked, the image is placed in
center and new variation images are displayed.
By dragging the Variation Amount Control slider, the value of correction can be changed in the
range from 1 to 20 (The initial value is 10).
When the Limit indication check box is checkmarked and the image is corrected in each red (R),
magenta (M), blue (B), cyan (C), green (G) or yellow (Y) direction, the part of the image in which
the limit of indication (0 to 255) is over is displayed in reversed color.
– 61 –
