Navigation Flow
The flow chart for the automatic operation is represented in icons according to the settings of
the Operation Item checkboxes and the Repeated Operation Item checkboxes.
When clicking on the icon, the operation can be started from the item of the icon you clicked.
Operation Item checkboxes
Only the items which the checkmarks are on these checkboxes can be performed in the
automatic operation. The icons in the flow chart change depending on the settings of the
Operation Item checkboxes. When clicking on the checkmark on the checkbox to remove the
checkmark, the icon of the clicked item is removed from the flow chart. The checkboxes of
"Index Scan" and "Frame Selection" are available only when "35 mm" or "APS Cassette" is
selected in the film format (p.20).
Repeated Operation Item checkboxes
The items which the checkmarks are on these checkboxes are performed even when the frame
changes. The icons in the flow chart change depending on the settings of the Repeated
Operation Item checkbox. When clicking on the checkmark on the checkbox to remove the
checkmark, the icon of the clicked item is removed from the flow chart. These checkboxes are
available only when "35 mm" or "APS Cassette" is selected in the film format (p.20).
Navigation Menu list box
The flow determined by .the settings of the Operation Item checkboxes and the Repeated
Operation Item checkboxes is called "Navigation Set". By clicking on the Navigation Menu list
box to display the menu, the operations such as inputting a name of navigation set and saving
it, selecting or deleting the saved navigation set can be performed.
When the Navigation window is displayed for the first time, the default setting is selected.
Operation Items
The items of the automatic operation are displayed. The order of the item cannot be changed.
Also, adding other items that is not displayed or deleting items cannot be performed.
Navigation Start button
This button performs the automatic operation according to the settings of the Operation Item
checkboxes and the Repeated Operation Item checkboxes.
Navigation Stop button
This button stops the automatic operation. When the Navigation Start button is clicked in this
mode, the operation resumes.
