This page allows user to set phone settings for Phone 1 and Phone 2 respectively. However, it

changes slightly according to different model you have.

Available settings are explained as follows:

Port – there are two phone ports provided here for you to

configure. Phone1/Phone2 allows you to set general settings

for PSTN phones.

Call Feature – A brief description for call feature will be

shown in this field for your reference.

Tone - Display the tone settings that configured in the

advanced settings page of Phone Index.

Gain - Display the volume gain settings for Mic/Speaker that

configured in the advanced settings page of Phone Index.

Default SIP Account – "draytel_1" is the default SIP account.

You can click the number below the Index field to change SIP

account for each phone port.

DTMF Relay – Display DTMF mode that configured in the

advanced settings page of Phone Index.

Symmetric RTP – Check this box to invoke the function. To

make the data transmission going through on both ends of

local router and remote router not misleading due to IP lost

(for example, sending data from the public IP of remote

router to the private IP of local router), you can check this

box to solve this problem.

Dynamic RTP Port Start - Specifies the start port for RTP

stream. The default value is 10050.

Dynamic RTP Port End - Specifies the end port for RTP

stream. The default value is 15000.

RTP TOS – It decides the level of VoIP package. Use the drop

down list to choose any one of them.

Vigor2860 Series User's Guide
