Installation - Perlick Signature Series Installation Manual

• Never use extension cord to connect
power to the unit.
• If a 2-prong receptacle is encountered, or
a longer power cord is required, contact
a qualifi ed electrician to have it replaced
in accordance with applicable electrical
codes.
General Information
• All electrical instructions assume the outlet is
located 4" - 10" above the fl oor surface.
• Floor must be level in area of installation. Leg
levelers are used for fi ne-tune adjustment only
and should not be used to compensate for
fl oor differences exceeding 1/2".
Anti-Tip Brackets
Unit may tip forward if
CAUTION
loaded racks/shelves are
all pulled out at the same time. To prevent
tipping, and to provide a stable installation,
the unit must be secured in place with the
anti-tip brackets supplied with the unit. The
anti-tip brackets, when properly installed,
should secure the rear legs/glides to the
mounting surface and prevent the unit from
tipping forward. Refer to Figure 1 for anti-tip
bracket mounting locations.
NOTE: If installing on a concrete fl oor, concrete
fasteners are required and not included with anti-
tip kit.
A set of anti-tip brackets are supplied with the
unit. These brackets should be attached to the
fl oor at the rear of the unit. Each bracket must be
located to engage the rear glides when the cabinet
is pushed back into position (Figure 1).
NOTE: Some installation sites may require
modifi cations to provide a secure surface for
attaching the brackets.
Printed in USA
DANGER
result in possible death or serious injury, fi re,
or loss of property
Casters or Legs (Optional)
Optional casters or legs may be ordered from
the factory for you unit. Refer to the instructions
supplied with the kit for installation.

INSTALLATION

15/32"
3/16"
Figure 1. Anti-Tip Bracket Installation
Preparing the Space
CAUTION
recommended that the countertop be
supported by a structure other than the unit
itself to prevent damage to the unit.
CAUTION
surrounding fi nished fl oor. Protect a fi nished
fl oor with plywood, cardboard or some other
suitable material before moving the unit into
place. Failure to do this may result in damage
to the fl oor.
NOTE: If unit has been laid on its back or sides,
place unit upright and allow minimum of 24 hours
before connecting to a power source.
4
Signature Series Installation Manual
Failure to comply with these
electrical guidelines may
Bottom View of Unit
If unit is to be installed
under a countertop, it is
Make sure the fl oor under
the unit is level with the
3/8"
Anti-tip bracket
engaged with
glide
0213
