Appendix A – Upgrading the Modem's Firmware
Your modem is controlled by semi-permanent software, called firmware, which is stored in flash memory. Firmware is
nonvolatile; that is, it remains stored in memory when the modem is turned off. However, it can be changed by either the
manufacturer or the user as bugs are fixed or new features are added.
Since the firmware in your modem is stored in flash memory, you can upgrade it yourself in a few minutes by using the
following procedures.
Upgrade Overview
The upgrade procedure consists of the following steps, which are described in greater detail in the following sections.
Identify the model number and firmware version of your modem.
1.
Identify the current version of the firmware (you can view this on the Multi-Tech Web site). If your modem already has
2.
the current firmware, there is no need to update it.
Download the upgrade file and the appropriate Flash Wizard for your modem.
3.
Install the Flash Wizard and extract the firmware .HEX file from the file you downloaded.
4.
Document and clear your stored parameters.
5.
Upgrade the modem's firmware using the .HEX file and the Flash Wizard.
6.
Restore your parameters.
7.
Step 1: Identify the Modem Firmware
You must know the model number and firmware version of your Multi-Tech modem to know whether or not you should update
it.
Run your favorite terminal program. If you are using Windows 95 or above, you can use Windows HyperTerminal.
1.
In the program's terminal window, type AT&F. Even if you cannot see the AT&F command on your screen, be sure to
2.
type it completely, and then press E
Now type ATI, press E
3.
to that shown below.
LT V.92 1.0 MT9234ZBA-V-V92 Serial Voice/Data/Fax Modem Version 1.25k
Step 2: Identify the Current Firmware Version
Identify the current version of the firmware at the Multi-Tech Web site. If your modem already has the current firmware, there is
no need to update it.
Using your favorite Web browser, go to http://www.multitech.com/en_US/SUPPORT/Updates/Firmware/.
1.
Scroll down to your modem model number.
2.
Look at the firmware version number for your modem.
3.
If the firmware version number matches the firmware version number found in "Step 1: Identify the Modem Firmware,"
4.
you have the current firmware version and do not need to be update.
If the firmware version number is greater than the firmware version number found in "Step 1: Identify the Modem
5.
Firmware," your modem has an older firmware version. Continue with "Step 3: Download the Upgrade File."
Warning:
properly; e.g., if your current firmware version is 4.16, replace it only with 4.xx firmware, not 6.xx firmware.
Step 3: Download the Upgrade File
If you are not already at the MultiModem ZBA Firmware page of the Multi-Tech Web site, follow the procedure in
1.
"Step 2: Identify the Current Firmware."
Download the upgrade file for your modem by clicking its name, and save the file in a temporary folder on your hard
2.
disk.
In the same section of the Web page, click the Flash Wizard utility for your operating system to download it, and save
3.
it in the same folder.
Multi-Tech Systems, Inc. MT9234ZBA-Series User Guide (S000387D)
Downloaded from Elcodis.com electronic components distributor
NTER
, and record your results. The model number and firmware version should appear similar
NTER
The first digit of the new firmware must match the first digit of the old firmware, or the modem may not work
Appendix A – Upgrading the Modem's Firmware
. If the modem does not respond with OK, repeat the AT&F command.
