SCAN SETTINGS WINDOW
Input size lock button
This locks the value in each Input size W or H text box so that you cannot change the value.
While the Input size is locked, the cropping frame is also locked, therefore, that size cannot be
changed.
Magnification Size text box
This allows you to specify a magnification size. Normally, the value which an input resolution is
divided by an output resolution or the value which an output size is divided by an input size is
indicated in percentage. You can also input a value in this box.
*When the input and output sizes are not locked, the input resolution and the output sizes are
changed according to the magnification size you specified.
*When the output size is locked, the input resolution and the input sizes (W/H) are changed
according to the magnification size you specified.
*When the input size is locked, the input resolution and the output sizes (W/H) are changed
according to the magnification size you specified.
*When "pixel" is selected in the Unit list box, the magnification size cannot be selected or
specified.
Output Size text box
This allows you to specify an output size. With the default setting, the image is printed in a
scale of 100 % after performing the final scan.
Although the output size is normally determined by the input and output resolutions and the
cropping frame you specified (p.42 to 44), you can also input a value directly in each W (Wide)
or H (Height) box. In this case, the input resolution and the input size change according to the
values you input and the size of cropping frame also changes correspondingly.
Output size lock button
This locks the value in each Output size W or H text box so that you cannot change the value.
Unit list box
This allows you to select the unit of Input size and Output size from the following units
displayed in the list box. The value with "#" is the default setting.
#pixel/mm/cm/inch/pica/point
Reset button
This resets the scan settings to the settings of the currently selected job file.
Image Size display
This shows the estimated image size after performing the final scan with the current settings.
– 82 –
